Zone Panel - Kidde Fire Protection SIRIUS Manual

5.2

4 ZONE PANEL

TERMINALS
Note
Mains Block
Common Fault Relay
Common Fire Relay 1
Common Fire Relay 2
Auxillary Supply
Sounder Circuit 1
Sounder Circuit 2
Repeat Outputs
Remote Inputs
User LEDs 1 & 2
Zones 1 - 4
Battery
Fault Input
Evac. Output
Silence Output
Reset Output
NOTE: The remote inputs and outputs are for internal use only.
INTERNAL CONTROLS
SW1
Leaf 1 OFF
Leaf 1 ON
Leaf 2 ON
Leaf 3 ON
Leaf 4
TM0066
All terminals are capable of accepting conductors of cross
sectional area 1.0 - 2.5 mm.
Live, neutral and earth 240V a.c. + 10%/-15%, 50/60Hz.
Single pole changeover rated at 30V 1 Amp.
Single pole changeover rated at 30V 1 Amp.
Single pole changeover rated at 30V 1 Amp.
0V and 24V d.c. output terminals rated at 250 mA.
Reverse polarity monitored circuit rated at 500 mA.
Reverse polarity monitored circuit rated at 500 mA.
Common fault and zones 1 - 4 repeat rated at 100 mA.
Evacuate, silence and reset terminals which require a 0V to
activate them.
0V input required to activate the LEDs located on the
membrane.
+ & - per zone, each rated at 5 mA with a maximum of 20
detectors per zone.
+ & - input terminals which can receive a maximum of 500
mA from the charger.
0V input requires to drive common fault indication.
0V output to sound alarms mode.
0V output to silence alarms mode.
0V output in Reset mode.
4 Way DIL switch
Sounder circuits constant
Sounder circuits pulsed
Zone 1 non latching mode
Initiates the test mode
Function not allocated
Page 29 of 39 Issue 2.01
