RBP -1308B-RX3 Instructions

2017 FORD F-250/350 SUPER CREW CAB RX3

HARDWARE INCLUDED

18 8mm x 24mm OD x 2mm Flat Washer
18 8mm Nylon Lock Nut
18 8mm Plastic Washers

PASSENGER-RIGHT SIDE INSTALLATION:

STEP 1- Remove any old steps and hardware as required from truck.
STEP 2-Select (9) 8mm Plastic Insulation Washers. Thread the Washers onto each of the factory
studs in the inner side of the passenger side body panel, (Figures 1—3). IMPORTANT: The Plastic
Washers are designed to prevent corrosion between the aluminum body panel and the steel mounting
brackets. Do not install the side steps without the Plastic Washers.
STEP 3-Carefully unwrap and select the passenger side step, (Figure 4). With assistance, place the
step over the factory threaded studs. Attach the side step to the threaded studs with (9) 8mm Flat
Washers and (9) 8mm Nylon Lock Nuts, (Figures 5—7). Do not fully tighten hardware at this time.
STEP 4- Once the step is installed and the bolts snug tightened, check the fitment and alignment.
Once everything is verified, torque the bolts down to 20ft-lbs.
STEP 5- Repeat Steps 1—4 for the driver side installation.
Periodically check installation and re-torque all fasters to specifications.
RBP 13000 TEMPLE AVE. CITY OF INDUSTRY, CA 91746 800-237-7560
RBP-1308B-RX3/RBP-1308SS-RX3
Factory mounting
studs
Page 1 of 2

RECOMMENDED TOOLS

13mm Wrench
13mm Socket
3/8 Torque Wrench
3/8 Ratchet w/3" & 6" extensions
4/2017
