TC-32 User's Guide
Parameter
Chassis ground connection
Note 7: Voltage specification applies at barrel plug power input. The power supply provided with the device
meets this specification at the rated total power supply current. If a different power supply is used,
small line resistances could cause significant voltage drop between the power supply and the barrel
plug input.

USB

Parameter
Device type
Device compatibility
Connector
Cable length
Power

Network

Ethernet connection

Parameter
Ethernet type
Communication rates
Connector
Cable length
Additional parameters

Network interface

Parameter
Protocols used
Network ports used
Network IP configuration
Network name
Network name publication
www.MicroDAQ.com
Conditions
Table 11. USB specifications
Specification
USB 2.0 full speed
USB 1.1, USB 2.0, USB 3.0
Standard B
5 meters max
Self-powered (no USB current consumed)
Table 12. Ethernet connection specifications
Specification
100 Base-TX
10 Base-T
10/100 Mbps, auto-negotiated
RJ-45, 8 position
100 meters max
HP Auto-MDIX support
Table 13. Factory default specifications
Specification
TCP/IP (IPv4 only), UDP
UDP:54211 (discovery)
TCP:54211 (commands)
DHCP + link-local, DHCP, static, link-local
TC-32-xxxxxx, where xxxxxx are the lower 6 digits of the device MAC
address
By NBNS (responds to b-node broadcasts, therefore only available on the local
subnet)
22
(603) 746-5524
Specification
6-32 screw on rear of enclosure
