1.4.2 Manual Devices

MANUFACTURER
KAC
KAC
FKI
NOTES 1.
2.
3.
4.
5.
TM0066
PART NO.
MCP/R/F
All break glass call points must have a 510 ohm resistor in series with
the normally open alarm contacts.
The quiescent current of a detection zone without an end-of-line
resistor fitted is 2.6mA.
The maximum line resistance of a detection zone is 50 ohms.
The end-of-line resistor value for detection zones is 3K9 ohms. ¼
watt.
The end of line resistor valve for alarm circuits is 2k2 Ohms ½ watt.
Page 14 of 39
KR9/510
KR72
DESCRIPTION
Call point complete with
resistor
Call point
Call point
Issue 2.01
