Cartridge filter pump for above-ground swimming pools
Hide thumbs Also See for SUMMER WAVES RX330:

Advertisement

Quick Links

SUMMER WAVES
CARTRIDGE FILTER PUMP
READ AND KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
For answers to common questions, setup videos and troubleshooting
tips, please visit support.polygroupstore.com or call Customer
Service: (844) 252-9983 Email: ctcwarranty@polygroup.com
DO NOT RETURN PRODUCT TO STORE
Should you encounter a problem with your Polygroup
be made directly to Polygroup
. For any setup and troubleshooting issues, please visit support.polygroupstore.com. Customer Service: (844) 252-9983.
®
You may be asked to return all or part of the product for inspection and/or repair. Do not return any product to Polygroup
Authorization number.
DISTRIBUTED BY: Polygroup
Should you encounter any problems, contact Customer Service at (844) 252-9983 from 8AM to 5PM MST, Monday-Friday.
FOR ABOVE-GROUND SWIMMING POOLS
RX330 Model
Product, please DO NOT return the product to the place of purchase. All warranty claims must
®
Trading Limited. Unit 606, 6th Floor, Fairmont House, No.8 Cotton Tree Drive, Central, Hong Kong.
®
Extended operating days and hours during peak season requirements.
OWNER'S MANUAL
®
To order parts and accessories,
please visit
www.polygroupstore.com
without a Return Merchandise
®
EN
©2021
©2021

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SUMMER WAVES RX330 and is the answer not in the manual?

Questions and answers

Summary of Contents for Polygroup SUMMER WAVES RX330

  • Page 1 . For any setup and troubleshooting issues, please visit support.polygroupstore.com. Customer Service: (844) 252-9983. ® You may be asked to return all or part of the product for inspection and/or repair. Do not return any product to Polygroup without a Return Merchandise ®...
  • Page 2: Limited Warranty

    God outside the control of Polygroup . Non-manufacturing defects, such ® as grasses that may grow through the ground cloth and/or pool liner are examples of which Polygroup cannot be held responsible for. ®...
  • Page 3 CUSTOMERS WHO PURCHASE POOLS MAY BE REQUIRED BY LOCAL OR STATE LAW TO INCUR ADDITIONAL EXPENSES WHEN INSTALLING A POOL, IN ORDER TO COMPLY WITH STATE OR LOCAL LAWS REGARDING FENCING AND OTHER SAFETY REQUIREMENTS. CUSTOMERS SHOULD CONTACT THEIR LOCAL BUILDING CODE ENFORCEMENT OFFICE FOR FURTHER DETAILS. POLYGROUP IS NOT RESPONSIBLE FOR ANY ADDITIONAL EXPENSES THAT YOU MAY INCUR.
  • Page 4 Turn on the pump for the recommended hours daily. If you are unsure of the time frames please refer to support.polygroupstore.com for the recommended Pump Operation Hours based on pool types and sizes. Clean and replace filter cartridge frequently. Replace only with a genuine Polygroup / Summer Waves Brand filter cartridge.
  • Page 5: Risk Of Electrocution

    OWNER′S MANUAL Risk of Electrocution • Keep all electrical lines, radios, speakers, and other electrical appliances away from the pool. • Do not place the pool near or under overhead electrical lines. First Aid • Keep a working phone and a list of emergency numbers near the pool. •...
  • Page 6: Installer Responsibilities

    Safety Education Programs and Materials Educational programs and materials (i.e., seminars, workshops, brochures, videos, instructional guides) are available from the APSP, other aquatic safety groups, and from private firms. As a means of communicating useful safety information to pool owners/operators, and users, industry members are permitted to provide such information to owners/operators and to request or require owners/operators to sign a statement that they have received, read, and will follow the guidelines.
  • Page 7: Preliminary Steps

    ) or its latest approved edition. ® ® • This Filter Pump is manufactured by Polygroup and ETL control number 4000608 and 4006317 – double insulated and grounded – 120VAC 60Hz. All units must ® have a minimum of 105VAC to start and run properly.
  • Page 8 RETURN FITTING SUCTION FITTING with GFCI without GFCI...
  • Page 9 OWNER′S MANUAL...
  • Page 10: Setup Instructions

    SETUP INSTRUCTIONS Before assembly, take a few minutes to identify and become familiar with all the parts. WARNING: CLIMBING HAZARD! PLEASE PREVENT CHILDREN FROM CLIMBING ON THE FILTER CANISTER TO GAIN ACCESS TO THE POOL. Suction & Return Fittings Installation 1.
  • Page 11 OWNER′S MANUAL 5. Connect the Suction Fitting to the Pump inlet with a Hose and 6. Connect the Return Fitting to the Pump outlet with another Hose and one Clamp on each end. one Clamp on each end. Before Using the Pump 8.
  • Page 12 USE OF PUMP 1. Locate a grounded receptacle at least 15 feet (4.5 m) away from the pool. GFCI Plug with Timer Function 2a. If your pump includes a Power cord set without GFCI , simply plug in the power cord set to the power outlet to turn on the Pump.
  • Page 13: Pump Maintenance

    (see POOL WATER CARE, below). 5. Dispose of any used filter media in accordance with applicable regulations/legislation. Filter Cartridges; they are available at where you purchased your pool or from polygroupstore.com. 6. Always use genuine Polygroup Summer Waves ®...
  • Page 14: Pool Water Care

    NEVER drop lumps or pellets of chemicals into the pool – this may present a hazard to the swimmers and/or damage your pool liner. • Clean your pool regularly with a garden-hose-powered vacuum from Polygroup or any pool supplies stores.
  • Page 15 OWNER′S MANUAL 4. Turn the Pump upside down, and remove the Canister Screws 5. Take out the Motor Assembly 6. Remove the Rubber Nozzle . Be careful not to lose it. STEP 2: Rotor Inspection/Replacement 1. To take out the Rotor Assembly , simply remove the Volute Cover Screws and pull it out from the Pump Body 2.
  • Page 16 3. Once the inspection or replacement is done, carefully insert the Rotor Assembly back into the Pump Body. The force of the magnet will pull the Rotor down in place. 4. Align the Volute Cover with the top Shaft End Cap, then tighten with the Volute Cover Screws. STEP 3: Pump Replacement/Reassembly 1.
  • Page 17: Troubleshooting Guide

    OWNER′S MANUAL TROUBLESHOOTING GUIDE Problem Cause Solution A. Plug the Power Cord Set to a 3-wire grounded power outlet. A. Not plugged in For Power Cord Set (with GFCI), press the RESET button to start the Pump. 1. Motor doesn’t start, B.
  • Page 19: Manuel De L'utilisateur

    (844) 252-9983 Courriel : ctcwarranty@polygroup.com www.polygroupstore.com NE RETOURNEZ PAS L’ARTICLE AU DÉTAILLANT Si vous rencontrez un problème avec votre produit Polygroup , nous vous prions de ne pas retourner le produit au lieu d’achat. Toute réclamation sous garantie doit être soumise directement à Polygroup .
  • Page 20: Table Of Contents

    La présente garantie ne couvre pas les déstockages, les produits défectueux vendus par une usine ou les produits revendus (c.-à-d. produits issus de vide grenier, enchères en ligne ou commerçants en ligne qui ne sont pas achetés directement à Polygroup ”).
  • Page 21: Avertissements

    LORS DE L’INSTALLATION D’UNE PISCINE POUR ÊTRE CONFORMES AUX LOIS NATIONALES ET LOCALES RELATIVES AU CLÔTURAGE ET À D’AUTRES EXIGENCES DE SÉCURITÉ. LES CLIENTS DOIVENT CONTACTER L’AGENCE LOCALE CHARGÉE DE L’APPLICATION DU CODE DE LA CONSTRUCTION POUR PLUS DE DÉTAILS. POLYGROUP NE PEUT ÊTRE TENU RESPONSABLE DES FRAIS SUPPLÉMENTAIRES QUE VOUS POURRIEZ ENGAGER.
  • Page 22 Lavez et remplacez fréquemment la cartouche filtrante. Remplacez-la exclusivement par une cartouche filtrante d'origine de la marque Polygroup Summer Waves .
  • Page 23 MANUEL DE L'UTILISATEUR Risque de Noyad • Gardez les enfants sans surveillance à l’écart de la piscine en installant une clôture ou d’autres barrières agréées tout autour de la piscine. Il est possible que les lois étatiques ou locales nécessitent une barrière ou d’autres barrières agréées. Vérifiez les lois et les codes nationaux ou locaux avant d’installer la piscine. •...
  • Page 24: Responsabilités De L'installateur

    Des programmes éducatifs de sécurité ainsi que des matériels Programmes éducatifs et du matériel (à savoir des séminaires, des colloques, des brochures, des vidéos, des guides éducatifs) sont disponibles auprès de APSP, d’autres groupes de sécurité aquatiques et des entreprises privées. En vue de communiquer des renseignements utiles sur la sécurité aux propriétaires/opérateurs et utilisateurs des piscines, les membres de l’industrie sont permis à...
  • Page 25: Étapes Préliminaires, Information Sur La Puissance De La Pompe De Filtre

    édition approuvée la plus récente. • Cette pompe de filtration est fabriquée sous les numéros de contrôle Polygroup et ETL 4000608 et 4006317 - à double isolation et avec mise à la terre - 120 VCA 60Hz. Toutes les unités doivent avoir un minimum de 105VAC pour démarrer et fonctionner correctement.
  • Page 26 RACCORD DE REFOULEMENT RACCORD D’ASPIRATION avec disjoncteur différentiel sans disjoncteur différentiel...
  • Page 27 MANUEL DE L'UTILISATEUR...
  • Page 28: Instructions D'assemblage

    INSTRUCTIONS D’ASSEMBLAGE Avant le montage, prenez quelques minutes afin d’identifier et vous familiariser avec toutes les pièces. AVERTISSEMENT : GRIMPAGE DANGEREUX ! VEUILLEZ EMPÊCHER LES ENFANTS DE GRIMPER SUR LE SYSTÈME DE FILTRATION POUR ALLER DANS LA PISCINE. Installation des raccords d’aspiration et de refoulement 1.
  • Page 29 MANUEL DE L'UTILISATEUR 5. connectez le raccord d'aspiration à l'entrée de la pompe avec un 6. Brancher le raccord de refoulement à la sortie de la pompe avec tuyau et un collier de serrage à chaque extrémité. un autre tuyau et une bride à chaque bout. Avant d’utiliser la pompe 8.
  • Page 30: Utilisation De La Pompe, Entretien Du Moteur De La Pompe

    UTILISATION DE LA POMPE 1. Installez un boîtier de mise à la terre à une distance qu'au moins 4,5 m (15 pieds) de la piscine. Fiche avec disjoncteur 2a. Si votre pompe est fournie avec un câble d'alimentation sans disjoncteur différentiel , il vous suffit de brancher le différentiel et fonction câble d'alimentation...
  • Page 31: Entretien De Pompe, Utilisation Et Entretien De La Cartouche Filtrante

    (voir TRAITEMENT DE L’EAU DE LA PISCINE ci-dessous). 5. Jeter tout support de filtrage usagé conformément aux règlements/lois applicables. 6. Toujours utiliser les cartouches filtrantes véritables Polygroup Summer Waves ; elles sont disponibles auprès du détaillant où vous avez acheté votre piscine...
  • Page 32: Entretien De L'eau De La Piscine

    NE JAMAIS laisser tomber des morceaux ou des pastilles de produits chimiques dans la piscine — faire ainsi peut présenter un danger pour les nageurs ou endommager la toile de votre piscine. • Nettoyez régulièrement votre piscine avec un aspirateur à tuyau d'arrosage de Polygroup ou provenant de tout autre magasin de fournitures de piscine.
  • Page 33: Instructions D'entretien De La Pompe - Inspection Du Rotor 15

    MANUEL DE L'UTILISATEUR 5. Retirez le bloc moteur 4. Retournez la pompe et retirez les vis du conteneur 6. Retirez l'ajutage en caoutchouc . Veillez à ne pas le perdre. ÉTAPE 2 : Inspection/remplacement du rotor 1. Retirez le bloc du rotor , Pour cela, retirez simplement les vis du couvercle en volute et tirez le rotor hors du boîtier de la pompe 2.
  • Page 34: Instructions D'entretien De La Pompe - Remplacement De La Pompe

    3. Une fois l’inspection ou le remplacement terminés, soigneusement réinsérer le bloc du rotor dans le corps de la pompe. La force de l’aimant tirera le rotor vers le bas et en place. 4. Aligner le couvercle en volute avec le bouchon supérieur de l'extrémité de l'arbre, puis serrez-le à l'aide de ses vis. ÉTAPE 3 : Remplacement/réassemblage de la pompe 1.
  • Page 35: Guide De Dépannage

    MANUEL DE L'UTILISATEUR GUIDE DE DÉPANNAGE Problème Cause Solution A. Branchez le câble d'alimentation à une prise secteur avec terre. Avec le câble A. N’est pas branché d'alimentation (avec GFCI), appuyez sur le bouton RESET pour démarrer la pompe. 1. Le moteur B.
