RBP -1509B-RX3 Instructions

2007 – 2017 JEEP WRANGLER JK 4-DOOR
12- 8-1.25mm x 30mm Hex Bolt
12- 8mm Lock Washer
18- 8mm x 24mm OD x 2mm Flat Washer
6- 8mm Nuts
STEP 1- Locate the driver side step (The shorter bent side goes toward the front of the vehicle)
STEP 2- Remove any old steps or factory installed "Rock Rails" and hardware from vehicle.
STEP 3- Start installation toward the front of the driver side of the vehicle. Determine if the vehicle has an open
floor panel or a threaded hole in the floor panel for the top tab on the Bracket, (Figures 1 - 2). Remove any
insulation that may be covering the mounting locations.
STEP 4- Place the driver step close to the vehicle and follow the instructions below:
a) Vehicles with open mounting location: Insert (1) 10mm Nut Plate into the large square opening in the
floor panel. Line up the threaded nut with the small hole in line with the tab on the Bracket. Bolt the
Bracket to the Nut Plate with (1) 10mm x 35mm Hex Bolt, (1) 10mm Lock Washer and (1) 10mm x 34mm
Flat Washer. Hand tighten at this time only and do this for all three brackets.
b) Vehicles with factory threaded hole in floor panel: Bolt the tab on the Bracket to the threaded hole in the
floor panel with (1) 8mm x 30mm Hex Bolt, (1) 8mm Lock Washer and (1) 8mm x 24mm OD Flat Washer.
Hand tighten at this time only and do this for all three brackets.
STEP 5- Line up the mounting plate on the Bracket with the factory hole in the pinch weld. Bolt the Mounting
Bracket to the back of the pinch weld using (1) 8mm x 30mm Hex Bolt, (2) 8mm x 24mm OD Flat Washers,
(against pinch weld), (1) 8mm x 24mm OD Flat Washers, (inside against the bracket), (1) 8mm Lock Washer, and
(1) 8mm Nuts, (You may need to drill a hole in the pinch weld to enlarge an existing hole for the 8mm Hex Bolt).
Hand tighten at this time only and do this for all three brackets.
STEP 6- Once the step is installed and the bolts are hand tight, verify the fitment and alignment. Once
everything is verified, torque the bolts down to 20lbs per square foot. Repeat steps for the passenger side.
RBP 13000 TEMPLE AVE. CITY OF INDUSTRY, CA 91746 800-237-7560
RBP-1509B-RX3/RBP-1509SS-RX3

HARDWARE INCLUDED

4-
4-
4-
4-
10mm Nut Plates
10-1.5mm x 35mm Hex Bolt
10mm Lock Washer
10mm x 34mm OD x 2mm Flat Washer
Page 1 of 2

RECOMMENDED TOOLS

2- 13mm Wrenches
Drill & 5/16" Bit
4/2017
