- Page 1 ZA-1037L6 Motherboard User Manual Support Intel Celeron 1037u 1.80 GHz Processor ®...
- Page 2 ZA-1037L6 Motherboard Diagram...
-
Page 3: Motherboard Specification
Motherboard Specification Size 210mm x 180mm Support Intel Celeron 1037u 1.80 GHz Processor Graphics Intel HD Graphics Chipset 1037u Memory 1* DDR3 Slot ,1066/1333/1600MHz memory ,Up to 8 GB 1* USB PIN,Support 2* USB2.0 Internal I/O 1* CPUFan 1* SATA 1* RJ45 COM1 6* LAN WG82583 10/100/1000M ethernet ports Rear I/O... - Page 4 Motherboard I/O Interface Diagram DC_IN DDR3 JSATA1-2 SATA1-2 PWON SFAN2 MSATA USB6 WIFI USB2 SFAN1 VGA2 LPC1 COM1 KBPS2 USB2.0 TJ45COM1 PWR_HDD_LED TJ1-6 RST DEF...
- Page 5 SFAN1 SFAN2 Installation memory: 1. Please turn off the power before installing or removing the memory, and dial down the AC power cord. 2. Carefully hold both ends of the memory stick, and do not touch the metal contact above. 3.
- Page 6 Define Define Define Define VGA_VSYNC VGA_HSYNC VGA_RED VGA_GRN VGA_BULE DDC_DATA DDC_CLK FUSB1 Define Define FUSB1 DATA 0- DATA1- DATA0+ DATA1+ NC(CUT) *Other Matters Please consult the sales. ShenZhen Zeal-All Technology Co.,Ltd www.zeal-all.com +86-0755-86959086...
