1.3.1 Panel Indications

Twin Fire LEDs (Red)
Supply Healthy LED (Green)
System Fault LED (Amber)
Disablement LED (Amber)
Test LED (Amber)
User LED # 1 (Amber)
User LED # 2 (Amber)
Zonal Alarm LEDs (1 Per Zone) (Red)
Zonal Fault LEDs (1 Per Zone) (Amber)
Processor Fault LED (Amber)

1.3.2 Panel Control Switches

Sounds Alarms
Silence Alarms
Systems Reset
Relay Isolate
Keypad - Digits 0 to 9
Cancel (Also clears the processor fault indication, 2 and 4 zone
panels only)
Enter
1.3.3 Internal Indications and Controls
Secured to the chassis is the motherboard which incorporates controls and indications for
engineering purposes.
1.3.3.1 Indications
LED1 - Power Supply Fault LED (Amber)
LED2 - Alarm Circuit Fault LED (Amber)
LED3 - Membrane Disconnection LED (Amber)
LED 4 - Earth Fault LED (Amber)
TM0066 Page 11 of 39 Issue 2.01
