RBP -1414B-RX3 Instructions

HARDWARE INCLUDED

1 Driver Side RX3 Side Step
1 Passenger side RX3 Side Step
12 8-1.25mm x 30mm Hex Bolts
STEP 1 — Remove any old steps or factory installed "Rock Rails" and hardware from vehicle.
STEP 2 — Start installation on the driver/left front side of the vehicle. Locate and remove the (2) factory hex
bolts covering the mounting location on the body panel, (Figure 1). NOTE: Temporarily hold up in position the
driver side RX3 Step to help determine the correct mounting locations.
STEP 3 — Move along the body panel to the center and rear mounting locations and repeat Step 2, (Figure 2).
STEP 4 — Select the Driver side RX3 Step. Line up the welded Brackets on the Step with the threaded inserts on
the body panel. With assistance, use (6) 8mm Hex Bolts, (6) 8mm Lock Washers and (6) 8mm Flat Washers to
attach the (6) slots on the Brackets to the (6) threaded inserts, (Figures 3—6). Leave hardware loose.
13000 TEMPLE AVE. CITY OF INDUSTRY, CA 91746 1-800-237-7506
2010- 2017 4RUNNER RX3 SIDE STEPS
12 8mm x 24mm x 2mm Flat Washers
12 8mm Lock Washers
Page 1 of 2
RBP-1414B-RX3
Driver/left side
RX3 step
Front of
Vehicle
Passenger/right
side RX3 step

RECOMMENDED TOOLS

1 13mm Socket or Wrench
10/18/17 (RA)
