Weighing, Loading, and Towing
Do not exceed any applicable motorhome weight ratings. Doing so could damage
your motorhome or affect handling and braking characteristics.
Your motorhome's braking system is designed and rated for operation at the gross
vehicle weight rating (GVWR) listed on the unit's weight labels, not the gross
combined weight rating (GCWR).
Proper loading is one of the most important considerations when traveling in a motorhome.
Your motorhome is built to withstand a set maximum load (GVWR). Read and follow the
information listed on your motorhome's Federal Certification Label (located in the driver's area)
to determine safe load limits. For safety's sake, NEVER OVERLOAD YOUR MOTORHOME.

Federal Weight Label

THOR MOTOR COACH, INC.
MANUFACTURED BY:
GVWR: XXXX KG (XXXXX LB)
INC. VEH. MFG. BY: <Insert Chassis Manufacturer>
GAWR KG(LB) TIRES
FRONT: XXXX (XXXX) LT215/85R16
REAR: XXXX (XXXX)
LT215/85R16
TAG:
THIS VEHICLE CONFORMS TO ALL APPLICABLE U.S. FEDERAL MOTOR VEHICLE SAFETY
STANDARDS IN EFFECT IN MM/DD/YYYY
V.I.N.:XXXXXXXXXXXXXXXXX
Typical Federal Weight Label, including GVWR, GAWR, and tire pressure information
The TMC Motorhome Weight Specifications label concisely states the occupant and cargo
carrying capacity of your motorhome and meets the requirements of 49 CFR part 571.120 as
issued by the National Highway Traffic Safety Administration (NHTSA).
T H O R M O T O R C O A C H |
WARNING
SERIAL: XXXXXXXXXXXXXX
COLD INFLATION
RIMS
PRESSURE
5.5 J X 16 XXX KPA(XX PSI)
5.5 J X 16 XXX KPA(XX PSI)
TYPE: MULTIPURPOSE PASSENGER
VEHICLE
M A D E T O F I T
W E I G H I N G , L O A D I N G , A N D T O W I N G
MM/YY
OFFLINE:
MODEL: XXXX
SINGLE DUAL
