Mocka Kitchen Assembly Instructions Manual page 9

Mocka Kitchen
Assembly Instructions
15
14
A
A
Attach panel [13] to panels [14] and [15] with 4x screws (A).
Tighten all screws with a screwdriver.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
16
15
13
A A
Slide panel [12] into the back of panels [9] and [11].
Attach panel [13] to panels [6], [8] and [11].
Attach panel [13] to panel [8] with 2x screws (A).
Attach panel [13] to panels [6] and [11] with 4x screws (B).
Tighten all screws with a screwdriver.
B
B
12
B
B
11
9 6
13
A
A
8
9
