6.4

16 ZONE PANEL

Mains on (Battery voltage at 24 volts, control voltage at 28 volts)
Quiescent current:
Alarm current:
Max. zone current:
Min. zone current:
Mains off (Battery voltage 24 volts, control voltage at 23.1 volts)
Quiescent current:
Alarm current:
Max. zone current:
Min. zone current:
Mains off (Battery voltage at 18 volts, control voltage at 17.8 volts)
Quiescent current:
Alarm current:
Max. zone current:
Min. zone current:
6.5 32 ZONE PANEL
Mains on (Battery voltage at 24 volts, control voltage at 28 volts)
Quiescent current:
Alarm current:
Max. zone current:
Min. zone current:
Mains off (Battery voltage 24 volts, control voltage at 23.1 volts)
Quiescent current:
Alarm current:
Max. zone current:
Min. zone current:
Mains off (Battery voltage at 18 volts, control voltage at 17.8 volts)
Quiescent current:
Alarm current:
Max. zone current:
Min. zone current:
TM0066
200 mA
330 mA
45 mA
10 mA
179 mA
280 mA
40 mA
10 mA
140 mA
213 mA
30 mA
10 mA
400 mA
660 mA
45 mA
10 mA
358 mA
560 mA
40 mA
10 mA
280 mA
426 mA
30 mA
10 mA
Page 39 of 39 Issue 2.01
