1.2.1.3 Inner Mounting Chassis
The chassis is mounted on the back box by means of five M4 x 6 mm screws which are
accessible without removing the mother board. The chassis is served with a piano type hinge on
the right hand side which allows the membrane to be opened through 90 degrees and the
membrane is secured by means of three "Allen" type bolts located on the left hand side of the
membrane.
1.2.1.4 Battery Brackets
Battery space has been allocated at the bottom of the back box and this has been designed around
the Yuasa range of sealed lead acid cells. The batteries are clamped into position by means of
two brackets which are secured at each end of the brackets by two M4 x 6 mm screws.
1.2.2 Panel Specific Details
No of Ref No.
Zones
2 SR2000
2 SR2001
4 SR4000
4 SR4001
8 SR8000
16 SR1600
32 SR3200
Plain case enclosures are available in all sizes to accommodate additional equipment which can
be mounted on a purpose made, detachable mounting plate.
1.3

FUNCTIONAL DESCRIPTION

The membrane display is constructed of a smooth anti-static, polycarbonate material which
incorporates tactile switches and LED indications.
TM0066
Dimensions
276(h) x 306(w) x 100(d)
370(h) x 330(w) x 113(d)
276(h) x 306(w) x 100(d)
370(h) x 330(w) x 113(d)
370(h) x 330(w) x 113 (d)
450(h) x 440(w) x 138(d)
450(h) x 880(w) x 138(d)
Page 10 of 39
Knock Weight include
Outs batteries (kg)
10 9
14 11
10 9
14 11
14 16
22 20
44 40
Battery
size(Ah)
2 x 3.2
2 x 6
2 x 3.2
2 x 6
2 x 6
2 x 12
2 x 12
Issue 2.01
