- Page 1 380W Beam/Spot/Wash Moving Head Manual Book （Color display, touch screen） Please read this manual carefully before your operation.
-
Page 2: Table Of Contents
Catalogue I Notice and Setup.......................3 Maintaining......................3 Statement......................3 Notice......................3 Parameter......................3 Signal connection（DMX）................4 Item installation....................4 II Menu operation......................5 Summary......................5 Operation......................6 Control item by touch screen or console...........6 Value input....................6 Setup value....................6 Sbupage（parameter）................6 Function operation and parameter setup............7 Setup DMX address code................7 Setup work mode..................8 Setup menu display..................9 Test......................10 Setup work parameter................10... -
Page 3: I Notice And Setup
I Notice and setup Maintaining Keep dry, don’t use it in wet environment. Intermittent using can extend the life of item. Please often clean fan, fan net and lens to get better cooling and brightness effect. Please don’t clean the cover with solvent like alcohol. -
Page 4: Signal Connection（Dmx
Bigger adjustable range of beam angle； Strobe：Mechanical strobe and can adjust speed，support Macro function of strobe； Channel: 23/28CH Lens optical system，electrical focus，beam angle: 3.8°-53° linear adjustment； Use photo-electricity reset system, self-correction； Pan 540°，8Bit/16Bit； Tilt 270°，... -
Page 5: Menu Operation
Picture 2 Reversal hang show II Menu operation Summary Like picture 3（it’s 4 keys in this picture），left is TFT display that support touch operation; right is 4 keys or 5 keys or encoder knob, you can control light directly or setup system parameter by them. -
Page 6: Operation
Picture 3 Display Operation 1. Control item by touch screen or console The left is TFT display and touch area. You can setup the parameter or check status by touching menu contents. The right is rotary encoder. Please swirl encoder to setup or check menu if you don’t use TFT touch screen. -
Page 7: Function Operation And Parameter Setup
TEST：For lighting test, simulate the value of corresponding DMX channel； ADVANCE：set operating parameter； STATUS：check current status. Picture 6 Submenu 3 Function operation and parameter setup Get into menu like picture 6: In primary menu, can get into corresponding submenu by touching 6 different button. ... -
Page 8: Setup Work Mode
Picture 7 Add set page 2. Set work mode Please set the work mode, control lamp and channel mode like picture . The light has four mode-DMX mode, auto run mode, sound active mode and master/slave mode. The detail parameter is as following: ... -
Page 9: Setup Menu Display
Picture 8 Run mode windows Set menu display There are two language-Chinese and English like picture 9. Langudge：Choose Chinese or English language Screen Saver：If there is no change in 10 seconds, the light will be screen saver. When light is in “Mode 1”, the screen is closed(black screen);... -
Page 10: Test
Test The light is on test mode like picture 10. The lights don’t receive the DMX controller’s date.The parameter on menu is related to the DMX channels value and you can control the light run by changing value. The detail value is as following: ... -
Page 11: Check Current Status
Picture 11 advance page Check current status Get into page like picture 12： In this page, can check the current status and version information of light； DMXClr：Make the DMX date be zero； SysRst：motor reset； Picture 12 status page... -
Page 12: Channel Description
III Channel description Channel list Channel Channel Value Description Function Mode 1 Mode 2 4-103 Pulse strobe from slow to fast 104-107 Strobe 108-207 Gradually strobe from slow to fast 208-212 213-251 Random strobe from slow to fast 252-255 Dimmer 0-255 0-100% dimmer Dimmer fine... - Page 13 Gobo 1 10-14 Gobo 2 15-19 Gobo 3 20-24 Gobo 4 25-29 Gobo 5 30-34 Gobo 6 35-39 Gobo 7 40-44 Gobo 8 45-49 Gobo 9 50-54 Gobo 10 55-59 Gobo 11 60-64 Gobo 12 65-69 Gobo 1 shaking from slow to fast 70-74 Gobo 2 shaking from slow to fast 75-79...
- Page 14 150-199 Forward water effect from fast to slow 200-255 Reverse water effect from slow to fast 0-127 0-360 degree 128-187 Forward water effect from fast to slow CH11 Gobo rotation 188-195 Stop 196-255 Reverse water effect from slow to fast CH12 0-255 Rotation fine...
- Page 15 0-127 CH22 CH17 Frost 128-191 Chromosomal schema CH23 CH18 0-255 0-540 degree CH24 CH19 Pan fine 0-255 0-2 degree CH25 CH20 Tilt 0-255 0-270 degree CH26 CH21 Tilt fine 0-255 0-1 degree CH27 CH22 XY speed 0-255 From fast to slow 100-105 Lamp on after 3 seconds 200-205...
-
Page 16: Normal Faulty And Using Attention
IV Normal faulty and using attention 1) Normal faulty solution There are professional parts like mainboard, power supply in lights. Non-professionals mustn’t disassemble item and parts without authorization. Lamp is not on. Possible reason：lamps don’t cool down; lamps is out of life. Solution is as following: ... - Page 17 2) Using attention Check if the local power is suitable for the rated voltage or not, leakage protector and over-current protector is suitable for the electrical load or not ； Don’t use the power line with damaged insulating layer, don’t connect the power line with other guide wire；...
