TECHNICAL SPECIFICATIONS
5.1
2 ZONE PANEL
Note
Mains Block
Common Fault Relay
Common Fire Relay 1
Common Fire Relay 2
Auxiliary Supply
Sounder Circuit 1
Sounder Circuit 2
Repeat Outputs
Remote Inputs
User LEDs 1 & 2
Zones 1 & 2
Battery
Fault Input
Evac. Output
Silence Output
Reset Output
NOTE:
The remote inputs and outputs are for internal use only.
TM0066
CHAPTER 5
TERMINALS
All terminals are capable of accepting conductors of cross
sectional area 1.0 - 2.5 mm.
Live, neutral and earth 240V a.c. + 10%/-15%, 50/60Hz
Single pole changeover rated at 30V 1 Amp.
Single pole changeover rated at 30V 1 Amp.
Single pole changeover rated at 30V 1 Amp.
0V and 24V d.c. output terminals rated at 250 mA.
Reverse polarity monitored circuit rated at 500 mA.
Reverse polarity monitored circuit rated at 500 mA.
Common fault and zones 1 & 2 repeat rated at 100 mA.
Evacuate, silence and reset terminals which require a 0V to
activate them.
0V input required to activate the LEDs located on the
membrane.
+ & - per zone, each rated at 5 mA with a maximum of 20
detectors per zone.
+ & - input terminals which can receive a maximum of 500
mA from the charger.
0V input requires to drive common fault indication.
0V output to sound alarms mode.
0V output to silence alarms mode.
0V output in Reset mode.
