Automata Eva Technical Reference User Manual page 5

The robot will be in a sleep state when first connected to a power source. Wake
the robot by pushing the button once. When the system is awake and running,
the button indicator ring and the LEDs on the robot head will illuminate white.
When the robot is idle, press the power button once to shut the robot down. A
shutdown can be forced by pressing and holding the power button for several
seconds. This is not an emergency procedure. Refer to the safety manual for
information on e-stops and other protective features.
Communication
Connect to the robot for the first time via wifi or ethernet.
Wi-Fi
Eva will be available as its own wireless access point, identified with the format
eva-Name. Connect to this access point with the password on the sticker below,
open a browser and navigate to the URL eva.automata or 172.16.172.1.
Ethernet
To connect via ethernet, configure your host side interface to IP: 172.16.16.1,
Subnet Mask: 255.255.255.0. Open a browser and navigate to 172.16.16.2.
Once connected, it's possible to configure the robot to connect to another wifi
access point or an ethernet network with a static IP. If Eva detects it has lost its
connection, or has been configured with invalid settings, it will continue to at-
tempt to connect for three minutes, before rolling back to the default access
point and ethernet configuration.
First time setup
After navigating to Eva's IP address for the first time, a setup screen will be
displayed:
5
