Mocka Kitchen Assembly Instructions Manual page 11

Mocka Kitchen
Assembly Instructions
19
9
F
1
E
2 2
E
F
2
F
D
2
D
Place 1x hinge (F) into panel [9].
Insert hinge (E) into panel [1] and swing panel [2] down into hinge (F).
Attach hinge (F) to panel [2] with 2x screws (D).
Tighten all screws with a screwdriver.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
2
1
9
20
31
D D
D
D
D D
3
Attach panel [31] to panel [3] with 6x screws (D).
Attach 1x hinge (F) to panel [3] with 2x screws (D).
Attach 1x latch (H) to panel [3] with 2x screws (D).
Attach panel [24] to panel [3] with 2x screws (B).
Tighten all screws with a screwdriver.
D
D
F
D
D
H
B
B
3
24
11
