CARTRIDGE FILTER PUMP
READ AND KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
For answers to common questions, setup videos and troubleshooting tips, please visit
support.polygroupstore.com or call Customer Service: (888) 919-0070
DO NOT RETURN PRODUCT TO STORE
Should you encounter a problem with your Polygroup® Product, please DO NOT return the product to the place of purchase. All Warranty claims must be made directly
to Polygroup®. Prior to contacting Customer Service, please first review the Troubleshooting Guide in the Installation Manual, or review the FAQ and instructional
videos at support.polygroupstore.com. If you are still unable to correct the problem, please contact Polygroup® Customer Service at (888) 919-0070. Please have the
product type, model number and your purchase receipt ready, so that our Customer Service Representative can assist you in resolving the problem. You may be asked
to return all or part of the product for inspection and/or repair. Do not return any product to Polygroup® without a Return Merchandise Authorization number.
Polygroup
Limited (Macao Commercial Offshore), (hereinafter "Polygroup
®
material and workmanship for 180 days from the date of purchase.
receipt and must produce such upon request by Polygroup
This Limited Warranty applies only to the original purchaser of the product and is limited solely to the repair or replacement of the product, to be decided in Polygroup
sole discretion. Consequential damages, including claims for loss of water, pool chemicals, damage, or labor are not covered under this Limited Warranty. This Warranty
will be declared invalid should the Purchaser modify or repair the product themselves or by unauthorized persons; use non-Polygroup
product; use the product in contravention of the manufacturer's Instructions; use improper voltage; abuse the product in any way; or through accident or negligence.
Normal wear-and-tear is not covered under this Warranty, nor are acts of God outside the control of Polygroup
grasses that may grow through the ground cloth and/or pool liner, as this is not a manufacturing defect.
IN NO EVENT SHALL Polygroup
PARTY FOR DIRECT OR CONSEQUENTIAL DAMAGES. Some states or countries, or others jurisdictions, do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitation or exclusion may not apply to you.
DISTRIBUTED BY: Polygroup
Unit J, 10
SUMMER WAVES
FOR ABOVE GROUND SWIMMING POOLS
RP350 / RP400 models

LIMITED WARRANTY

Original Purchaser must retain proof of such purchase in the form of an original store sales
or its designated agents.
®
, THEIR AUTHORIZED AGENTS, RELATED ENTITIES, OR EMPLOYEES BE LIABLE TO THE BUYER OR ANY OTHER
®
LIMITED (MACAO COMMERCIAL OFFSHORE)
®
Floor, Macau Square, Av do Infante D.Henrique, No.43-53A, Macau
th
") warrants to the original purchaser only, the RP type Electric Filter Pump against defects in
®
Warranty claims cannot be processed without a valid proof of purchase.
OWNER'S MANUAL
®
To order parts and accessories,
please visit www.polygroupstore.com
parts or accessories with the
®
. Polygroup
will not be held responsible for
®
®
09C3A40USA11
's
®
Manual #

Advertisement

Chapters

Table of Contents
loading

Summary of Contents for Polygroup SUMMER WAVES RP350

  • Page 1: Limited Warranty

    Warranty claims cannot be processed without a valid proof of purchase. ® This Limited Warranty applies only to the original purchaser of the product and is limited solely to the repair or replacement of the product, to be decided in Polygroup ’s ®...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS Warnings 3 ~ 6 Preliminary Steps & Filter Pump Important Notes & Filter Pump Power Information & Parts 7 ~ 9 List Setup Instructions 10 ~ 11 Filter Pump Operation & Motor Protection & Filter Cartridge Cleaning and Replacement Pool Maintenance &...
  • Page 3: Warnings

    EXPENSES WHEN INSTALLING A POOL, IN ORDER TO COMPLY WITH STATE OR LOCAL LAWS REGARDING FENCING AND OTHER SAFETY REQUIREMENTS. CUSTOMERS SHOULD CONTACT THEIR LOCAL BUILDING CODE ENFORCEMENT OFFICE FOR FURTHER DETAILS. POLYGROUP® IS NOT RESPONSIBLE FOR ANY ADDITIONAL EXPENSES THAT YOU MAY INCUR. Safety Care for Children 1.
  • Page 4 Turn on the pump for the recommended hours daily. If you are unsure of the time frames please refer to support.polygroupstore.com for the recommended Pump Operation Hours based on pool types and sizes. Clean and replace filter cartridge frequently. Replace only with genuine Polygroup / Summer Wave Brand filter cartridge.
  • Page 5: Warnings

    OWNER’S MANUAL First Aid 1. Keep a working phone and a list of emergency numbers near the pool. 2. Become certified in cardiopulmonary resuscitation (CPR). In the event of an emergency, immediate use of CPR can make a lifesaving difference. Special Warning 1.
  • Page 6: Save These Instructions

    ASME American Society of Mechanical Engineers Two Park Avenue, New York NY 10016-5990 Contact: 800-843-2763 (U.S. & Canada) 973-882-1170 (outside North America) www.asme.org NSPI National Spa and Pool Institute (see APSP) UL Underwriters Laboratories 333 Pfingsten Road,Northbrook IL 60062-2096 Contact: 877-854-3577 or 847-272-8800 www.ul.com NSF NSF International P.O.
  • Page 7: Parts List

    DO NOT use this to dispense powdered chlorine, shock treatment, or any other type of chemicals as damage to the pump, filter cartridge, and pool will occur. 4. The RP Series Filter Pump systems are manufactured by Polygroup and ETL control number 4000608 and 4006317 - double insulated and ®...
  • Page 8 How to use the GFCI plug Press "RESET" Button To Start Pump Operation *Do not connect to a timer device RP-350 / RP-400 RETURN FITTING SUCTION FITTING Should you encounter any problems, contact Customer Service at (888) 919-0070 from 8 AM to 5 PM Mon. thru Fri. MST.
  • Page 9 OWNER’S MANUAL 17 A RP-350 RP-400 Should you encounter any problems, contact Customer Service at (888) 919-0070 from 8 AM to 5 PM Mon. thru Fri. MST. Extended operating days and hours during peak season requirements.
  • Page 10: Setup Instructions

    SETUP INSTRUCTIONS Before assembling your product, please take a few minutes to check the contents and become familiar with all the parts. WARNING: CLIMBING HAZZARD! PLEASE PREVENT CHILDREN FROM CLIMBING ON THE FILTER CANISTER TO GAIN ACCESS TO THE POOL. 1.
  • Page 11 OWNER’S MANUAL 5. Lubricate the O-rings on the Suction Fitting and the Filter Pump 6. Lubricate the O-rings on the Return Fitting and the Filter Pump Inlet with petroleum jelly (not included). Outlet with petroleum jelly (not included). Connect the Hose from Connect the Hose from the Suction Fitting...
  • Page 12 We recommend that you keep at least one spare filter cartridge on hand at all times. Filter cartridges may be purchased at the store you purchased your pool from, or ordered from Polygroup® at polygroupstore.com. *Do not connect to a timer device 6.
  • Page 13: Pool Maintenance & Water Care

    . Also, a well-maintained, clean cartridge assures you that your filter will always be ready to operate at peak efficiency. 9. Filter cartridges may be purchased at the store you purchased your pool from, or ordered from Polygroup at polygroupstore.com. Always replace with ®...
  • Page 14: Troubleshooting Guide

    TROUBLESHOOTING GUIDE WARNING: TURN OFF THE PUMP AND UNPLUG THE POWER CORD BEFORE TROUBLESHOOTING THE FILTER PUMP. SYMPTOM CAUSE SOLUTION A Unit not plugged in or A Unit must be plugged into a 3-wire grounded power outlet. Press the reset button on the GFCI not activated GFCI to start the pump.
  • Page 15: Pump Removal Instructions For Troubleshooting

    OWNER’S MANUAL PUMP REMOVAL INSTRUCTIONS FOR TROUBLESHOOTING 1. First turn the pump off and unplug the main power cord of the system. Remove the RF Diverter from the Return Fitting , and then plug the Return Fitting with the RF Plug .
  • Page 16 Please see Pool Support - Filtration System Troubleshooting for the RP350/RP400 Filtration System at support.polygroupstore.com. PLEASE NOTE: Even if the rotor assembly is in perfect condition; if it is not seated properly between the volute housing and the pump it will not function correctly. To reassemble the pump (Motor Assembly): Carefully insert the Rotor Assembly into the Pump Motor Body .
  • Page 17: Replacement Parts Ordering Information

    OWNER’S MANUAL REPLACEMENT PARTS ORDERING INFORMATION RP-350 RP-400 DESCRIPTION PART # Fitting Gasket P58PF1520K01 P58PF1520K01 Suction Fitting P58281283W05 P58281283W05 Suction Fitting Thrust Washer (SF Washer) P58PF1510K01 P58PF1510K01 Return/Suction Fitting Lock Nut P58PF1430W05 P58PF1430W05 Suction Fitting Cap (SF Cap) P58PF2820P01 P58PF2820P01 Return Fitting P58PF7800W05 P58PF7800W05...
  • Page 18: Asme Compliant Suction Fitting Information

    OWNER’S MANUAL ASME COMPLIANT SUCTION FITTING INFORMATION PSF-100A AND PSF-100B SUCTION OUTLET (FOR ABOVE GROUND POOLS) 1. PSF-100A and PSF-100B Suction Outlets are certified by IAPMO in accordance with the ASME/ANSI A112.19.8b-2009 Suction Fitting for use in Swimming Pools, Wading Pools, Spas, and Hot Tubs. 2.
  • Page 19 Esta garantía no cubre el desgaste normal, así como los casos de fuerza mayor fuera del control de Polygroup®. Polygroup® no se hace responsable de las hierbas que pueden crecer a través del paño de tierra y / o el revestimiento de la piscina, ya que esto no es un defecto de fabricación.
  • Page 20 ÍNDICE Advertencias..............................3 ~ 6 Pasos Preliminares y Notas Importantes Acerca de la Bomba de Filtración y Información Sobre La Potencia de la Bomba de Filtración y Lista de Piezas.................. 7 ~ 9 Instrucciones de montaje..........................10 ~ 11 Funcionamiento de la bomba de filtración, protección del motor y limpieza y sustitución del cartucho filtrante....Mantenimiento de la piscina y tratamiento del agua..................
  • Page 21: Advertencias

    ADICIONALES AL INSTALAR UNA PISCINA, EN CUMPLIMIENTO DE LAS LEYES ESTATALES O LOCALES RELATIVAS AL VALLADO Y OTROS REQUISITOS DE SEGURIDAD. LOS CLIENTES DEBEN PONERSE EN CONTACTO CON LAS AUTORIDADES LOCALES CORRESPONDIENTES PARA MÁS INFORMACIÓN. POLYGROUP NO ES RESPONSABLE POR GASTOS ADDICIONALES QUE PUEDAN OCCURIR. Precauciones de seguridad para los niños 1.
  • Page 22 Active el sistema de bomba del filtro durante al menos 6 horas al día. Limpie y cambie el cartucho del filtro con frecuencia. Reemplazar solo con un cartucho de filtro original de la marca Polygroup / Summer Waves .
  • Page 23 MANUAL DE USUARIO filtro de la bomba debe colocarse de manera que no pueda ser usado por los niños pequeños como medio de acceso a la piscina. No deje juguetes dentro de la piscina al terminar de usarla, ya que los juguetes y objetos similares podrían atraer a los niños a la piscina. 3.
  • Page 24 ANSI American National Standards Institute 25 West 43rd Street, New York NY 10036 Contacto: 212-642-4900 www.ansi.org APSP Association of Pool & Spa Professionals (formerly National Spa and Pool Institute) 2111 Eisenhower Avenue, Suite 500 Alexandria VA 22314-4679 Contacto: 703-838-0083 www.apsp.org ASME American Society of Mechanical Engineers Two Park Avenue, New York NY 10016-5990 Contacto: 800-843-2763 (U.S.
  • Page 25: La Bomba De Filtración Y Lista De Piezas

    (véase la página 9). NO lo utilice para dispensar cloro en polvo, sustancias químicas para tratamientos de choque o de cualquier otro tipo ya que la bomba, el cartucho filtrante y la piscina pueden resultar dañados. 4. Los sistemas de bomba de filtración de la serie RP son fabricados por Polygroup con el número de control de ETL 4000608 y 4006317, con doble aislamiento y ®...
  • Page 26 Cómo utilizar el tapón del GFCI Pulse el botón "RESET" para arrancar la bomba *No conectar a un temporizador RP-350 / RP-400 ACCESORIO DE RETORNO ACCESORIO DE SUCCIÓN En caso de problemas, póngase en contacto con el servicio de atención al cliente en el (888) 919-0070, de L a V de 8h a 17h. MST.
  • Page 27 MANUAL DE USUARIO 17 A RP-350 RP-400 En caso de problemas, póngase en contacto con el servicio de atención al cliente en el (888) 919-0070, de L a V de 8h a 17h. MST. Los horarios de atención se amplían durante temporada alta.
  • Page 28: Instrucciones De Montaje

    INSTRUCCIONES DE MONTAJE Antes de montar el producto, dedique unos minutos a comprobar el contenido y familiarícese con todas las piezas. ADVERTENCIA: COLOQUE ESTE PRODUCTO APARTADO DE LA PISCINA A FIN DE EVITAR QUE LOS NIÑOS SE SUBAN A ÉL Y ACCEDAN A LA PISCINA. 2.
  • Page 29 MANUAL DE USUARIO 5. Lubrique los anillos negros del accesorio de succión y la abertura de la bomba 6. Lubrique los anillos negros en el accesorio de retorno y en la salida de la con vaselina (no incluida). Conecte la manguera al accesorio de succión bomba con vaselina (no incluida).
  • Page 30: Funcionamiento De La Bomba De Filtración, Protección Del Motor Y Limpieza Y Sustitución Del Cartucho Filtrante

    Le recomendamos que tenga siempre a mano al menos un cartucho filtrante de repuesto. Puede comprar los cartuchos *No conectar a un temporizador filtrantes en la tienda donde compró la piscina o pedirlos a Polygroup ® 6. Para apagar la bomba de filtración, desenchufe el cable de alimentación con disyuntor diferencial PROTECCIÓN DEL MOTOR DE LA BOMBA...
  • Page 31: Mantenimiento De La Piscina Y Tratamiento Del Agua

    Además, un cartucho limpio y con un buen mantenimiento le asegura que el filtro siempre estará listo para funcionar con la máxima eficacia. 9. Puede comprar los cartuchos filtrantes en la tienda donde compró la piscina o pedirlos a Polygroup . Sustitúyalos siempre por auténticos cartuchos filtrantes ®...
  • Page 32: Guía De Resolución De Problemas, Desmontaje Y Almacenamiento De La Bomba

    GUÍA DE RESOLUCIÓN DE PROBLEMAS ADVERTENCIA: DESENCHUFE EL CABLE DE ALIMENTACIÓN ANTES DE SOLUCIONAR CUALQUIER PROBLEMA EN LA BOMBA DE FILTRACIÓN. SÍNTOMA CAUSA SOLUCIÓN A La unidad no está enchufada A La unidad debe estar enchufada a una tomacorriente conectada a tierra. Pulse el botón de o el disyuntor diferencial no reinicio (reset) situado en el disyuntor diferencial para arrancar la bomba.
  • Page 33: Instrucciones Sustitución Del Rotor

    MANUAL DE USUARIO INSTRUCCIONES DE SUSTITUCIÓN DEL ROTOR 1. Primero apague y desenchufe el cable de la bomba. Remueva el Desviador de Retorno RF de el Accesorio de Retorno y después tape el Accesorio de Retorno con el tapón de cierre (para servicio) .
  • Page 34 6. Para sustituir el mecanismo del rotor , retire el conjunto de tornillos de la tapa de la voluta y la tapa de la voluta y saque el mecanismo del rotor del estator . Coloque un nuevo mecanismo de rotor en el estator 7.
  • Page 35: Información Sobre El Pedido De Piezas De Respuesto

    MANUAL DE USUARIO INFORMACIÓN SOBRE EL PEDIDO DE PIEZAS DE REPUESTO RP-350 RP-400 CLAVE DESCRIPCIÓN N.º DE PIEZA Empaque de Retorno P58PF1520K01 P58PF1520K01 Accesorio de succión P58281283W05 P58281283W05 P58PF1510K01 P58PF1510K01 Arandela/Junta del accesorio de succión (arandela SF) Contratuerca del accesorio P58PF1430W05 P58PF1430W05 Tapón del accesorio de succión (tapón SF)
  • Page 36: Información Sobre El Accesorio De Succión En Conformidad Con Asme

    MANUAL DE USUARIO INFORMACIÓN SOBRE EL ACCESORIO DE SUCCIÓN EN CONFORMIDAD CON ASME PSF-100AAND PSF-100B ORIFICIO DE SALIDA DE SUCCIÓN (PARA PISCINAS SOBRE SUELO) 1. Los orificios de salida de succión PSF-100A y PSF-100B tienen la certificación de la IAPMO de acuerdo con la norma ASME/ANSI A1 12.19.8b-2009 Accesorio de succión para piscinas, piscinas infantiles, spas y bañeras de hidromasaje.
