- Page 1 2018 JEEP WRANGLER JL 4-DOOR RX3 SIDE STEPS INSTALLATION INSTRUCTIONS 1-877-519-9090...
- Page 2 The paintable, textured inserts allow you to customize your steps for a look truly your own. The RBP RX-3 step bars include all mounting brackets and instructions for easy installation.
-
Page 3: Hardware Included
2018 JEEP WRANGLER JL 4-DOOR RX3 SIDE STEPS INSTALLATION INSTRUCTIONS HARDWARE INCLUDED RECOMMENDED TOOLS Driver/left RX3 Side Step 13mm Wrench and/or Socket Passenger/right RX3 Side Step 10mm Wrench and Socket 8-1.25mm x 35mm Hex Bolts 8mm x 28mm x 3mm Flat Washers 8mm Lock Washers 6-1.0mm x 25mm Hex Bolts 6mm x 22mm x 2mm Flat Washers... - Page 4 2018 JEEP WRANGLER JL 4-DOOR RX3 SIDE STEPS INSTALLATION INSTRUCTIONS STEP 4: With assistance, hold the Driver/left RX3 Side Step up in place against the back of the pinch weld. Line up the (3) welded brackets with the (6) factory holes in the pinch weld. Bolt the brackets to the back of the pinch weld with the included (6) 6mm x 25mm Hex Bolts, (12) 6mm Flat Washers and (6) 6mm Nylon Lock Nuts, (Figures 5—8, 10).
- Page 5 2018 JEEP WRANGLER JL 4-DOOR RX3 SIDE STEPS INSTALLATION INSTRUCTIONS FIGURE 2 Threaded hole on floor panel Pair of holes on pinch weld FRONT Driver/left side front mounting location FIGURE 3 Threaded hole on floor panel Pair of holes on pinch weld FRONT Driver/left side center mounting location 1-877-519-9090...
- Page 6 2018 JEEP WRANGLER JL 4-DOOR RX3 SIDE STEPS INSTALLATION INSTRUCTIONS FIGURE 4 Threaded hole on floor panel Pair of holes on pinch weld REAR Driver/left side rear mounting location FIGURE 5 (2) 6mm x 25mm Hex Bolts (4) 6mm Flat Washers (2) 6mm Nylon Lock Nuts 8mm Hex Bolt FRONT...
- Page 7 2018 JEEP WRANGLER JL 4-DOOR RX3 SIDE STEPS INSTALLATION INSTRUCTIONS FIGURE 6 (2) 6mm x 25mm Hex Bolts (4) 6mm Flat Washers FRONT (2) 6mm Nylon Lock Nuts Driver/left side front welded Bracket attached to back of pinch weld FIGURE 7 (2) 6mm x 25mm Hex Bolts FRONT (4) 6mm Flat Washers...
- Page 8 2018 JEEP WRANGLER JL 4-DOOR RX3 SIDE STEPS INSTALLATION INSTRUCTIONS FIGURE 8 (2) 6mm x 25mm Hex Bolts REAR (4) 6mm Flat Washers (2) 6mm Nylon Lock Nuts Driver/left side rear welded Bracket attached to back of pinch weld FIGURE 9 8mm Hex Bolt 8mm Lock Washer 8mm Flat Washer...
- Page 9 2018 JEEP WRANGLER JL 4-DOOR RX3 SIDE STEPS INSTALLATION INSTRUCTIONS FIGURE 10 (4) 6mm x 25mm Hex Bolts (8) 6mm Flat Washers (4) 6mm Nylon Lock Nuts (2) 8mm Hex Bolts FRONT (2) 8mm Lock Washers (2) 8mm Flat Washers Driver/left side Center &...
- Page 10 2018 JEEP WRANGLER JL 4-DOOR RX3 SIDE STEPS INSTALLATION INSTRUCTIONS FIGURE 10 FRONT 8mm Hex Bolt 8mm Lock Washer 8mm Flat Washer Driver/left side center welded Bracket attached to inner floor panel FIGURE 11 REAR 8mm Hex Bolt 8mm Lock Washer 8mm Flat Washer Driver/left side rear welded Bracket attached to inner floor panel...
- Page 11 STRAIGHT DOIN’ IT ™ www.rollingbigpower.com may have additional information about this product including the latest instructions, videos, photos, etc. For customer support, please call us at 1-877-519-9090 to speak directly with a RBP customer service representative.
