SERVICE MANUAL
Ver. 1.0 2013.10
Note:
Be sure to keep your PC used for service and
checking of this unit always updated with the
latest version of your anti-virus software.
In case a virus affected unit was found during
service, contact your Service Headquarters.
Playback Specifications
Frequency response: 2 Hz - 80 kHz (–3 dB)
Dynamic range: 105 dB or higher
THD: 0.0015% or less
Network section
Wired LAN
1000BASE-T/100BASE-TX/10BASE-T
Wireless LAN
Compatible standards: IEEE 802.11 b/g/n
Frequency band/channel: 2.4 GHz band, channels 1-11 (models for the USA and Canada),
channels 1-13 (models for Europe)
HDD section
Capacity
1 TB (*)
*
Some portions of the capacity are used for data management. Therefore, the capacity a user can
use is less than 1 TB.
Supported playback format
DSD (DSF, DSDIFF), LPCM (WAV, AIFF), FLAC, ALAC, ATRAC Advanced Lossless, ATRAC, MP3,
AAC, WMA (2 channels)
Jack section
Output jacks
LINE OUT UNBALANCED
Output level: 2.0 Vrms (50 kilohms)
Impedance: 10 kilohms or higher
LINE OUT BALANCED
Output level: 2.0 Vrms (50 kilohms)
Impedance: 600 ohms or higher
EXT port
Type A USB, Hi-Speed USB, for connecting an external hard disk drive
IR REMOTE OUT jack
for connecting the monaural mini-plug cable (supplied) or IR blaster (supplied)
9-893-887-01
Sony Corporation
2013J33-1
©
2013.10
Published by Sony Techno Create Corporation
HAP-Z1ES

SPECIFICATIONS

General and others
Power requirements
Models for the USA and Canada: AC 120 V 60 Hz
Models for Europe: AC 230 V 50/60 Hz
Power consumption
On: 35 W
During standby mode (when [Network Standby] is set to [Off]): 0.3 W
During standby mode (when [Network Standby] is set to [On] and a wired LAN is used): 2.6 W
During standby mode (when [Network Standby] is set to [On] and a wireless LAN is used): 2.8
W
Dimensions (approx.) (w/h/d)
430 mm × 130 mm × 390 mm (17 in. × 5 1/8 in. × 15 3/8 in.) including projecting parts and
controls
Mass (approx.)
14.5 kg (32 lbs 0 oz)
Supplied accessories
Remote control (1)
R03 (size-AAA) batteries (2)
AC power cord (mains lead) (1)
LAN cable (1)
Audio cord (1)
IR blaster (1)
Monaural mini-plug cable (1)
Design and specifications are subject to change without notice.
US Model
Canadian Model
AEP Model
UK Model
HDD AUDIO PLAYER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HAP-Z1ES and is the answer not in the manual?

Questions and answers

Summary of Contents for Sony HAP-Z1ES

  • Page 1: Specifications

    Type A USB, Hi-Speed USB, for connecting an external hard disk drive IR REMOTE OUT jack for connecting the monaural mini-plug cable (supplied) or IR blaster (supplied) HDD AUDIO PLAYER 9-893-887-01 Sony Corporation 2013J33-1 © 2013.10 Published by Sony Techno Create Corporation...
  • Page 2 12 TONE ANALYSIS and its logo are trademarks of Sony Corporation. aged by heat. “DSEE” is a registered trademark of Sony Corporation. SensMe™ and the SensMe™ logo are trademarks or registered trademarks of Sony Mobile Communications AB. FLEXIBLE CIRCUIT BOARD REPAIRING Microsoft, Windows, Windows Vista and Windows Media are either trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries.
  • Page 3: Table Of Contents

    HAP-Z1ES TABLE OF CONTENTS SERVICING NOTES 5-15. Printed Wiring Board - IO Board - ......... 50 ..........5-16. Schematic Diagram - IO Board - ........51 5-17. Printed Wiring Board - FPGA DSP Board - ....52 DISASSEMBLY 5-18. Schematic Diagram - FPGA DSP Board (1/3) - ..... 53 2-1.
  • Page 4: Servicing Notes

    HAP-Z1ES SECTION 1 SERVICING NOTES UNLEADED SOLDER NOTE OF REPLACING THE HARD DISK DRIVE (Ref. Boards requiring use of unleaded solder are printed with the lead- No. HDD1) free mark (LF) indicating the solder contains no lead. When the hard disk drive (Ref. No. HDD1) is replaced, be sure (Caution: Some printed circuit boards may not come printed with to carry out the “Factory Reset”...
  • Page 5 HAP-Z1ES NOTE OF REPLACING THE COMPLETE MAIN BOARD When the complete MAIN board is replaced, the following set- The MAC address for the wireless LAN has been changed tings that is recorded on the MAIN board are cleared, and returned by this repair.
  • Page 6: Disassembly

    HAP-Z1ES SECTION 2 DISASSEMBLY • This set can be disassembled in the order shown below. 2-1. DISASSEMBLY FLOW 2-2. CASE TOP, FUSE (F901, F902, F1401, F1402) (Page 7) 2-3. CASE L BLOCK, CASE R BLOCK 2-7. WLAN/BT COMBO CARD (WBC1)
  • Page 7: Case Top, Fuse (F901, F902, F1401, F1402)

    HAP-Z1ES Note: Follow the disassembly procedure in the numerical order given. 2-2. CASE TOP, FUSE (F901, F902, F1401, F1402) 2 case top 1 two flat head screws (TP) 1 three flat head screws (TP) 3 fuse (F901) 6 fuse (F1402)
  • Page 8: Plate Bottom Outer

    HAP-Z1ES 2-4. PLATE BOTTOM OUTER 1 screw (BVTT4 4 twelve screws 3 twelve screws 2 foot assy (BVTP3 (BVTT4 4 four screws 1 screw (BVTP3 (BVTT4 2 foot assy 1 screw (BVTT4 4 screw (BVTP3 2 foot assy 5 plate bottom outer...
  • Page 9: Plate Bottom, Cable Tie

    HAP-Z1ES 2-5. PLATE BOTTOM, CABLE TIE 2 plate bottom Note: In reassembling, use new cable tie to fasten the clamp same as before. 3 Cut two cable ties. 1 Remove the plate bottom in the direction of an arrow. DCDC board...
  • Page 10: Front Panel Block

    HAP-Z1ES 2-6. FRONT PANEL BLOCK Note: When installing the flexible flat cable, KEY JOG board lead pin ensure the colored line. No slanting after insertion. flexible flat cable colored line 2 two screws (BVTP3 connector 4 two brackets (panel) SPIRITOSO-LCD board...
  • Page 11: Wlan/Bt Combo Card (Wbc1)

    HAP-Z1ES 2-7. WLAN/BT COMBO CARD (WBC1) Note: When the WLAN/BT COMBO card (Ref. No. WBC1) and coaxial (U.FL connector) cables (Ref. No. WR1, WR2) are replaced, refer to “CHECKING METHOD OF NETWORK CONNECTION” on page 5. Coaxial cables (U.FL connector) are upward.
  • Page 12: Key Jog Board

    HAP-Z1ES 2-9. KEY JOG BOARD 6 Remove the KEY JOG board 1 knob (jog) assy in the direction of an arrow. 2 accessory nut 7 conector (CN304) 8 KEY JOG board 4 four screws (BVTP3 5 lug wire 4 screw...
  • Page 13: Spiritoso-Ant-L Board

    HAP-Z1ES 2-11. SPIRITOSO-ANT-L BOARD – – coaxial cable (U.FL connector) (WR1) [black] Do not fold. 3 coaxial cable (U.FL connector) (WR1) [black] 1 two claws 4 SPIRITOSO-ANT-L board SPIRITOSO-ANT-L board 2 Remove the SPIRITOSO-ANT-L board in the direction of an arrow.
  • Page 14: Led Board

    HAP-Z1ES 2-13. LED BOARD 2 Remove the LED board in the direction of an arrow. 1 screw (BVTP3 3 connector 4 LED board (CN031) – Front panel block rear view – 2-14. LCD PANEL (LCD1) Note: Attach to fit the corner.
  • Page 15: Hdd Block

    HAP-Z1ES 2-15. HDD BLOCK 1 harness (S-002) Note 1: Check that the harness (S-002) is not twisted. 2 harness (S-004) 6 HDD block MAIN board DC fan 4 screw (BVTP3 4 screw (BVTP3 3 connector (CN51) 5 Remove the HDD base block in the direction of an arrow.
  • Page 16: Power Transformer (T1, T2)-1

    HAP-Z1ES 2-17. POWER TRANSFORMER (T1, T2)-1 Note: In reassembling, use new cable tie power transformer to fasten the clamp same as before. (T1) cable tie Keep a distance. 2 Cut the cable tie. 2 Cut the cable tie. 3 clamp filter...
  • Page 17: Power Transformer (T1, T2)-2

    HAP-Z1ES 2-18. POWER TRANSFORMER (T1, T2)-2 power transformer power transformer (T1) (T2) Twist the wire in the direction of an arrow. 5 two screws (BVTT4 3 conector 4 conector (CN902) (CN903) 6 power transformer (T2) 5 two screws 1 conector...
  • Page 18: Fpga Dsp Board

    HAP-Z1ES 2-19. FPGA DSP BOARD 4 flexible flat cable (24P) (FFC2) Note: When installing the flexible flat cable, (CN506) ensure the colored line. 5 four screws 1 cushion No slanting after insertion. 1 cushion (BVTP3 flexible flat cable colored line...
  • Page 19: Main Board Block

    HAP-Z1ES 2-20. MAIN BOARD BLOCK 6 screw 6 screw (BVTP3 (BVTP3 5 connector (CN1003) 6 screw 8 MAIN board block (BVTP3 1 harness (S-002) 7 Draw out two wires. (CN1001) 6 screw (BVTP3 4 connector 2 connector (CN701) 3 connector...
  • Page 20: Apower Board

    HAP-Z1ES 2-22. APOWER BOARD IO board Note: In reassembling, use new cable tie to fasten the clamp same as before. APOWER board lead pin lead pin 1 Cut the cable tie. DCDC board 3 connector (CN1502) lead pin lead pin...
  • Page 21: Dcdc Board

    HAP-Z1ES 2-23. DCDC BOARD IO board lead pin 3 connector (CN1402) 2 connector (CN1403) 1 Remove the wire from the lead pins. DCDC board 4 connector (CN1406) 5 connector (CN1409) 6 two screws 0 connector (BVTP3 (CN1408) DCDC board clamp...
  • Page 22: Io Board Block

    HAP-Z1ES 2-24. IO BOARD BLOCK IO board 2 four screws (BVTP3 4 IO board block 3 Remove the IO board block in the direction of an arrow. 1 Draw out the wire. 1 Draw out wires. 2-25. IO BOARD 6 connector...
  • Page 23: Stanby Board

    HAP-Z1ES 2-26. STANBY BOARD 2 screw 1 connector (BVTP3 (CN904) 2 screw 2 two screws (BVTP3 (BVTP3 4 STANBY board 3 Remove the STANBY board in the direction of an arrow. 2-27. AC INLET (2P) (AC1) 2 clamp filter (ferrite core)
  • Page 24: Audio Board

    HAP-Z1ES 2-28. AUDIO BOARD Thread the wire between the wire from CN157 and CN158. AUUBOUT board CN157 CN158 AUDIO board 1 connector (CN157) 2 connector AUDIO board (CN158) 4 three screws (BVTP3 4 three screws (BVTP3 6 Remove the 8 AUDIO board wire from the lead pins.
  • Page 25: Test Mode

    HAP-Z1ES SECTION 3 TEST MODE 1. Entering Method of The Service Diag Mode 4. Operation of The Service DIAG Mode 4-1. Version Info Procedure: It can display the version information. 1. Connect the power cord to an outlet. 2. After becoming the standby state, while holding down two...
  • Page 26 HAP-Z1ES 4-3. LED/KEY 4-3-3. KEY Check It can check the keys and knobs. Procedure: 1. Enter the service DIAG mode. Procedure: (Refer to “1. Entering Method of The Service DIAG Mode” on 1. Enter the “3. LED/KEY” mode. page 25) (Refer to “4-3.
  • Page 27 HAP-Z1ES 4-4. LCD/Others 4-4-2. LCD Back light Check It can check the liquid crystal display back light. Procedure: 1. Enter the service DIAG mode. Procedure: (Refer to “1. Entering Method of The Service DIAG Mode” on 1. Enter the “4. LCD/Others” mode.
  • Page 28 2. Serial 5307C10GT 3. Firmware Rev. AM001Y 4. Rotate the selector knob to select the “1. fan off (HAP-Z1ES only)” and press the [ENTER] key. 4. SMART Data Read(Need USB Memory) 5. The fan motor is stopped. 5. SMART Short Test (2min) 6.
  • Page 29 HAP-Z1ES 6. The SMART data is saved as a text fi le in the USB memory. 4-6. Audio (The fi le name is “hap_smart_data_xxxxx_yyyyy.log (xxxxx: hard disk drive model name, yyyyy: hard disk drive serial Procedure: number)) 1. Enter the service DIAG mode.
  • Page 30 HAP-Z1ES 4-7. WiFi 4-7-2. Ping/RSSI It can display the results indicating whether or not the gateway Procedure: responded to the PING and RSSI value. Note: This mode supports only DHCP. 1. Set the SSID and KEY of the connecting access point with “SONY_HAP_TEST”.
  • Page 31 HAP-Z1ES 4-8. Ether 4-8-2. Ping It can display the results indicating whether or not the gateway Procedure: responded to the PING. Note: This mode supports only DHCP. 1. Connect the main unit to the router with the network LAN cable.
  • Page 32 HAP-Z1ES 4-9. IR Learning 4-9-2. Learning Check It can check the learning function. Procedure: 1. Enter the service DIAG mode. Procedure: (Refer to “1. Entering Method of The Service DIAG Mode” on 1. Enter the “9. IR Learning” mode. page 25) (Refer to “4-9.
  • Page 33: Electrical Check

    HAP-Z1ES SECTION 4 ELECTRICAL CHECK HDD CHECK 7. When the result of test is OK, following screen is displayed on the liquid crystal display. It can check the result of hard disk drive test. 5-6.SMART Long Test 1. Operation of The SMART Long Test SMART Test is Succeded.
  • Page 34 HAP-Z1ES 3. Checking Method of The SMART Test Result Procedure: 1. After the SMART test is completed, press the [ENTER] key or [BACK] key to return to the “5. HDD” menu. 2. Rotate the selector knob to select the “4. SMART Data Read(Need USB Memory)”...
  • Page 35: Diagrams

    HAP-Z1ES SECTION 5 DIAGRAMS 5-1. BLOCK DIAGRAM - HDD/USB/LAN/FPGA/DSP Section - HDD1 FPGA AUDIO DSP HARD DISK DRIVE IC101 (1/3) IC001 (1/2) IC601 HR+0 B14 SATA_RXP PICE_TXP J2 GXB_RX0p IO/VREFB7N0 42 DAI_P19 IO/DIFFCLK_T11N/DQ0T 40 DAI_P13 HR–0 A14 SATA_RXM PICE_TXM J1 GXB_RX0n...
  • Page 36: Block Diagram - Audio Section

    HAP-Z1ES 5-2. BLOCK DIAGRAM - AUDIO Section - FPGA D/A CONVERTER IC001 (2/2) IC201 CN202 IO/RUP3 N13 DATA IOUTL+ 25 LOW-PASS LINE AMP IO/DIFFIO_R9N/DQ0R J13 IOUTR– 18 FILTER IC202 IC203 IO/DIFFIO_R13N/DQ0R L13 LRCK IOUTR+ 17 IOUTL– 26 IO/DIFFIO_R2N D12 IO/DIFFIO_R4P/DM0R E10...
  • Page 37: Block Diagram - Memory/Panel Section

    HAP-Z1ES 5-3. BLOCK DIAGRAM - MEMORY/PANEL Section - LCD1 LIQUID CRYSTAL SD-RAM SYSTEM CONTROLLER IC301 IC101 (2/3) DISPLAY IC7002 (2/3) REMOTE CONTROL DQL0 – DQL7 DRAM_D0 – DRAM_D7 65 SIRCS IN DISP_DAT0 – RECEIVER B0 – B7 DISP_DAT7 IC1002 DQU0 – DQU7 DRAM_D8 –...
  • Page 38: Block Diagram - Power Supply Section

    HAP-Z1ES 5-4. BLOCK DIAGRAM - POWER SUPPLY Section - USB_OTG_VBUS EIM_D22 EIM_D21 +3.3V +3.3V REGULATOR (FOR IC7007) IC7006 NANDF_CS0 D1003, 1004 USB_H1_VBUS VBUS WLAN/BT COMBO CARD SWITCH VBUS Q1001, 1002 ENET_TXD1 DC/DC 1.1V CONVERTER VCC 1.2V IC101 +2.5V VCC_2.5V REGULATOR IC102 VDD_3.3V,...
  • Page 39 HAP-Z1ES THIS NOTE IS COMMON FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS. • Circuit Boards Location (In addition to this, the necessary note is printed in each block.) STANBY board For Printed Wiring Boards. For Schematic Diagrams. Note: Note: • All capacitors are in μF unless otherwise noted. (p: pF) 50 APOWER board •...
  • Page 40: Printed Wiring Boards - Main Section

    HAP-Z1ES 5-5. PRINTED WIRING BOARDS - MAIN Section - • See page 39 for Circuit Boards Location. • : Uses unleaded solder. WBC1 WLAN/BT COMBO CARD U-COM (Page 50) (Page 58) >02P >07P MAIN BOARD BOARD BOARD SPIRITOSO-ANT-L BOARD SPIRITOSO-ANT-R BOARD...
  • Page 41: Schematic Diagram - Main Section (1/9)

    HAP-Z1ES 5-6. SCHEMATIC DIAGRAM - MAIN Section (1/9) - • See page 75 for IC Pin Function Description. MAIN BOARD (1/9) (2/10) (3/10) (1/10) IC101 IC101 IC101 (Chip Size Package) (Chip Size Package) IC101 IC101 C190 MCIMX6D5EYM10AC MCIMX6D5EYM10AC (Chip Size Package)
  • Page 42: Schematic Diagram - Main Section (2/9)

    HAP-Z1ES 5-7. SCHEMATIC DIAGRAM - MAIN Section (2/9) - • See page 70 for Waveforms. • See page 70 for IC Block Diagrams. MAIN BOARD (2/9) IC204 +3.3V REGULATOR IC204 MM3464A33NRE FL201 R261 VOUT >105S 3.3V GND1 GND2 MAIN USB_5V...
  • Page 43: Schematic Diagram - Main Section (3/9)

    HAP-Z1ES 5-8. SCHEMATIC DIAGRAM - MAIN Section (3/9) - • See page 75 for IC Pin Function Description. MAIN BOARD (3/9) IC101 (4/10) (Chip Size Package) IC101 MCIMX6D5EYM10AC CL301 D0DQ0 AC14 D0A0 DRAM_D0 DRAM_A0 D0DQ1 CL302 AB14 D0A1 DRAM_D1 DRAM_A1...
  • Page 44: Schematic Diagram - Main Section (4/9)

    HAP-Z1ES 5-9. SCHEMATIC DIAGRAM - MAIN Section (4/9) - See page 70 for IC Block Diagrams. • See page 75 for IC Pin Function Description. (Page 54) MAIN BOARD (4/9) FPGA DSP FL401 >03S BOARD (2/3) CN401 CN402 FL400 GND2...
  • Page 45: Schematic Diagram - Main Section (5/9)

    HAP-Z1ES 5-10. SCHEMATIC DIAGRAM - MAIN Section (5/9) - • See page 75 for IC Pin Function Description. MAIN BOARD (5/9) CL511 R509 R501 R502 FL501 C513 >110S 3.3V C514 MAIN BOARD (2/9) CL518 (Page 42) (6/10) IC101 NC_M7 NC_H1...
  • Page 46: Schematic Diagram - Main Section (6/9)

    HAP-Z1ES 5-11. SCHEMATIC DIAGRAM - MAIN Section (6/9) - • See page 70 for Waveforms. • See page 75 for IC Pin Function Description. MAIN BOARD (6/9) IC101 (7/10) C622 R648 R649 R626 (Chip Size Package) IC101 R605 R601 MCIMX6D5EYM10AC...
  • Page 47: Schematic Diagram - Main Section (7/9)

    HAP-Z1ES 5-12. SCHEMATIC DIAGRAM - MAIN Section (7/9) - • See page 70 for Waveforms. • See page 75 for IC Pin Function Description. MAIN BOARD (7/9) >119S DISP0_PWR_EN IC701 Q704 MAIN SSM3J134TU,LSOYF BOARD DC/DC CONVERTER (6/9) IC701 TB62752AFUG(O,EL) (Page 46)
  • Page 48: Schematic Diagram - Main Section (8/9)

    HAP-Z1ES 5-13. SCHEMATIC DIAGRAM - MAIN Section (8/9) - • See page 75 for IC Pin Function Description. MAIN BOARD (8/9) >120S DISP0_RST R854 DIAG_EN MAIN BOARD IC101 (9/10) (7/9) (Page 47) (Chip Size Package) IC101 MCIMX6D5EYM10AC EIM_LBA CL805 EIM_BCLK...
  • Page 49: Schematic Diagram - Main Section (9/9)

    HAP-Z1ES 5-14. SCHEMATIC DIAGRAM - MAIN Section (9/9) - • See page 70 for IC Block Diagrams. • See page 75 for IC Pin Function Description. MAIN BOARD (9/9) IC101 (10/10) CN1001 (Chip Size Package) IC101 C1013 MCIMX6D5EYM10AC 0.01 L1001 >103S...
  • Page 50: Printed Wiring Board - Io Board

    HAP-Z1ES 5-15. PRINTED WIRING BOARD - IO Board - • See page 39 for Circuit Boards Location. • : Uses unleaded solder. (Page 40) (Page 40) MAIN MAIN >04P BOARD (NC) >07P IO BOARD BOARD (COMPONENT SIDE) CN601 CN1003 CN4007...
  • Page 51: Schematic Diagram - Io Board

    HAP-Z1ES 5-16. SCHEMATIC DIAGRAM - IO Board - IO BOARD R4034 ET4005 R4033 R4023 R4021 2.2k (CHASSIS) Q4002 PDTC114ET R4030 BUFFER J4015 ET4004 R4022 IR REMOTE R4029 R4019 (CHASSIS) 2.2k CN4006 Q4001 CL4015 >08S 2SA1037AK-T146-QR IR_OUT R4020 CL4017 BUFFER 2.2k...
  • Page 52: Printed Wiring Board - Fpga Dsp Board

    HAP-Z1ES 5-17. PRINTED WIRING BOARD - FPGA DSP Board - • See page 39 for Circuit Boards Location. • : Uses unleaded solder. (Page 56) AUDIO >09P BOARD FPGA DSP BOARD (SIDE A) CN103 FFC2 CL302 CL301 CL504 CL503 FB201...
  • Page 53: Schematic Diagram - Fpga Dsp Board (1/3)

    HAP-Z1ES 5-18. SCHEMATIC DIAGRAM - FPGA DSP Board (1/3) - • See page 70 for IC Block Diagrams. • See page 75 for IC Pin Function Description. FPGA DSP BOARD (1/3) IC001 (1/4) FPGA C102 C105 C107 C110 R107 C112 C114 0.01...
  • Page 54: Schematic Diagram - Fpga Dsp Board (2/3)

    HAP-Z1ES 5-19. SCHEMATIC DIAGRAM - FPGA DSP Board (2/3) - • See page 75 for IC Pin Function Description. (Page 44) MAIN >03S BOARD (4/9) FPGA DSP BOARD (2/3) CN402 CN401 CL423 (Page 53) MAIN_5V >131S PCIE_REFCLK_N PCIE_REFCLK_P FPGA DSP...
  • Page 55: Schematic Diagram - Fpga Dsp Board (3/3)

    HAP-Z1ES 5-20. SCHEMATIC DIAGRAM - FPGA DSP Board (3/3) - • See page 70 for Waveforms. • See page 75 for IC Pin Function Description. FPGA DSP BOARD (3/3) CN506 DACGND DATAR_DSDRD CL505 DATAR_DSDRD IC001 (4/4) DACGND CL506 DATAL_DSDLD R604 68...
  • Page 56: Printed Wiring Board - Audio Board

    HAP-Z1ES 5-21. PRINTED WIRING BOARD - AUDIO Board - • See page 39 for Circuit Boards Location. • : Uses unleaded solder. BALANCED LINE OUT (Page 66) (Page 60) DCDC AUUBOUT AUDIO BOARD >15P >13P (FRONT VIEW) BOARD BOARD (FRONT VIEW)
  • Page 57: Schematic Diagram - Audio Board

    HAP-Z1ES 5-22. SCHEMATIC DIAGRAM - AUDIO Board - • See page 70 for Waveforms. • See page 70 for IC Block Diagrams. AUDIO BOARD CN102 CL519 FB101 DAC 5V >12S C109 C108 CL518 DACGND APOWER CL190 CL517 BOARD D202 CLK3.3V...
  • Page 58: Printed Wiring Board - U-Com Board

    HAP-Z1ES 5-23. PRINTED WIRING BOARD - U-COM Board - • See page 39 for Circuit Boards Location. • : Uses unleaded solder. (Page 50) (Page 40) (Page 66) MAIN DCDC U-COM BOARD >08P >02P >18P BOARD BOARD BOARD CN4006 CN203...
  • Page 59: Schematic Diagram - U-Com Board

    HAP-Z1ES 5-24. SCHEMATIC DIAGRAM - U-COM Board - • See page 70 for Waveforms. • See page 70 for IC Block Diagrams. • See page 75 for IC Pin Function Description. U-COM BOARD STBY_EN R7036 R7110 CN7005 FAN_EN PWR_LED_G_CNT CN7004...
  • Page 60: Printed Wiring Boards - Auubout/Spiritoso-Lcd Boards

    HAP-Z1ES 5-25. PRINTED WIRING BOARDS - AUUBOUT/SPIRITOSO-LCD Boards - • See page 39 for Circuit Boards Location. • : Uses unleaded solder. SPIRITOSO-LCD BOARD (SIDE A) LCD1 LIQUID CRYSTAL DISPLAY CN002 R013 CL010 R014 CL007 CL006 CL009 AUUBOUT BOARD (COMPONENT SIDE)
  • Page 61: Schematic Diagram - Auubout/Spiritoso-Lcd Boards

    HAP-Z1ES 5-26. SCHEMATIC DIAGRAM - AUUBOUT/SPIRITOSO-LCD Boards - AUUBOUT BOARD SPIRITOSO-LCD BOARD J201 (Page 57) CN157 CN001 CN002 R013 >13S VELD– VELD– AUDIO LGND VLED+ VLED+ BOARD C001 R014 C235 CN154 270p 250V R[0] R[0] UNBALANCED R[1] R[1] LINE OUT...
  • Page 62: Printed Wiring Boards - Key/Led Section

    HAP-Z1ES 5-27. PRINTED WIRING BOARDS - KEY/LED Section - • See page 39 for Circuit Boards Location. • : Uses unleaded solder. 7 7 7 (Page 58) U-COM POWER KEY BOARD KEY JOG BOARD (COMPONENT SIDE) (COMPONENT SIDE) >17P BOARD...
  • Page 63: Schematic Diagram - Key/Led Section

    HAP-Z1ES 5-28. SCHEMATIC DIAGRAM - KEY/LED Section - POWER KEY BOARD KEY JOG BOARD CN1002 CL1032 JL1020 S301 S304 JL1019 (Page 59) LEARN_3.3V JL1018 BACK D1002 CN304 STBY_3.3V SELU5423E-STP15 JL1017 >19S CL326 CL327 CL325 CL334 CL335 CL333 JL301 SIRCS_IN JL1016...
  • Page 64: Printed Wiring Board - Apower Board

    HAP-Z1ES 5-29. PRINTED WIRING BOARD - APOWER Board - • See page 39 for Circuit Boards Location. • : Uses unleaded solder. APOWER BOARD (COMPONENT SIDE) R1507 Q1501 D1526 R1505 R1506 (11) 1-888-904- APOWER BOARD (CONDUCTOR SIDE) CL1513 CL1521 F1504...
  • Page 65: Schematic Diagram - Apower Board

    HAP-Z1ES 5-30. SCHEMATIC DIAGRAM - APOWER Board - APOWER BOARD D1520 DA2J10100L CN1504 CL1521 CL1517 DAC 5V IC1504 CL1513 F1504 T2.5A 250V AUDIO >12S BOARD +5V REGULATOR DACGND CL1518 CN102 IC1504 D1506 D1512 CLK 3.3V (Page 57) KIA7805API M1FS4-4063 M1FS4-4063...
  • Page 66: Printed Wiring Boards - Dcdc/Fan-Connect Boards

    HAP-Z1ES 5-31. PRINTED WIRING BOARDS - DCDC/FAN-CONNECT Boards - • See page 39 for Circuit Boards Location. • : Uses unleaded solder. DCDC BOARD (COMPONENT SIDE) CN1408 IC1402 C1412 >18P R1415 CN1403 U-COM C1410 R1407 R1414 BOARD CL1414 CN7002 CL1417...
  • Page 67: Schematic Diagram - Dcdc/Fan-Connect Boards

    HAP-Z1ES 5-32. SCHEMATIC DIAGRAM - DCDC/FAN-CONNECT Boards - • See page 70 for Waveforms. • See page 70 for IC Block Diagrams. DCDC BOARD CL1416 L1401 22uH IC1402 DC/DC CONVERTER R1411 IC1402 CN1403 RT7256ALZSP C1412 R1412 STBY FET ON/OFF R1407 100k >21S...
  • Page 68: Printed Wiring Board - Stanby Board

    HAP-Z1ES 5-33. PRINTED WIRING BOARD - STANBY Board - • See page 39 for Circuit Boards Location. • : Uses unleaded solder. STANBY BOARD STANBY BOARD (CONDUCTOR SIDE) (COMPONENT SIDE) D901 D904 D906 C903 D903 D905 D902 R914 ~AC IN...
  • Page 69: Schematic Diagram - Stanby Board

    HAP-Z1ES 5-34. SCHEMATIC DIAGRAM - STANBY Board - DIGITAL POWER STANBY BOARD TRANSFORMER CN902 >22S DCDC BOARD CN1401 (Page 67) CL905 NOT REPLACEABLE: BUILT IN TRANSFORMER Q905 SSM6J50TU(T5RSONYF ANALOG POWER TRANSFORMER Q903 - 905 B+ SWITCH R908 R909 CN903 470k...
  • Page 70 HAP-Z1ES • Waveforms • IC Block Diagrams – MAIN Board – – FPGA DSP Board – – AUDIO Board – – MAIN Board – IC201 BU33TD3WG-TR IC202 1 (BST) IC601 qd (XTAL) IC101 1 VOLTAGE – REFERENCE VOUT OVER CURRENT 3.7 Vp-p...
  • Page 71 HAP-Z1ES IC203 TPS54295PWPR VREG5 VREG5 CONTROL CONTROL VIN1 1 VIN2 LOGIC LOGIC VBST1 VBST2 XCON XCON CH1 MIN-OFF CH2 MIN-OFF TIMER TIMER PGND1 4 PGND2 OCP1 OCP2 PGND1 REF_OCL REF_OCL PGND2 EN1 5 EN LOGIC SOFT START PROTECTION LOGIC +20%...
  • Page 72 HAP-Z1ES – FPGA DSP Board – IC101 TPS54295PWPR VREG5 VREG5 CONTROL CONTROL VIN1 1 VIN2 LOGIC LOGIC VBST1 VBST2 XCON XCON CH1 MIN-OFF CH2 MIN-OFF TIMER TIMER PGND1 4 PGND2 OCP1 OCP2 PGND1 REF_OCL REF_OCL PGND2 EN1 5 EN LOGIC...
  • Page 73 HAP-Z1ES – AUDIO Board – IC102 74LVC161PW-118 IC106 BU33TD3WG-TR VOLTAGE – MR 1 REFERENCE CP 2 BINARY COUNTER VOUT OVER CURRENT PROTECTION THERMAL SHUTDOWN D0 3 PARALELL LOAD CIRCUITRY STANDBY STBY CEP 7 GND 8 IC201, 251 PCM1795DBR VCC2L ZEROL 1...
  • Page 74 HAP-Z1ES IC7005 TC74VHC4052AFT (EK) 0Y 1 2Y 2 Y-COM 3 X-COM 3Y 4 1Y 5 INH 6 GND 7 GND 8 IC7006 MM1839A33NRE CONT 1 BIAS CURRENT LIMIT – REGULATOR VOUT THERMAL VOLTAGE SHUTDOWN REFERENCE GND 2 NC 3 – DCDC Board –...
  • Page 75 HAP-Z1ES • IC Pin Function Description MAIN BOARD IC101 MCIMX6D5EYM10AC (MPU) Pin No. Pin Name Description PCIE_REXT Terminal for the Impedance calibration PCIE_TXM Transmit data (negative) output to the FPGA GND3 Ground terminal FA_ANA Not used USB_OTG_DP Two-way USB data (positive) with the USB connector...
  • Page 76 HAP-Z1ES Pin No. Pin Name Description RTC_XTALO Real time clock output terminal (32.768 kHz) GND24 Ground terminal POR_B Reset signal input from reset signal generator and system controller “L”: reset BOOT_MODE0 Boot mode setting terminal Fixed at “L” SD3_DAT5 Not used...
  • Page 77 HAP-Z1ES Pin No. Pin Name Description RGMII_TD2 RGMII transmit data output to the ethernet transceiver EIM_EB2 Boot mode setting terminal Fixed at “L” EIM_D22 VBUS power on/off control signal output terminal for the USB connector “H”: power on E24, E25...
  • Page 78 HAP-Z1ES Pin No. Pin Name Description GND40 Ground terminal VDDARM_CAP1 Internal regulator output terminal VDDARM_IN1 Power supply terminal for the cores regulator (+1.42V) GND41 Ground terminal VDDSOC_IN1 Power supply terminal for the SOC and PU regulators (+1.42V) VDDPU_CAP1 Internal regulator output terminal...
  • Page 79 HAP-Z1ES Pin No. Pin Name Description EIM_DA3 Boot mode setting terminal Fixed at “L” EIM_DA6 Boot mode setting terminal Fixed at “H” CSI0_DAT13 Serial data or program data input from the system controller GND58 Ground terminal CSI0_DAT17, L3, L4 Not used...
  • Page 80 HAP-Z1ES Pin No. Pin Name Description VDDARM23_CAP6 Internal regulator output terminal Not used VDD_CACHE_CAP Internal regulator output terminal (+1.1V) VDDARM_CAP6 Internal regulator output terminal VDDARM_IN6 Power supply terminal for the cores regulator (+1.42V) GND67 Ground terminal VDDSOC_IN6 Power supply terminal for the SOC and PU regulators (+1.42V)
  • Page 81 HAP-Z1ES Pin No. Pin Name Description GPIO_2, GPIO_9, T1 to T5 GPIO_6, GPIO_1, Not used GPIO_0 KEY_COL4 Not used KEY_ROW3 Liquid crystal display dimmer control signal output terminal GND84 Ground terminal VDDARM23_IN7 Power supply terminal for the cores regulator Not used VSSSOC_CAP2 Internal regulator output terminal (+1.1V)
  • Page 82 HAP-Z1ES Pin No. Pin Name Description DISP0_DAT22, V24, V25 RGB signal (red) output to the liquid crystal display DISP0_DAT18 LVDS0_TX3_P Not used LVDS0_TX3_N Not used GND93 Ground terminal KEY_ROW2 Not used KEY_COL0, W5, W6 Not used KEY_COL2 W7 to GND94 to GND100...
  • Page 83 HAP-Z1ES Pin No. Pin Name Description AA19 GND8 Ground terminal AA20, DRAM_D45, Not used AA21 DRAM_D57 AA22 GND9 Ground terminal AA23 DRAM_D61 Not used AA24 DRAM_SDQS7_B Not used AA25 DRAM_SDQS7 Not used LVDS1_TX2_N Not used LVDS1_TX2_P Not used GND12 Ground terminal...
  • Page 84 HAP-Z1ES Pin No. Pin Name Description GND19 Ground terminal DRAM_SDQS2 Data strobe signal (upper byte) output to the SD-RAM DRAM_D29 Two-way data bus with the SD-RAM AD10 GND13 Ground terminal AD11 DRAM_D30 Two-way data bus with the SD-RAM AD12 DRAM_A12...
  • Page 85 HAP-Z1ES MAIN BOARD IC602 AR8035-AL1A (ETHERNET TRANSCEIVER, +1.1V/+1.8V REGULATOR) Pin No. Pin Name Description RSTN Reset signal input from the MPU “L”: reset Internal regulator output terminal (+1.1V) VDD33 Power supply terminal (+3.3V) XTALO System clock output terminal (25 MHz)
  • Page 86 HAP-Z1ES FPGA DSP BOARD IC001 EP4CGX30BF14C8N (FPGA) Pin No. Pin Name Description Data output terminal for the JTAG Not used Mode selection signal input terminal for the JTAG Not used Data input terminal for the JTAG Not used DCLK Serial data transfer clock signal input from the MPU IO/DATA0 Confi...
  • Page 87 HAP-Z1ES Pin No. Pin Name Description GXB_RX1p Not used GXB_RX1n Not used GND_E3 Ground terminal VCCINT_E4 Power supply terminal (+1.2V) GND_E5 Ground terminal CLK10/DIFFCLK_4n/ Reset signal input from the MPU “L”: reset REFCLK1n CLK11/DIFFCLK_4p/ 50 MHz clock signal input terminal...
  • Page 88 HAP-Z1ES Pin No. Pin Name Description VCCA_GXB_J3 Power supply terminal (+2.5V) VCCD_PLL_J4 Power supply terminal (+1.2V) CONF_DONE CONF_DONE signal output to the MPU CLK12/DIFFCLK_7p/ Clock signal (positive) input from the MPU REFCLK0p CLK13/DIFFCLK_7n/ Clock signal (negative) input from the MPU...
  • Page 89 HAP-Z1ES Pin No. Pin Name Description VCCL_GXB_N1 Power supply terminal (+1.2V) NC_N2 Not used MSEL1 Fixed at “L” IO/DIFFIO_B1P/ Not used CRC_ERROR IO/DIFFIO_B1N/ Not used NCEO IO/DIFFIO_B3N/ Not used DQ0B CLK15/DIFFCLK_6N Not used IO/DIFFIO_B12P/ Not used DQ0B IO/DIFFIO_B12N/ Not used...
  • Page 90 HAP-Z1ES FPGA DSP BOARD IC601 ADSP-21488KSWZ-3A1 (AUDIO DSP) Pin No. Pin Name Description VDD_INT Power supply terminal (+1.1V) (for core) Core instruction rate to CLKIN (pin 12) ratio selection signal input terminal CLK_CFG1 Fixed at “H” in this unit BOOT_CFG0 Boot mode selection signal input terminal Fixed at “L”...
  • Page 91 HAP-Z1ES Pin No. Pin Name Description 78, 79 VDD_INT Power supply terminal (+1.1V) (for core) 80 to 82 FLAG1 to FLAG3 Interrupt request signal output terminal Not used MLBCLK Media local bus clock signal input terminal Not used MLBDAT Media local bus data input/output terminal...
  • Page 92 HAP-Z1ES U-COM BOARD IC7002 MB9AF156NPMC-G-JNE2 (SYSTEM CONTROLLER) Pin No. Pin Name Description Power supply terminal (+3.3V) 2 to 8 Not used AMUTE Audio muting on/off control signal output terminal “L”: muting on POWER_RY Relay drive signal (for main power) output terminal “H”: relay on...
  • Page 93 HAP-Z1ES Pin No. Pin Name Description 86, 87 TEST1, TEST2 Not used STBY_EN Power cut on/off control signal output terminal for the sub power “H”: sub power cut on FAN_EN Fan motor on/off control signal output terminal “H”: fan motor on...
  • Page 94 HAP-Z1ES U-COM BOARD IC7007 PD78F0527GB (S)-410-UET-A (REMOTE COMMANDER CODE LEARNING PROCESSOR) Pin No. Pin Name Description P140/PCL/INTP6 Not used P120/INTP0/EXLVI Not used 3, 4 P40, P41 Not used !RESET! Reset signal input from the MPU “L”: reset P124/XT2/EXCLKS Not used...
  • Page 95: Exploded Views

    HAP-Z1ES SECTION 6 EXPLODED VIEWS Note: • -XX and -X mean standardized parts, so • The mechanical parts with no reference The components identifi ed by mark 0 they may have some difference from the number in the exploded views are not sup- or dotted line with mark 0 are critical for original one.
  • Page 96: Plate Bottom Outer Section

    HAP-Z1ES 6-2. PLATE BOTTOM OUTER SECTION not supplied power transformer section not supplied LCD section not supplied not supplied front side not supplied not supplied rear side – Bottom view – Ref. No. Part No. Description Remark Ref. No. Part No.
  • Page 97: Lcd Section

    HAP-Z1ES 6-3. LCD SECTION • Rear view front panel section not supplied supplied with not supplied EN301 (SPIRITOSO-ANT-R board) EN301 not supplied WBC1 not supplied not supplied (SPIRITOSO-ANT-L board) LCD1 not supplied not supplied not supplied (FFC1) (POWER KEY board)
  • Page 98: Front Panel Section

    HAP-Z1ES 6-4. FRONT PANEL SECTION • Rear view not supplied not supplied not supplied not supplied Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 4-465-989-01 BUTTON (POWER-BASE) 4-466-005-01 WINDOW (LCD) 4-465-988-01 BUTTON (POWER) 3-906-887-11 SCREW (+BTP) (DIA. 3) (BZN-N)
  • Page 99: Power Transformer Section

    HAP-Z1ES 6-5. POWER TRANSFORMER SECTION not supplied not supplied HDD section MAIN board section FFC2 not supplied not supplied Note: Wire (flat type) (24 core) (Ref. No. FFC2) for service is all straight. When installing it, please bending it by referring to the figure below.
  • Page 100: Hdd Section

    HAP-Z1ES 6-6. HDD SECTION not supplied not supplied (FAN-CONNECT board) HDD1 not supplied Note: When the hard disk drive (Ref. No. HDD1) is replaced, refer to “NOTE OF REPLACING THE HARD DISK DRIVE (Ref. No. HDD1)” on page 4. Ref. No.
  • Page 101: Main Board Section

    HAP-Z1ES 6-7. MAIN BOARD SECTION not supplied not supplied not supplied not supplied not supplied F1402 F1401 not supplied not supplied not supplied not supplied AUDIO board section Note: When the complete MAIN board is replaced, refer to “NOTE OF REPLACING THE COMPLETE MAIN BOARD”...
  • Page 102: Audio Board Section

    HAP-Z1ES 6-8. AUDIO BOARD SECTION not supplied not supplied not supplied not supplied not supplied not supplied not supplied not supplied chassis board section Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark A-1945-108-A STANBY BOARD, COMPLETE (AEP, UK) 3-087-053-01 +BVTP2.6 (3CR)
  • Page 103: Chassis Section

    HAP-Z1ES 6-9. CHASSIS SECTION not supplied not supplied not supplied not supplied not supplied not supplied not supplied not supplied not supplied not supplied not supplied not supplied not supplied Ref. No. Part No. Description Remark Ref. No. Part No.
  • Page 104: Electrical Parts List

    HAP-Z1ES SECTION 7 APOWER AUDIO ELECTRICAL PARTS LIST Note: • Due to standardization, replacements in • CAPACITORS When indicating parts by reference num- uF: μF the parts list may be different from the ber, please include the board name. parts specifi ed in the diagrams or the com- •...
  • Page 105 HAP-Z1ES AUDIO Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark C202 1-118-386-11 CERAMIC CHIP 0.1uF C288 1-127-961-21 FILM CHIP 220PF C203 1-127-956-21 FILM CHIP 0.1uF C204 1-112-090-11 ELECT 100uF < CONNECTOR > C205 1-112-100-11 ELECT 10uF...
  • Page 106 HAP-Z1ES AUDIO AUUBOUT DCDC Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R106 1-250-664-11 METAL CHIP 100K 1/10W R269 1-257-419-21 CARBON 1/2W R107 1-250-664-11 METAL CHIP 100K 1/10W R270 1-257-470-21 CARBON 220K 1/2W * R108 1-250-576-11...
  • Page 107 HAP-Z1ES DCDC FAN-CONNECT FPGA DSP Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark C1417 1-100-158-91 CERAMIC CHIP 1000PF 100V < RESISTOR > C1418 1-100-158-91 CERAMIC CHIP 1000PF 100V R1401 1-218-879-11 METAL CHIP 0.5% 1/10W C1419 1-118-435-11...
  • Page 108 HAP-Z1ES FPGA DSP Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark C117 1-118-386-11 CERAMIC CHIP 0.1uF C257 1-118-386-11 CERAMIC CHIP 0.1uF C118 1-118-386-11 CERAMIC CHIP 0.1uF C258 1-118-386-11 CERAMIC CHIP 0.1uF * C119 1-116-720-11 CERAMIC CHIP 10uF 6.3V...
  • Page 109 HAP-Z1ES FPGA DSP Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark FB201 1-469-094-21 FERRITE, EMI (SMD) (1608) R405 1-218-965-11 METAL CHIP 1/16W FB501 1-400-822-21 BEAD, FERRITE (1005) R409 1-218-929-11 METAL CHIP 1/16W FB502 1-400-822-21 BEAD, FERRITE (1005)
  • Page 110 HAP-Z1ES FPGA DSP KEY JOG Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R610 1-218-990-81 SHORT CHIP < RESISTOR > R611 1-218-935-11 METAL CHIP 1/16W R612 1-218-990-81 SHORT CHIP R4001 1-216-295-91 SHORT CHIP R613 1-218-935-11 METAL CHIP...
  • Page 111 HAP-Z1ES MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark LED BOARD C156 1-116-745-11 CERAMIC CHIP 0.22uF 6.3V ********* C157 1-116-745-11 CERAMIC CHIP 0.22uF 6.3V < CONNECTOR > C159 1-116-745-11 CERAMIC CHIP 0.22uF 6.3V C174 1-118-459-11 CERAMIC CHIP 0.01uF...
  • Page 112 HAP-Z1ES MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark C314 1-118-386-11 CERAMIC CHIP 0.1uF * C611 1-116-738-11 CERAMIC CHIP 1uF 6.3V C315 1-118-386-11 CERAMIC CHIP 0.1uF C612 1-118-386-11 CERAMIC CHIP 0.1uF C613 1-118-386-11 CERAMIC CHIP 0.1uF...
  • Page 113 HAP-Z1ES MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark < LUG TERMINAL > Q1001 6-552-621-01 SSM3K37MFV, L3SOF Q1002 6-552-029-01 MCH3377-S-TL-E * ET001 1-780-408-11 TERMINAL, LUG * ET002 1-780-408-11 TERMINAL, LUG < RESISTOR/FERRITE BEAD > * ET003...
  • Page 114 HAP-Z1ES MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R426 1-218-961-11 METAL CHIP 4.7K 1/16W R654 1-218-990-81 SHORT CHIP R429 1-250-471-11 METAL CHIP 1/16W R655 1-218-965-11 METAL CHIP 1/16W R430 1-250-471-11 METAL CHIP 1/16W R657...
  • Page 115 HAP-Z1ES MAIN POWER KEY SPIRITOSO-ANT-L SPIRITOSO-ANT-R SPIRITOSO-LCD Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R1023 1-218-990-81 SHORT CHIP < RESISTOR > R1024 1-218-990-81 SHORT CHIP R1026 1-218-965-11 METAL CHIP 1/16W R1001 1-216-837-11 METAL CHIP 1/10W...
  • Page 116 HAP-Z1ES STANBY U-COM Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark A-1945-108-A STANBY BOARD, COMPLETE (AEP, UK) C7002 1-116-734-11 CERAMIC CHIP 1uF A-1945-109-A STANBY BOARD, COMPLETE (US, CND) C7003 1-118-417-11 CERAMIC CHIP 0.1uF *********************** C7004 1-118-417-11 CERAMIC CHIP 0.1uF...
  • Page 117 HAP-Z1ES U-COM Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark D7005 6-503-704-01 DIODE CUS521, H3SONYF R7054 1-218-941-81 METAL CHIP 1/16W D7006 6-503-704-01 DIODE CUS521, H3SONYF R7055 1-218-941-81 METAL CHIP 1/16W D7008 6-503-704-01 DIODE CUS521, H3SONYF R7056...
  • Page 118 HAP-Z1ES U-COM Ref. No. Part No. Description Remark < COMPOSITION CIRCUIT BLOCK > RB7001 1-234-373-21 RES, NETWORK 220 (1005X4) < VIBRATOR > X7001 1-781-646-21 VIBRATOR, CERAMIC (4 MHz) X7002 1-813-005-21 VIBRATOR, CERAMIC (5 MHz) ************************************************************ MISCELLANEOUS ************** 0 AC1 1-821-082-41...
  • Page 119 HAP-Z1ES MEMO...
  • Page 120 HAP-Z1ES REVISION HISTORY Ver. Date Description of Revision 2013.10 How to search for a contact point of signal lines or the like in DIAGRAMS SECTION If a contact point of a BLOCK DIAGRAM, PRINTED WIRING BOARD or SCHEMATIC DIAGRAM is shown in a different page, use the PDF fi...

Table of Contents
