Models 5360 and 5365
Four Channel
Analog to Digital Video
Converters and
Embedders Data Pack
E
N S E M B L E
D
E
S
I
This data pack provides detailed installation, configuration and operation information for
both the 5360 and 5365 Four Channel Analog to Digital Video Converters and
Embedders module as part of the Avenue Signal Integration System.
The module information in this data pack is organized into the following sections:
• 5360 and 5365 Overview
• Applications
• Installation
• Cabling
• Module Configuration and Control
Front Panel Controls and Indicators
°
Avenue PC Remote Control
°
Avenue Touch Screen Remote Control
°
• Troubleshooting
• Software Updating
• Warranty and Factory Service
• Specifications
G
N
S
Revision 1.3 SW v2.2.1
5360-1
Advertisement
Table of Contents
Related Manuals for Ensemble Designs Avenue 5360
Summary of Contents for Ensemble Designs Avenue 5360
- Page 1 Models 5360 and 5365 Four Channel Analog to Digital Video Converters and Embedders Data Pack N S E M B L E Revision 1.3 SW v2.2.1 This data pack provides detailed installation, configuration and operation information for both the 5360 and 5365 Four Channel Analog to Digital Video Converters and Embedders module as part of the Avenue Signal Integration System.
- Page 2 Models 5360 and 5365 Four Channel Analog to Digital Video Converters and Embedders 5360 AND 5365 OVERVIEW The Avenue 5360 and 5365 modules convert four channels of analog video and audio to four streams of SD SDI with embedded audio. Use these modules with routers, switchers, remote trucks or any application that requires many channels of high quality video and conversion.
- Page 3 Models 5360 and 5365 Four Channel Analog to Digital Video Converters and Embedders 12 bit Composite Input SD SDI Output Frame Sync A to D Audio Channel Converter Proc Amp & Decoder Analog Audio Input 24 Bit 12 bit Composite Input SD SDI Output Frame Sync A to D...
-
Page 4: Satellite Reception
Models 5360 and 5365 Four Channel Analog to Digital Video Converters and Embedders APPLICATIONS This section provides a typical application for using the 5360 Video ADC/TBC module. Satellite Reception As illustrated in the block diagram below, the 5360 will accept up to four analog inputs, convert them to serial digital, then lock the signals to the house reference with full timing capability. -
Page 5: Installation
Models 5360 and 5365 Four Channel Analog to Digital Video Converters and Embedders INSTALLATION 5360 and 5365 ADC Modules Plug the 5360 or 5365 modules into any one of the slots in the 1 RU or 3 RU frame and install the plastic overlay provided onto the corresponding group of rear BNC connectors associated with the module location. - Page 6 Models 5360 and 5365 Four Channel Analog to Digital Video Converters and Embedders 3 RU Backplane 5360 ADC SDI Out 1 Connect a composite input to be converted to Cpst In 1 and the converted output SDI Out 1 to an Cpst In 1 SDI destination.
- Page 7 Models 5360 and 5365 Four Channel Analog to Digital Video Converters and Embedders 3 RU Backplane 5365 ADC SDI Out 1 Connect a composite input to be converted to Cpst In 1 and the converted output SDI Out 1 to an Cpst In 1 SDI destination.
-
Page 8: Module Configuration And Control
Models 5360 and 5365 Four Channel Analog to Digital Video Converters and Embedders MODULE CONFIGURATION AND CONTROL The configuration parameters for each Avenue module must be selected after installation. This can be done remotely using one of the Avenue remote control options or locally using the module front panel controls. - Page 9 Models 5360 and 5365 Four Channel Analog to Digital Video Converters and Embedders 5360 Parameter Table FACTORY DEFAULT CONTROL LOCAL REMOTE DEFAULT USER LEVEL Narrow (PAL Lines 1-6< NTSC Lines 1-9) Ch 1-4 Blanking Wide Wide Admin Wide (PAL Lines 1-22< NTSC Lines 1-20) Ext Ref Ch 1-4 Reference...
- Page 10 Models 5360 and 5365 Four Channel Analog to Digital Video Converters and Embedders 5365 Parameter Table FACTORY DEFAULT CONTROL LOCAL REMOTE DEFAULT USER LEVEL Narrow (PAL Lines 1-6< NTSC Lines 1-9) Ch 1-4 Blanking Wide Wide Admin Wide (PAL Lines 1-22< NTSC Lines 1-20) Ch 1-4 Setup Removal Admin...
-
Page 11: Front Panel Controls And Indicators
Models 5360 and 5365 Four Channel Analog to Digital Video Converters and Embedders Front Panel Controls and Indicators Each front edge indicators and switch settings are shown in the diagrams below: 5360 Channel ADC / TBC Ch 1-4 Input green LEDs: On indicates input video signal is present and detected on each Input 1... - Page 12 Models 5360 and 5365 Four Channel Analog to Digital Video Converters and Embedders 5365 Channel Ch 1-4 Input green LEDs: On indicates input video signal is present and detected on each Input 1 individual channel. OFF no input video signal detected Input 2 on the input of each channel.
-
Page 13: Avenue Pc Remote Configuration
Models 5360 and 5365 Four Channel Analog to Digital Video Converters and Embedders Avenue PC Remote Configuration The Avenue PC remote control menus for these module are illustrated and explained below. Refer to the 5360 and 5365 Parameter Tables for a summary of available param- eters that can be set remotely through the menus illustrated. - Page 14 Models 5360 and 5365 Four Channel Analog to Digital Video Converters and Embedders The Proc 2 menu shown below gives an example of the adjustable video processing parameters for each channel in their respective Proc 1 – 4 menus: • Gain – adjust the percentage of overall gain (luminance and chrominance). Available value range: 0 –...
- Page 15 Models 5360 and 5365 Four Channel Analog to Digital Video Converters and Embedders The Audio 1 menu example shown below shows the configuration parameters available for each individual channel 1 – 4 in their respective Audio menus. • Audio Gain – use this control to adjust the audio gain as desired, ranging from -700 to 120 dB.
- Page 16 Models 5360 and 5365 Four Channel Analog to Digital Video Converters and Embedders NOTE: The Config All menu as shown below is for model 5360. For the 5365, the Config All menu contains only the Dig Ref Level field. The Config All menu shown below allows you to select and monitor the reference for all channels as follows: •...
-
Page 17: Avenue Touch Screen Remote Configuration
Models 5360 and 5365 Four Channel Analog to Digital Video Converters and Embedders Avenue Touch Screen Remote Configuration The Avenue Touch Screen remote control menus for this module are illustrated and explained below. Refer to the 5360 and 5365 Parameter Tables for a summary of available parameters that can be set remotely through the menus illustrated. - Page 18 Models 5360 and 5365 Four Channel Analog to Digital Video Converters and Embedders Repeat the configuration for each of the four input channels with their respective Config menus. The Proc 2 menu shown below gives an example of the adjustable video processing parameters for each channel in their respective Proc 1 –...
- Page 19 Models 5360 and 5365 Four Channel Analog to Digital Video Converters and Embedders The Audio 1 menu example shown below shows the configuration parameters available for each individual channel 1 – 4 in their respective Audio menus. • Audio Gain – use this control to adjust the audio gain as desired, ranging from -700 to 120 dB.
- Page 20 Models 5360 and 5365 Four Channel Analog to Digital Video Converters and Embedders NOTE: The Config All menu as shown below is for model 5360. For the 5365, the Config All menu contains only the Dig Ref Level field. The Config All menu shown below allows you to select and monitor the reference for all channels as follows: •...
- Page 21 Models 5360 and 5365 Four Channel Analog to Digital Video Converters and Embedders...
-
Page 22: Troubleshooting
• Check cabling to inputs of module. • Check inputs to destinations are terminated properly. You may also refer to the technical support section of the Ensemble Designs web site for the latest information on your equipment at the URL below: http://www.ensembledesigns.com/support... -
Page 23: Warranty And Factory Service
If you return equipment for repair, please get a Return Material Authorization Number (RMA) from the factory first. Ship the product and a written description of the problem to: Ensemble Designs, Inc. Attention: Customer Service RMA ##### 870 Gold Flat Rd. - Page 24 Model 5330/6330 Video Audio ADC SPECIFICATIONS 5360 4 Channel ADC/TBC Analog Video Inputs (4 each) Signal Type NTSC, PAL Composite Impedance 75 Ω Return Loss > 40 dB DC to 5.5 MHz Input DC ±1 volt DC Input Hum <100 mV Reference Input (5360 only) Signal Type 1 V P-P Composite Video, PAL or NTSC...
