Mocka Kitchen Assembly Instructions Manual page 10

Mocka Kitchen
Assembly Instructions
17
A
A
7
A
A
A
11
9
Slide panel [1] into panel [11] and attach with 1x screw (A).
Attach panel [7] to panels [1], [9] and [13] with 5x screws (A).
Tigthen all screws with a screwdriver.
Slide panel [5] onto shelf supports (K) on panels [7] and [11].
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
13
A
1
7
11
18
5
Attach 1x latch (H) to panel [2] with 2x screws (D).
Attach 1x hinge (E) to panel [2] with 2x screws (D).
Attach panel [24] to panel [10] with 2x screws (B).
Tighten all screws with a screwdriver.
D
B
B
2
D D
E
D
H
24
10
