THOR Jayco NORTH POINT 2021 Owner's Manual

Fifth wheels
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
2021
FIFTH WHEELS
Owner's Manual
A subsidiary of Thor Industries, Inc.
0263154.2021

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Jayco NORTH POINT 2021 and is the answer not in the manual?

Questions and answers

Stephanie
January 22, 2025

I have a Jayco Northpoint 340 CKTS 2022. This is my first winter in it. I’m not sure what I’m supposed to do. It’s 18°tonight. Do I turn on the tank heaters? Do I let my water drip overnight?

0
1 comments:
Mr. Anderson
February 10, 2025

To winterize a 2021 Jayco North Point 340 CKTS when temperatures drop to 18°F:

1. Clear Water Lines: Attach a blowout plug to the water inlet on the utility center panel and connect an air hose. Set the air compressor to a maximum of 30 PSI and blow air into the utility center for 5–10 minutes to clear water from the lines.

2. Drain Water Heater: Turn off the air supply, remove the air hose and blowout plug, then close the low point drain. Replace the water heater drain plug if it’s a storage water heater. If it’s a tankless water heater, ensure the lines are purged of water.

3. Winterize Appliances: Refer to the owner’s manual for each appliance to ensure they are properly winterized, as methods may vary.

4. Protect Drain P-Traps: Pour one cup of RV antifreeze into all drain P-traps (sinks and bathtub).

5. Winterize Black Tank Flush:
- Connect a blowout plug to the Black Tank Flush inlet.
- Attach an air hose to the blowout plug and set the compressor to a maximum of 30 PSI.
- Ensure the black tank is emptied before proceeding.

These steps help prevent freezing damage to the RV's water system.

This answer is automatically generated

0

Subscribe to Our Youtube Channel

Related Manuals for THOR Jayco NORTH POINT 2021

Summary of Contents for THOR Jayco NORTH POINT 2021

  • Page 1 2021 FIFTH WHEELS Owner’s Manual A subsidiary of Thor Industries, Inc. 0263154.2021...

  • Page 3: Table Of Contents

    Table of Contents Section 1: Warranty & Service Factory Tours Options and Equipment Dealer Responsibility Customer Relations To Contact Us About This Manual Warranty Packet Safety Alerts Reporting Safety Defects Customer Responsibility Change Of Address/Ownership Suggestions For Obtaining Service Obtaining Service For Separately Warranted Items Obtaining Service At Our Customer Service Facility Parts and Accessories Section 2: Occupant Safety...
  • Page 4 Table of Contents Towing Behind Your RV Stowable Entrance Door Step (if so equipped) Entrance Door Rear Backup Camera Prep Campsite Hook-Up LCI 3.0 Leveling System (if so equipped) Auto Leveling Control Touch Pad Auto Leveling Touch Pad OneControl Touch Panel OneControl App (for your phone or tablet) OneControl Touch Panel Linc Remote...
  • Page 5 Table of Contents Section 5: Slideout Systems Electric Slide Room(s) (if so equipped) Slideout Overlap-Outside General Slideout Troubleshooting Checklist Flush Floor Slideout Schwintek In-Wall Slideout System Norco Slideout System Power Gear Slideout System Fig.1 Slideout Controller Power Gear Slim Rack Slideout System Power Gear Ram Slideout System Section 6: Electrical System The Electrical System...
  • Page 6 Table of Contents LP Gas Container Overfill Maintenance Propane Cylinder Recertification Hoses, Pipes, Tubes and Fittings Propane Regulator Propane Use and Safety Using the Propane System Propane System Label Cooking With Propane Gas Calculating Propane Gas Usage Traveling With Propane Installing Propane Cylinder(s) Single Cylinder Main Supply Hose...
  • Page 7 Table of Contents Faucets Bathroom Tub / Shower Black/Grey Water System and Tanks Black and Grey Tank Drains Black/Grey Tank Drain and Valves Macerator Pump System (if so equipped) Black Tank Flush (if so equipped) Tank Heaters (if so equipped) Toilet (if so equipped) Spray Port (if so equipped) Section 9: Heating &...
  • Page 8 Table of Contents Booth Dinette (if so equipped) Free-Standing Table and Chairs (if so equipped) Pantry or Hutch (if so equipped) Countertops Laminate Countertops (if so equipped) Solid Surface Countertops (if so equipped) Flooring Carpet Vinyl Flooring Bed Storage Prop Rod (if so equipped) Gas Struts (if so equipped) Loft Sleeping Area (if so equipped) Bunk Beds (if so equipped)
  • Page 9 WARNING: Read all instructions in this manual and component manufac- turer supplied information before using your RV. This manual has been provided by your recreational vehicle manufacturer for the sole pur- pose of providing instructions concerning the operation and maintenance of this recreational vehicle.

  • Page 11: Section 1: Warranty & Service

    Section 1: Warranty & Service Congratulations! Thank you for selecting a Jayco recreation vehicle. We are excited to welcome you to our growing RV family. We are committed to being the most respected name in RVs. We invite you to drop by our Visitors Center located in Middlebury, Indiana. Jayco recreation vehicles are manufactured for use as temporary living quarters for rec- reation, camping and travel uses, all as defined by the bylaws of the Recreation Vehicle Industry Association (RVIA).
  • Page 12 Section 1: Warranty & Service NOTE: Please provide the following information when contacting us for assistance: Customer name and current location. Phone number where you can be reached. 17-digit chassis Vehicle Identification Number (VIN) or 9-digit Serial. The current vehicle mileage (motorhomes). Your date of purchase.

  • Page 13: To Contact Us

    Section 1: Warranty & Service Obtaining weekend or after business hours repair assistance If an authorized Jayco dealer is not located nearby, contact your selling dealer for assistance. If your dealer is closed, check with the campground staff or telephone yellow pages for an RV repair facility.

  • Page 14: Warranty Packet

    Section 1: Warranty & Service Warranty Packet There are components that are excluded from the vehicle warranty, or are warranted sepa- rately by their own individual manufacturer’s limited warranty. The Warranty Packet con- tains these component manufacturer supplied manuals or information sheets, warranty cards and/or registrations.

  • Page 15: Reporting Safety Defects

    Section 1: Warranty & Service Indicates a potentially hazardous situation that, if not avoided, may result in death or serious injury. Reporting Safety Defects In the United States: If you believe that your recreation vehicle has an alleged defect which could cause a crash or cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA), in addition to notifying our Cus- tomer Service Department.

  • Page 16: Customer Responsibility

    Section 1: Warranty & Service Customer Responsibility It is important you read and understand all instructions and precautions before operating the recreation vehicle. Even if you are an experienced RV’er we encourage you to thoroughly read this Owner’s Manual, as well as the information contained in your Warranty Packet and Chassis Guide (motorized only).

  • Page 17: Obtaining Service For Separately Warranted Items

    Section 1: Warranty & Service Please be aware that all service shops require notification of any issues with their repairs within a specified time limit. Make sure you are familiar with their repair policies. Obtaining Service For Separately Warranted Items Your selling dealer is responsible for servicing your recreation vehicle before delivery, and has an interest in your continued satisfaction.
  • Page 18 Section 1: Warranty & Service JAYCO NORTH POINT, PINNACLE, SEISMIC, AND EAGLE LIMITED WARRANTY WHAT AND WHO IS COVERED This Limited Warranty covers only Jayco North Point, Pinnacle, Seismic, and Eagle brand recreational vehicles sold in, and that remain in, the United States, U.S. Territories and Canada and used for the intended purpose of recreational travel and camping.
  • Page 19 Section 1: Warranty & Service THIS EXCLUSION OF CONSEQUENTIAL AND INCIDENTAL DAMAGES SHALL BE INDEPENDENT OF ANY FAILURE OF THE ESSENTIAL PURPOSE OF ANY WAR- RANTY, AND THIS EXCLUSION SHALL SURVIVE ANY DETERMINATION THAT THIS LIMITED WARRANTY OR ANY IMPLIED WARRANTY HAS FAILED OF ITS ESSENTIAL PURPOSE.
  • Page 20 Section 1: Warranty & Service If you need assistance, you may contact Jayco, at 903 S. Main Street, P.O. Box 460, Middle- bury, Indiana 46540, Attn: Customer Service, (800) 283-8267. NOTE: Jayco does not control the scheduling of service work at the independent, authorized dealerships.
  • Page 21 Section 1: Warranty & Service recreational use or items that are working as designed but that you are unhappy with; exterior paint or finish; problems, including water leaks, related to misuse, mishandling, neglect or abuse, in- cluding failure to maintain the RV in accordance with the owner’s manual, or other routine maintenance such as inspections, lubricating, adjustments, tightening of screws and fittings, tightening of lug nuts, sealing, rotating tires;...
  • Page 22 Section 1: Warranty & Service accident, whether or not foreseeable, including any acts of weather or damage or corrosion due to the environment, theft, vandalism, fire, explosions, overloading in excess of weight ratings, and tampering with any portion of the RV, or any use of the RV as a semi-permanent or permanent home.
  • Page 23 Section 1: Warranty & Service LEGAL REMEDIES EXCLUSIVE JURISDICTION FOR DECIDING LEGAL DISPUTES RELATING TO AN ALLEGED BREACH OF WARRANTY OR OTHERWISE RELATING TO YOUR PUR- CHASE OR OWNERSHIP OF THE RV MUST BE FILED IN THE COURTS WITHIN THE STATE OF INDIANA. THIS LIMITED WARRANTY SHALL BE INTERPRETED AND CONSTRUED IN ACCORDNACE WITH THE LAWS OF THE STATE OF INDI- ANA.
  • Page 24 Section 1: Warranty & Service Notes:...

  • Page 25: Section 2: Occupant Safety

    Section 2: Occupant Safety Secondary Means of Escape (Exit Window) Your recreation vehicle has been equipped with a window(s) that serves as a secondary means of escape. The window(s) will allow a quick exit from the vehicle during an emer- gency if access to the main entrance door is not available.

  • Page 26: Fire Safety

    Section 2: Occupant Safety Lever style latch Remove the screen by pulling the red tab (upper rightarrow). Pull the lever out from the sash clamps. Swing the lever out so it is positioned straight out from the window. Push the lever (and window) out to open and exit the vehicle. Fire Safety If a fire does start, follow these basic safety rules: Call 911 and evacuate the vehicle immediately.

  • Page 27: Smoke Alarm

    Section 2: Occupant Safety Do not check the pressure, test or practice using the fire extinguisher by squeezing the trigger, even briefly. The fire extinguisher is not rechargeable or refillable. Once used, it will gradually lose pressure and will not be fully charged for use in an emergency.

  • Page 28: Combination Carbon Monoxide /Propane Alarm

    Section 2: Occupant Safety The LED light will indicate the battery is functioning properly. When the production of combustion is sensed, the smoke detector sounds a loud alarm that continues until the air is cleared. The LED light will also give a visual indication of a sounding alarm. When the battery becomes weak, the alarm will “beep”...
  • Page 29 Section 2: Occupant Safety Do not cover or obstruct the carbon monoxide/propane alarm with any- thing that could prevent gas from entering the alarm. This alarm is not designed to detect smoke, fire or gases other than car- bon monoxide and propane. The carbon monoxide detector installed is intended for use in ordinary indoor locations of recreation vehicles.
  • Page 30 Section 2: Occupant Safety fumes, adhesives, lacquer, kerosene, glues, wine, liquor, most cleaning agents and the pro- pellants of aerosol cans. High temperatures can activate glue and adhesive vapors. If you close up a recreational vehicle on a hot day, the chemicals used in its construction may be detected for months after the vehicle was constructed (for more information, refer to Sec.
  • Page 31 Section 2: Occupant Safety If problems are identified during this inspection, have the alarm serviced immediately. Note any combustion equipment not inspected by the technician and consult the manufacturer’s instructions or contact the manufacturer directly for more information about carbon monox- ide safety and this alarm.

  • Page 32: Formaldehyde

    Section 2: Occupant Safety Repair or replace the combination carbon monoxide/propane alarm when the alarm no lon- ger functions. As with any electronic product, it has a limited life. Alarms that do not work cannot protect you. NOTE: The carbon monoxide/propane alarm manufacturer strongly rec- ommends replacement of the detector five years after the date of purchase.

  • Page 33: Condensation

    Section 2: Occupant Safety Condensation Condensation may cause dampness, mildew, mold, staining and, if allowed to continue, it may result in damage to the recreation vehicle (damage caused by condensation is not warrantable). It can also lead to mold or mildew issues, which could be a health hazard.
  • Page 34 Section 2: Occupant Safety Notes:...

  • Page 35: Section 3: Pre-Travel Information

    Section 3: Pre-Travel Information Tow Vehicle If you plan to tow your recreation vehicle with a tow vehicle you already own, or if you plan to purchase a new one, make sure the Gross Vehicle Weight Rating (GVWR) or your recreation vehicle does not exceed your tow vehicles towing rating.

  • Page 36: Occc Label (Yellow)

    Section 3: Pre-Travel Information OCCC Label (Occupant and Cargo Carrying Capacity The upper portion of this yellow label is feder- ally required and includes the maximum Oc- cupant & Cargo Carrying Capacity that may be placed in or on the trailer as it was manufac- tured and weighed before leaving the factory.

  • Page 37: Loading Your Recreation Vehicle

    Section 3: Pre-Travel Information Loading Your Recreation Vehicle Never load the RV in excess of the GAWR for either axle. Overload- ing your RV may result in adverse handling characteristics and dam- age to the RV. DO NOT EXCEED YOUR GVWR! This means you should weigh your RV as loaded for your normal travel to determine the actual weight.

  • Page 38: Rear Bumper

    Section 3: Pre-Travel Information Rear Bumper Do not add items to the recreation vehicle rear bumper. Add-on items will eventually damage your bumper. Damage caused by such aftermarket equip- ment installation or improper loading voids the Towable Limited Warranty. The rear bumper of your RV is not designed to carry cargo. Items that extend beyond the bumper OR weigh over 100 lbs.

  • Page 39: Fifth Wheel Pin Box

    Section 3: Pre-Travel Information Fifth Wheel Pin Box The fifth wheel factory installed pin box is not interchangeable. Maintain the proper pin box weight on the hitch. Fifth Wheel Pin Box Height There is no recommended hitch height for fifth wheels; usually the fifth wheel pin box is adjustable for variance in trucks and truck suspension systems.

  • Page 40: Weighing Your Tow Vehicle And Rv

    Section 3: Pre-Travel Information White Ground Blue Electric Brakes Green Running Lights Black Auxiliary +12V battery charge line Stop & left turn Brown Stop & right turn Yellow Back up Lights The connector plug may build up corrosion with extended use. It should be cleaned peri- odically to insure good electrical contact.
  • Page 41 Section 3: Pre-Travel Information Weigh the RV including the tongue weight, while detached from the tow vehicle. This actual overall weight must be less than or equal to the GVWR for safe operation. If the overall weight is greater than the GVWR, some contents must be removed until the actual overall weight is less than or equal to GVWR.
  • Page 42 Section 3: Pre-Travel Information Notes:...

  • Page 43: Section 4: Vehicle Operation

    Section 4: Vehicle Operation Towing If your RV is equipped with the Command Control Bluetooth system, make sure you turn off your battery disconnect switch according to the following instructions. BEFORE TOWING YOUR RV ON THE ROADWAY: TURN OFF THE BATTERY DISCONNECT SWITCH! Certain components inside the RV can unexpectedly activate which could result in personal injury or property damage.

  • Page 44: Rv Brake System

    Section 4: Vehicle Operation When descending a long hill, drop down into a lower gear or range. Avoid conditions that require excessive and prolonged use of your brakes. Apply and release brakes at short inter- vals to allow them to cool. The tow vehicle transmission and engine will help in controlling downhill speed and can lengthen brake life.

  • Page 45: Brake Controller (Customer Supplied)

    Section 4: Vehicle Operation Brake Controller (customer supplied) The brake controller should be installed in the tow vehicle to work in conjunction with the RV electric brakes. Consult with your dealer or the brake controller OEM to decide what is right for your towing combination.

  • Page 46: Towing Behind Your Rv

    Section 4: Vehicle Operation Towing Behind Your RV If you do not have a Jayco factory installed hitch receiver, towing items behind your Jayco RV, or overloading the rear, will void the warranty and may result in: damage to the RV or add-on items, towing difficulties, property dam- age and/or personal injury.

  • Page 47: Entrance Door

    Section 4: Vehicle Operation NOTE: Certain models may have dual gas struts built into the step mechanism make the steps very easy to raise and lower in place. Step operation Open the entrance/screen door all the way. Twist the locking handle to release the steps from the locked position on the door frame (A).

  • Page 48: Rear Backup Camera Prep

    Section 4: Vehicle Operation NOTE: Locks on entrance and baggage doors need biannual lubrication using a light coat of silicone spray. Conditions such as rain, salt, dust and pollution may increase the maintenance needs. Rear Backup Camera Prep Your recreation vehicle has been pre-wired to allow for installation of a (customer supplied and customer installed) rear backup camera and a customer installed (or dealer installed) camera ON/OFF switch so the backup camera can be used as an observation/security cam- era.

  • Page 49: Lci 3.0 Leveling System (If So Equipped)

    Section 4: Vehicle Operation LCI 3.0 Leveling System (if so equipped) The LCI Ground Control 3.0 is an electric 4 or 6 point automatic leveling control. The system utilizes one main control board and a separate waterproof remote level sensor to measure and manage level point, and can be operated from several user interface devices including: Auto Leveling Control Touch Pad - Mounted outside the RV within view of the...

  • Page 50: Auto Leveling Touch Pad

    Section 4: Vehicle Operation NOTE: Pressing both the arrow buttons simultaneously turns on the touch- pad. Touchpad will time out after 7 minutes of non-use. Auto Level Touchpad LED Indicator status: OFF - Touch pad is locked Solid Green - Touch pad is active Blinking Green - Jacks are moving...

  • Page 51: Onecontrol Touch Panel

    Section 4: Vehicle Operation NOTE: Refer to the Lippert Ground Control 3.0 manual included in our warranty packet for complete instructions on the following procedures. OneControl Touch Panel Press the button at the bottom of the touch panel to power up the display. Select MyRV Control Panel from the menu list- ing on the screen.

  • Page 52: Onecontrol Touch Panel

    Section 4: Vehicle Operation The App will now display all functions. Choose Leveler. The following functions can be operated using the OneControl App. Refer to the Ground Control 3.0 manual for complete instructions. Standard Mode and Menu Basic Jack operation Unhitching Instructions Auto Leveling Linc Remote Control...

  • Page 53: Dexter Ez Flex Equalizer (If So Equipped)

    Section 4: Vehicle Operation Dexter EZ Flex Equalizer (if so equipped) Your recreation vehicle may be equipped with the Dexter EZ Flex Equalizer suspension. This includes heavy-duty shackles and wet bolts. Wet bolts have a grease zerk attached to the head of the bolt, and a hollow channel inside going to a single hole in the middle of the bolt.

  • Page 54: Emergency Stopping

    Section 4: Vehicle Operation Disconnect the battery from the system prior to manual operation. Operation: Insert the 1/2” diameter crank handle inside the coupler. The slot in the end of the crank handle accommodates the pin inside the coupler to allow manual extension/retrac- tion of the stabilizer jack.

  • Page 55: Emergency Towing

    Section 4: Vehicle Operation Emergency Towing Never allow anyone to go under the recreation vehicle while it is being lifted and/or being towed. If your recreational vehicle needs to be towed, please contact an emergency road service provider or a qualified service facility for assistance. Wheel Lugs After your first trip, check the wheel lug torque periodically for safety.

  • Page 56: Wheel Lug Nut Diagrams

    Section 4: Vehicle Operation Wheel Lug Nut Diagrams Because of the importance of having proper torque on the wheel lug nuts, you should always have the wheels mounted and properly torqued by a qualified technician using the proper tools. Wheel Lug Nut Torque Values Prior to travel and after excessive braking, wheel lug nuts should be checked for torque.

  • Page 57: Tires

    Section 4: Vehicle Operation Lug Nut Pattern and Warning Label The following labels showing the proper lug nut tightening pattern and a warning label are located on the driver side of the A frame hitch on travel trailers, and on the driver side of the pinbox on fifth wheel units.
  • Page 58 Section 4: Vehicle Operation Tire Pressure Failure to follow proper inflation guidelines may result in tire failure, which, under certain circumstances can cause loss of vehicle control or accidents that may result in property damage, bodily injury and/or death. You must follow the manufacturer’s inflation guidelines for maximum load capacity; under-inflation is just as dangerous as over-inflation.

  • Page 59: Changing A Tire

    Section 4: Vehicle Operation It is recommended that the tire pressure be checked at the beginning of each trip to obtain the maximum life of the tire. Follow the instructions listed on the Federal Certification label, to determine the correct tire pres- sure.

  • Page 60: Spare Tire Carrier (If So Equipped)

    Section 4: Vehicle Operation Tire Replacement Any service or warranty coverage on tires is to be handled by the tire manufacturer or the store representing the brand installed on your recreation vehicle. They are not to be returned to your dealer or recreation vehicle manufacturer. If you have questions regarding your tires, contact the tire manufacturer.

  • Page 61: Bumper Mount

    Section 4: Vehicle Operation Securing the spare tire To secure the spare tire in the travel position, put the steel hoist lift support located on the end of the cable through the rim of the tire. The hoist lift support clips need to seat inside the center hole of the tire rim.

  • Page 62: Setting Up Your Recreation Vehicle

    Section 4: Vehicle Operation Setting Up Your Recreation Vehicle Position the RV as desired. Level the RV (side-to-side). Leveling your recreation vehicle is important as the water drainage systems are designed with proper slope and must be level for proper opera- tion, and the appliances perform best when level.

  • Page 63: Cargo Ramp Transition Label

    Section 4: Vehicle Operation Push up on the bar latch handles that hold the ramp door in place, and move them to the outside of the trailer to avoid contact when opening the ramp door. Using caution, pull the ramp door open. Support the ramp door at all times and do not let it drop to the ground.

  • Page 64: Manual Ramp Door

    Section 4: Vehicle Operation LCI One Touch Screen® / One Touch® Smartphone app The automated ramp door can also be controlled with the LCI One Touch® system inside the RV or with the One Touch® app for your smartphone. Using the One Touch® app, your smartphone can be used as a remote control to operate the ramp door from outside the RV.

  • Page 65: Cargo Ramp Door Capacity

    Section 4: Vehicle Operation Cargo Ramp Door Capacity The cargo ramp has a maximum weight capacity of 2500 lbs. (1133Kg) (with load evenly distributed) and 1000 lbs. (453 Kg) per wheel contact in the vehicle-loading mode (cargo bay capacity may be different). Do not exceed this maximum weight rating at any time. The cargo ramp door is spring assisted to aid in opening and closing the ramp door.

  • Page 66: Weight Distribution

    Section 4: Vehicle Operation Any motorized vehicle or motorized equipment powered with flammable liq- uid can cause fire or explosion or asphyxiation if stored or transported within the recreational vehicle. To reduce the risk of fire, explosion or asphyxiation: Do not ride in the vehicle storage area while vehicles are present. Do not sleep in the vehicle storage area while vehicles are present.

  • Page 67: Awnings (If So Equipped)

    Section 4: Vehicle Operation To open the vent(s), firmly grasp the vertical bar in the middle of the vent, and push or pull it to the left or right until it clears the notch in the pivot base as shown below and the vent will open.

  • Page 68: Power Awnings (If So Equipped)

    Section 4: Vehicle Operation Electric Patio Awning With Remote Control NOTE: The electric awning requires connection to a 120-volt power source. Make sure you have sufficient power available before operating your awning (refer to Electrical Systems, Calculating electrical load). **Cer- tain awnings (Reatta, Reatta XL &...
  • Page 69 Section 4: Vehicle Operation Adjusting the Awning Pitch Do not set the individual arm pitch at more than three (3) positions differ- ent between the left and right arms. Damage to the arms and the canopy can occur if the awning is retracted when the arms are set at more than three (3) positions difference.

  • Page 70: Carefree® Travel'r Awnings (If So Equipped)

    Section 4: Vehicle Operation Periodically check that the fasteners are tight (tighten if necessary). Keep the awning fabric and arms clean. Refer to the manufacturer’s user guide for detailed operating and safety information. Emergency Operation If power to the vehicle is not available, the awning can be retracted by jumping the motor using a 10VDC –...
  • Page 71 Section 4: Vehicle Operation Emergency Operation If power to the vehicle is not available, the awning can be retracted by jumping the motor using a 10VDC – 14VDC power source such as a cordless drill battery or car battery. Locate and separate the quick disconnects located in the motor arm channel. Position the wires from the motor on the outside of the channel.
  • Page 72 Section 4: Vehicle Operation Notes:...

  • Page 73: Section 5: Slideout Systems

    Section 5: Slideout Systems Electric Slide Room(s) (if so equipped) The mechanical components of the slide out are gear driven. Electric powered slideout room systems have a manual override to allow you to extend or retract the slideout room(s) in case of a power loss.

  • Page 74: Slideout Overlap-Outside

    Section 5: Slideout Systems To retract the slideout, press the in section of the slideout control switch and hold it until the slideout is fully retracted. Operating the switch after the room is fully extended or retracted may damage the switch and motor.
  • Page 75 Section 5: Slideout Systems Electric Operation NOTE: Install transit bars (if so equipped) on the slideout room during storage and transportation. NOTE: For long-term storage it is recommend the room be closed (retracted). Extending/retracting the room Level the unit. Main Power switch at stepwell (locations may vary) must be ON. Verify the battery is fully charged and hooked up to the electrical system.

  • Page 76: Schwintek In-Wall Slideout System

    Section 5: Slideout Systems Schwintek In-Wall Slideout System The in-wall slideout system requires no maintenance or adjustments. This system has two vertical columns with a drive motor located at the top of each column. The right and left motors are synchronized by a circuit board.Schwintek slideouts are typically used on both towables and motorhomes.
  • Page 77 Section 5: Slideout Systems This slideout system requires very little maintenance. It contains a pre-lubed bearing that is lubricated when the room is moved in and out. Do not spray oil or grease on the rails while the room is extended. Trouble shooting the in-wall slideout system Checking Fuses: The in-wall slide requires a minimum 30-amp fuse.
  • Page 78 Section 5: Slideout Systems The red and green LED’s will flash indicating you are in override mode. Release the mode button. Using either a wall or command center panel switch, press and hold the switch toward the word IN or RETRACT until the unit comes in completely. This will allow you to get the recreation vehicle to a service center to have the slideout malfunction diagnosed.

  • Page 79: Norco Slideout System

    Section 5: Slideout Systems Bend back the wipe seal and visually locate the motor (Fig. 4). Pull the motor up until it disengages (about 1/2 inch). Repeat this process for both sides of the slide room. Physically push/ pull the room back into the opening; keep both sides relatively even. The room must be travel locked to keep the room in place for road travel.

  • Page 80: Power Gear Slideout System

    Section 5: Slideout Systems This drive can be activated using an electric drill and the flexible shaft provided with each unit (or use a ratchet to actuate the motor) to pull the room in or out. If the motor is func- tioning, check the room for obstructions.
  • Page 81 Section 5: Slideout Systems If the room does not move when the switch is pressed, check the following: Make sure the slideout system is turned on. Battery is fully charged and connected. Transit bars have been removed (if so equipped). When the motor brake is disengaged the slideout room WILL NOT lock into place and will not be sealed.

  • Page 82: Power Gear Slim Rack Slideout System

    Section 5: Slideout Systems The room is now free to move. Using either a 5/8” or 3/4” wrench or socket, crank the room either in or out completely. If the slideout system is supplied with a gearbox override (optional), use the crank handle to move the room. When the rooms is fully in or out have one person apply pressure to the wrench/ratchet and return the brake lever to its engaged position.
  • Page 83 Section 5: Slideout Systems Turn ON the on/off switch or key. Press and hold the OUT button (Fig 4). To retract, press and hold the IN button. There will be a slight delay before the room begins moving. The GREEN LED should be solid ON when room is in motion.
  • Page 84 Section 5: Slideout Systems -Check all connections at control box and motor. -Bad or loose connec- Excessive -Check the harness for bro- tion Major Battery Volt- ken wires. -Defective harness -Put 12.0 VDC direct to -Open or shorted motor the motor. If it does not run replace the motor.
  • Page 85 Section 5: Slideout Systems Emergency Retract Mode Use this procedure when there is NO loss of power or electrical problem with the system. Remove the touchpad (Fig 4) from the wall. Prior to clearing the MAJOR fault, record the number of RED &...
  • Page 86 Section 5: Slideout Systems Unplug the motor from the harness and remove the motor by lifting it up and out. Repeat steps 1-4 for the other side. Place a socket wrench with a 3-inch extension and a 5/8” deep well socket (Fig 12) through the motor access opening and seat the socket onto the coupler (Fig 13).

  • Page 87: Power Gear Ram Slideout System

    Section 5: Slideout Systems Power Gear Ram Slideout System Typically used for Class C motorhomes. Manual Override Procedure The system has been equipped with 3/4” hex override couplers located on the drive compo- nent of the system. Due to the size and weight of some rooms, assistance may be needed to push the room in.
  • Page 88 Section 5: Slideout Systems 12. Return the brake release lever back to the “engaged” position (parallel to the spring lock lever). Pressing the bent end of the spring lock lever will allow the brake le- ver to be moved. 13. Plug the motor connector back in again. 14.

  • Page 89: Section 6: Electrical System

    Section 6: Electrical System The Electrical System The RV electrical system is comprised of two independent electrical systems. One operates off of 12-volt DC power and the other off of 120-volt 60hz AC power. All installations have been made in compliance with industry standards applicable on the date of manufacture. Because the electrical equipment and associated circuitry are engineered into a dedicated system specific to your RV, do not make unauthorized changes or add fixed appliances to it.

  • Page 90: Command Center

    Section 6: Electrical System Command Center The command center is typically located inside the entrance door or in the living area of the RV, and contains switches and controls for various electrical functions. Command center applications, configurations and components will vary by model. Command Center Panel or Command Center Panel with Switch Modules Items found on these panels may include:...

  • Page 91: Gfci Receptacle

    Section 6: Electrical System GFCI Receptacle There is a ground fault current interrupter (GFCI) engineered into the electrical system. It is designed to reduce the possible injury caused by electric shock. The GFCI will not protect against short circuits or circuit overloads. Test all GFCI receptacles monthly: Push in the GFCI “TEST”...

  • Page 92: Bmpro Rvmaster System (If So Equipped)

    Section 6: Electrical System NOTE: Switches that are turned on with the LCI One Control App or the LCI One Control touchscreen, override switches at the command center panel on the wall. If you were to turn on a device with the app or the touch- screen and then the touchscreen or the app were to fail for some reason;...
  • Page 93 Section 6: Electrical System ○ Interior and Exterior Lights ○ RV Slide-out Rooms ○ Power Awnings ○ Generator ○ TV and Bed Lifts ○ HVAC thermostat ○ Gas and Electric water heaters ○ Fresh Water, Black water, Gray water tank levels ○...
  • Page 94 Section 6: Electrical System To replace the remote on the wall bracket: ○ Hook the top of the remote back on the top of the wall bracket. ○ Push the bottom of the remote back in place. You will again hear an audible snap as it attaches to the mount.
  • Page 95 Section 6: Electrical System Menu Display (between arrow buttons) use the arrow keys to scroll through the following selections: Menu Display shows A1 or A2 (awnings) Cycle between awnings with the arrows. ○ Press and hold EXT or RET to extend or retract the selected awning.
  • Page 96 Section 6: Electrical System Pairing a smart device to the RVMaster app Download and install the BMPro RVMaster app from Google Play Store or the Apple App Store. When you start the app it will tell you to press the Menu Display arrow keys until the small display shows PA.
  • Page 97 Section 6: Electrical System Rotating the tires: TPMS sensors – DO NOT MOVE WITH THE TIRES! • The TPMS sensor on the front tire (on either side of the trailer) STAYS at • the front tire position when rotating tires. The TPMS sensor on the middle tire (on either side of a 3 axle trailer) •...
  • Page 98 Section 6: Electrical System Installing tire sensors Tire sensors come already paired to the RVMaster system from the factory. Sensors come on a card (F) that shows where each sensor should be installed on the RV. The top of the card represents the “hitch” end of the RV. Top left sensor would install on the front driver side tire.

  • Page 99: Testing The Campsite Power Connection

    Section 6: Electrical System ○ When a motor is in operation, motor control is disabled on any other device run- ning the RVMaster app. Climate Screen Shows the thermostat to control heating and cooling in the RV, and fan speed Lights Screen Turn lights on and off along with ability to dim certain lighting with sliders.
  • Page 100 Section 6: Electrical System The shore power cord should be unplugged when the recreation vehicle is left unattended When you are ready to leave, reverse the power cord connection process. Use care to pre- vent damaging the power cord electrical connection pins when connecting or disconnecting the shore power cord.

  • Page 101: Inverter (If So Equipped)

    Section 6: Electrical System Inverter (if so equipped) A factory installed inverter converts 12-volts DC to useable 120-volts AC and supplies con- tinuous AC power to the appliance plugged into it. It is important that you familiarize your- self with the inverter function and operation. The inverter should be “off” when not in use. The factory-installed inverter is not intended for use with medical device(s).

  • Page 102: Power Converter

    Section 6: Electrical System NOTE: The power button is NOT a power disconnect switch and will not remove DC power from the inverter. Disconnect ALL power from the inverter before working on it. Pressing the SELECT button also cycles through inverter settings.

  • Page 103: Converter With Charge Wizard (If So Equipped)

    Section 6: Electrical System Before checking for converter output voltage, the battery cables must be disconnected at the battery. Make sure the converter is plugged into an AC source (105-132 AC volts). Check the converter output voltage at the battery with a voltmeter. Place the voltmeter probes on the disconnected battery cables.

  • Page 104: 12-Volt Dc System

    Section 6: Electrical System MANUAL MODE (Not recommended): The wizard mode button is used to override the charge wizard. Refer to the converter owner’s manual for additional information. REVERSE BATTERY PROTECTION: Reverse polarity fuse(s) provide protection for the converter when a battery is used. If the battery is connected backwards to the fuse board a fuse will blow preventing damage to the converter.

  • Page 105: Auxiliary Battery (Customer Supplied)

    Section 6: Electrical System Keep the protective dust cap on the 12-volt DC outlet when not in use to pre- vent ingestion of foreign material and potential short circuit conditions. Auxiliary Battery (customer supplied) Do not store anything inside the battery compartment(s) or near the batteries that could touch the battery or battery cable terminals.

  • Page 106: Battery Disconnect Switches

    Section 6: Electrical System this from occurring, disconnect the 7-way trailer plug or install a battery isolator. When the tow vehicle engine is operating with the RV connected, the tow vehicle charging system will charge both batteries. Replacement and Maintenance Some equipment in your RV will draw small amounts of current even when turned OFF.

  • Page 107: Load Center

    Section 6: Electrical System Load Center The Load Center contains 12VDC fuses and 120VAC circuit breakers for almost all of the electrical appliances and circuits in the RV. The 120V main breaker may be located in this panel and will turn off all 120-volt power to the RV. Locations will vary by model. Refer to the diagram inside the load center for specific fuse assignments.

  • Page 108: Approximate Electrical Load Ratings

    Section 6: Electrical System Replacement circuit breakers must be of the same voltage, amperage rating and type. Never use a higher rated replacement circuit breaker; doing so may cause a fire by overheating the RV wiring. Maintenance At the beginning of the camping season, inspect the circuit breakers and replace as needed. Test by turning each circuit breaker “off”...

  • Page 109: 120-Volt 50 Amp Ac Electric System (If So Equipped)

    Section 6: Electrical System 120 VOLT SYSTEM Air Conditioner 18 AMPS Coffee Maker 6-12 AMPS Converter (each) 8 AMPS DVD System 3 AMPS Fireplace 15 AMPS Hair Dryer or Curling Iron 10-14 AMPS Microwave 15 AMPS Refrigerator 6 AMPS Satellite Receiver 2 AMPS 2-4 AMPS Vacuum Cleaner...

  • Page 110: Generator

    Section 6: Electrical System 50 amp Power Cord Do not hook up the power cord to any receptacle until you have verified proper polarity and grounding. Polarity indicators can be purchased in most electrical and hardware stores. Do not use any cheater plug, adapter or extension cord to reconfigure incoming AC power or break the continuity of the circuit connected to the grounding pin.
  • Page 111 Section 6: Electrical System Before Starting the Generator Make sure the carbon monoxide detector is working. Turn “off” air conditioners and all other appliances. Check for fuel, exhaust and coolant leaks. STOP the generator immediately if there is a fuel, exhaust or coolant leak and have it repaired! CARBON MONOXIDE IS DEADLY! Do not run the generator when your RV is indoors or in a confined space.

  • Page 112: Solar Prep (If So Equipped)

    Section 6: Electrical System Maintenance With the exception of simple items such as normal maintenance (i.e., oil changes, etc.), all service work should be done by a repair facility authorized by the generator OEM. Improper adjustments can damage the generator and electrical appliances, and can result in a safety hazard.

  • Page 113: Section 7: Fuel & Propane System

    Section 7: Fuel & Propane System Exhaust Gas Fumes Avoid inhaling exhaust gases as they contain carbon monoxide, which is a potentially toxic gas that is colorless and odorless. If you are in a recreation vehicle with either a nearby tow vehicle engine running or the generator (if so equipped) running there is a potential for exhaust fumes to filter back into the recreation vehicle.

  • Page 114: Propane Gas Container

    Section 7: Fuel & Propane System Continued periodic checks of the propane system at 5,000 miles of travel (or at least once a year), by a qualified propane service representative as part of your normal maintenance is recommended. Hand tighten the LP gas system valves only, do not use a wrench or pliers as over tightening may damage the valve seals and cause them to leak.

  • Page 115: Servicing Or Filling

    Section 7: Fuel & Propane System DOT cylinders are typically marked with “top” or an arrow to indicate the correct orientation of the cylinder(s). Do not mount, store or transport any cylinder other than the in proper position indicated. Be sure to securely re-install DOT cylinder(s) after they have been removed for filling or replacement.

  • Page 116: Lp Gas Container Overfill

    Section 7: Fuel & Propane System This “shut off for re-fueling” label should be kept permanently affixed to your RV. The position of the propane container(s) and the hoses are criti- cal to proper operation and propane flow. Follow these instruc- tions to make sure your propane container(s) are connected properly.

  • Page 117: Propane Regulator

    Section 7: Fuel & Propane System Be sure to inspect the hose before each season and when having the tank refilled. Look for signs of deterioration such as cracks or loss of flexibility. When replacing the hose or other propane components, make sure to always replace them with components of the same type and rating (check with your dealer).

  • Page 118: Propane Use And Safety

    Section 7: Fuel & Propane System Propane Use and Safety Propane is a colorless and odorless gas that, in the liquefied state, resembles water. An odorant (usually a sulfur com- pound) is added as a warning agent. If you smell propane within the vehicle, quickly and carefully perform the proce- dure listed on the propane system label.

  • Page 119: Cooking With Propane Gas

    Section 7: Fuel & Propane System Cooking With Propane Gas Do not turn gas range burner controls to ON and allow gas to escape before lighting. Do not use portable fuel burning equipment (i.e., wood and charcoal grills or stoves) inside the recreation vehicle. Unlike homes, the amount of oxygen supply is limited due to the size of the recreation ve- hicle.

  • Page 120: Traveling With Propane

    Section 7: Fuel & Propane System Traveling With Propane NOTE: Some states prohibit propane appliances to be operated during travel, especially in underground tunnels. Know the laws for the areas where you travel. Use care when fueling your motor fuel tanks and/or propane containers.

  • Page 121: Main Supply Hose

    Section 7: Fuel & Propane System Attach the 1/4” inverted flare x 24” Type 1 pigtail hose to the regulator inlet and the right hand swivel nut to the cylinder valve. Secure the cylinder to the A-frame bracket using the bolts, nuts and washers provided. Double Cylinder Mounted On A-Frame (if so equipped) When a second cylinder is installed, a tee check valve is used to replace the 90°...
  • Page 122 Section 7: Fuel & Propane System Notes:...

  • Page 123: Section 8: Plumbing System

    Section 8: Plumbing System Plumbing System There are two different water systems in your recreation vehicle: The fresh water system consists of the fresh water holding tank, faucets and con- nections, water pump, outside shower assembly (if so equipped), water heater, tub/ shower, and water purification system (if so equipped).

  • Page 124: Command Center

    Section 8: Plumbing System Operation Press only one tact switch at a time. As you push either the FRESH, BLK GREY1 or GREY2 switch, one or more LED lights will illuminate (from left to right) indicating the content level for that tank. When pushing the “BATT” switch, the LED lights illuminate from left (lowest) to right (highest) to indicate the estimated auxiliary battery condi- tion.

  • Page 125: Fresh Water System

    Section 8: Plumbing System NOTE: This light will not appear on touchscreens, RV remote controls or on a WiFi app, it will only appear on the Command Center switch panel. Fresh Water System All water contains contaminant and mineral particles that can cause fresh water system odors.

  • Page 126: Water Purification System (If So Equipped)

    Section 8: Plumbing System 12-volt Water Pump and Switch There must be sufficient 12-volt DC power to run the water pump when your recreation vehicle is not hooked up to city water. Once activated, the water pump (also known as the demand pump) will self-prime, and provide water.

  • Page 127: Draining The Fresh Water System

    Section 8: Plumbing System Remove the O-ring from the groove in the housing and wipe clean. Coat with petro- leum jelly. Replace the O-ring in the groove, making sure it is properly seated. Install the new filter cartridge. Replace the canister housing (hand tighten is normally sufficient). 10.

  • Page 128: Uni-Dock Utility Center (If So Equipped)

    Section 8: Plumbing System Open the “low point drains” by turning, then pulling the handles up. They are installed at the lowest point of the water lines. A la- bel is placed on the outside of the RV to indicate where the drains are located.
  • Page 129 Section 8: Plumbing System There are 3 TV connections provided at the utility center: SAT input is wired only to the wall plate for the satellite receiver at the main TV loca- tion. (AUX/SAT input on faceplate). (can also be used with a tripod mounted satellite antenna) CABLE input is wired to the faceplate of the main TV also.
  • Page 130 Section 8: Plumbing System The following information details the functions of the utility center water valves as dis- played on the valve operation label: “POWER FILL TANK” (Pressurized fresh water source) Connect the fresh water hose to the City water connection inlet on the utility center. Set the color coded valves to POWER FILL TANK setting: (A) White handle pointing right (B) Blue handle pointing left...
  • Page 131 Section 8: Plumbing System Pump until solution is drawn out of the container, or tank is at the desired level. Turn the pump Switch OFF. Disconnect the garden hose from the city water fill inlet on the utility center. “DRY CAMPING” (pump supplies water from the fresh water tank) Make sure the fresh water tank has an adequate supply of water.

  • Page 132: Sanitizing The Plumbing System

    Section 8: Plumbing System Connect a garden hose to the city water inlet (do not use your fresh water hose to win- terize the water lines). Set the color coded valves to the WINTERIZE setting: (A) White handle pointing down (B) Blue handle pointing left (C) Black handle pointing right (D) Red handle pointing left...
  • Page 133 Section 8: Plumbing System Prepare one gallon of solution for every 15 gallons of tank capacity. This will result in a residual chlorine concentration of 50 ppm in the water system. If a 100-ppm concentration is required, use ½ cup of household bleach with one gallon of water to prepare the chlorine solution.
  • Page 134 Section 8: Plumbing System Rinse the system with fresh water Fill the fresh water tank full of clean (potable) water. Use water from either a pressur- ized source, or from a container (as detailed below). a). Filling from a pressurized source: Set the valves to the POWER FILL TANK setting.

  • Page 135: Winterizing The Plumbing System (With Utility Center)

    Section 8: Plumbing System fresh water tank (the water heater will be bypassed automatically). When the container is empty, turn pump OFF, and disconnect hose from utility panel. To aid in siphoning, place the container approxi- mately (2) feet off the ground. The drain valves must be closed.

  • Page 136: Tank Style (Storage) Water Heater

    Section 8: Plumbing System NOTE: The winterization process may vary slightly due to different plumb- ing configurations between models. NOTE: Appliances (refrigerator, dishwasher or clothes washer) must be winterized. Refer to the appliance owner's manual for possible additional information or contact your Dealer or Customer Service for assistance. If your RV is equipped with a residential style refrigerator, winterizing instruction sheet (0311859 Whirlpool) may be included in your Warranty Packet.
  • Page 137 Section 8: Plumbing System Before applying air pressure to the utility center, 4 colored valves (WHITE, RED, GREEN, BLUE) MUST be set to 45° or damage may occur to the utility center. Never apply air pressure to the water system with any of the valves in the closed position.

  • Page 138: Winterizing The Black Tank Flush

    Section 8: Plumbing System NOTE: Filters should be replaced at the beginning of the camping season or if they have come into contact with contaminated water or antifreeze. Turn the (color) valve handles to the POWERFILL position. Open the low point drain on the RV to remove water in the plumbing lines. Open all faucets in the RV.

  • Page 139: Winterize With Antifreeze Method

    Section 8: Plumbing System Release the nozzle and disconnect the hose from the port. Rinse out the hose before storing it. Winterize with Antifreeze Method Requires non-toxic RV antifreeze in the water lines and does not require any special tools. Use ONLY RV ANTIFREEZE in your fresh water system for freeze protection.

  • Page 140: Winterizing The Macerator System (If So Equipped)

    Section 8: Plumbing System When you are finished adding RV antifreeze: 12. Turn only the BLUE, GREEN, and WHITE valve handles so they are at a 45° angle for 10 seconds (Fig 3). The pump should still be ON. 13. Turn the water pump OFF with the switch on the utility center panel. 14.

  • Page 141: Water Heater

    Section 8: Plumbing System Water Heater Hydrogen gas may result if you have not used the water heater for two weeks or more. HYDROGEN GAS IS EXTREMELY FLAMMA- BLE. To reduce the risk of injury under these conditions, open the hot water faucet for several minutes at the kitchen sink before you use any electrical appliance connected to the hot water system.

  • Page 142: Anode Rod Replacement Chart

    Section 8: Plumbing System Turn the switch to the “ON” position. If the burner does not light, the system will automatically attempt two more tries for ignition before lock-out occurs. NOTE: Each ignition cycle will have a 15 second purge before spark cycle if the system is a three try system.
  • Page 143 Section 8: Plumbing System To prevent a water leak when replacing the anode rod, a pipe thread sealant approved for potable water (such as Teflon tape) must be applied to the threads of the anode rod. Proper application of a thread sealant will not interfere with the anode’s function. High altitude deration Operation of the water heater at high altitudes may require derating.
  • Page 144 Section 8: Plumbing System Maintenance Do not allow the burner to burn with a yellow flame, or continue to operate the water heater with an improper burner flame. Periodically, inspect the water heater vent for soot. Soot is a sign of incomplete combustion and must be corrected before operating the water heater.
  • Page 145 Section 8: Plumbing System Open hot water faucet to a medium water flow. It may take a few seconds for the water to travel from the water heater to the faucet. To reduce temperature: ○ Turn GMC dial “counter-clockwise”. ○ Increase hot water flow.

  • Page 146: Truma® Tankless Water Heater (If So Equipped)

    Section 8: Plumbing System TRUMA® Tankless Water Heater (if so equipped) Your recreation vehicle may be equipped a Truma® tankless water heater. The tankless water heater has no pilot light and supplies an unlimited supply of hot water on demand. It does not require an anode rod to prevent corrosion, and is not affected by high altitudes.

  • Page 147: Filling The Water Heater

    Section 8: Plumbing System Turn the locking knob, and open the exterior water heater panel to the first open position (photo A). To open the panel to the second (or service) position, the door must first be open as shown in (A). Then lift the door so it comes out of the slots along the bottom of the door (photo B).

  • Page 148: Aqua Go Comfort Plus Models

    Section 8: Plumbing System Pressure – Temperature Relief Valve SCALDING INJURY – EXPLOSION Valve is not serviceable; if defective it must be replaced. Tampering with the valve will result in scalding injury. Do not place a plug or reducing coupling on the outlet part of the valve. If you use a discharge line allow complete drainage for both valve and line.

  • Page 149: Draining The Aqua Go Water Heater

    Section 8: Plumbing System Draining the Aqua Go Water Heater The Aqua Go water heater does not have a conventional drain plug. Instead it includes a “drain chute”. Water heater power should be OFF, water pump OFF, and fixtures open to relieve pressure on the plumbing system.

  • Page 150: Winterization

    Section 8: Plumbing System □ When the drain chute is folded out, it protrudes past the sidewall of the RV. □ When walking past or stooping down, make sure you and others have sufficient clearance to prevent injuries. □ Never actuate the Easy Drain Lever as long as the appliance is under water pressure or is still hot.
  • Page 151 Section 8: Plumbing System Decalcification Procedure for Comfort and Comfort Plus Models Set the rotary dial inside the RV to OFF. Turn water pump OFF or turn the water supply OFF. NOTE: If you are using the electric antifreeze kit, it must be removed and unplugged from the power supply before decalcification.
  • Page 152 Section 8: Plumbing System IRRITATION TO SKIN AND EYES! The decalcification agent may cause irritation to skin and eyes. In case of contact with skin immediately rinse with plenty of water. In case of eye contact, hold eyelid open and rinse with running water for 10-15 minutes. Consult an eye specialist.

  • Page 153: Outside Shower (If So Equipped)

    Section 8: Plumbing System Before using the water system and the water heater, check the color of the water coming out of the faucets. If water is slightly red, rinse again. If water is clear, decalcification is finished. Turn OFF the water supply or turn OFF the water pump. Remove the warning signs placed earlier.

  • Page 154: Black/Grey Water System And Tanks

    Section 8: Plumbing System Unlike your home, the recreational vehicle does not contain a water pressure balance valve. If someone is using the shower, it is recommended that the fresh water system NOT BE USED until they are finished. The shower faucet includes a vacuum breaker for the shower. There are two purposes for this breaker: To prevent siphoning water through the hose from another fixture.
  • Page 155 Section 8: Plumbing System Vents Vent pipes and vents release air from the grey and black water holding tanks. On most models the exterior vent cap is attached to the roof and must be kept clear of obstructions to perform as intended. On some models, the vent pipe may be part of the drainage system referred to as a “wet vent”...

  • Page 156: Black And Grey Tank Drains

    Section 8: Plumbing System Black and Grey Tank Drains There are labels on the exterior of the recreation vehicle indicating the location of the grey and black tank drains (also called dump valves). Always drain the black water holding tank first so the grey tank wastewater can help rinse any solids or debris from the dump outlet and sewer hose.

  • Page 157: Macerator Pump System (If So Equipped)

    Section 8: Plumbing System Macerator Pump System (if so equipped) Your RV may be equipped with a macerator pump system used to discharge waste from the gray and black waste tank. The system has a 1-1/2 inch diameter flexible hose that runs from the pump (under the RV) and is stored in an exterior storage compartment.

  • Page 158: Black Tank Flush (If So Equipped)

    Section 8: Plumbing System The Macerator Bypass Valve is located underneath the external hose storage box. This bypass will allow you to gravity dump the waste from the tanks straight down to a 3-inch sewer hose connection under the trail- er, in the event there is a problem with the macerator motor.

  • Page 159: Tank Heaters (If So Equipped)

    Section 8: Plumbing System Dump the black water tank (see Black and Gray Tank Drains) and leave the black tank drain valve open. Connect a garden hose from the water supply source to the black tank flush. With the water source turned ON, flush the black water holding tank until the water running out of the black tank drain valve is clear (not discolored or cloudy).

  • Page 160: Toilet (If So Equipped)

    Section 8: Plumbing System In order for the 120VAC tank heaters to be in operation, the recreation • vehicle MUST be hooked up to shore power or under generator power. If the recreation vehicle is not operating on shore power or generator •...

  • Page 161: Spray Port (If So Equipped)

    Section 8: Plumbing System The toilet system will perform better when water is run for ten to fifteen seconds after flush- ing to ensure that the waste will proceed to the bottom of the tank. If there is not a sufficient amount of water used during flushing, the waste materials may not evacuate properly from the drain line to the tank.
  • Page 162 Section 8: Plumbing System Notes:...

  • Page 163: Section 9: Heating & Cooling

    Section 9: Heating & Cooling Air Conditioner The air conditioning system is controlled by a thermostat. Cooled air enters the RV through the grill. Make sure you have sufficient power available before operating the air conditioner. Do not operate the air conditioner without the return air filter. Operating the system without the filter allows the lint and dirt that is normally stopped by the filter to accumulate on the cooling coil of the air conditioner.

  • Page 164: Ceiling Fan (If So Equipped)

    Section 9: Heating & Cooling NOTE: For RV models with touch screens, the powered roof vent(s) may be controlled on one of the selectable screens on the touch screen. Ceiling Fan (if so equipped) Be careful to avoid placing any object in the path of the ceiling fan blades! Turn the ceiling fan ON/OFF using an interior wall switch.

  • Page 165: Fireplace (If So Equipped)

    Section 9: Heating & Cooling The furnace should be inspected periodically (monthly during the heat- ing season) for presence of soot on the vent. Soot is formed whenever combustion is incomplete. This is a visual warning that the furnace is op- erating in an unsafe manner.
  • Page 166 Section 9: Heating & Cooling Notes:...

  • Page 167: Section 10: Appliances

    Section 10: Appliances Microwave To prevent damage, remove the turntable from the microwave when trav- eling. Make sure you are connected to a 120-volt power source. Never use the microwave cavity for storage. The microwave cavity should always be empty when not in use. For details on operation, cleaning and safety information, refer to the manufacturer’s user guide.

  • Page 168: Cooktops, Range And Oven (If So Equipped)

    Section 10: Appliances Cooking With Propane (if so equipped) See the Propane System section for important safety instructions. Refer to the manufactur- er’s owner’s manual for detailed operating and safety instructions for all propane appliances. Cooktops, Range and Oven (if so equipped) For detailed operating and safety information, refer to the manufacturer’s user guide.
  • Page 169 Section 10: Appliances Do not use aluminum foil on the electric range cooktop, as this material will damage the cooktop surface if it melts. Do not use aluminum foil under any circumstances on the electric range cooktop. Gas Drop-In Cooktops (if so equipped) Depending on your model, it may be equipped with either a 2 burner or 3 burner cooktop.

  • Page 170: Gas Bbq Grill (If So Equipped)

    Section 10: Appliances Gas BBQ Grill (if so equipped) Be sure to read, understand and follow all information supplied with your recreation vehicle concerning the use of propane before operating the BBQ grill. The propane hose must be correctly connected before lighting the grill.

  • Page 171: Attaching The "Quick Coupler" Connection

    Section 10: Appliances Rail Mount (if so equipped) Hang the grill bracket on the aluminum mount- ing strip located on the side of the recreation vehicle. Open the (2) folding arms on the bracket mak- ing sure they lock in position. Slide the grill onto the (2) arms against the stops.

  • Page 172: Range Hood (If So Equipped)

    Section 10: Appliances Range Hood (if so equipped) If your recreational vehicle is equipped with a range hood, it will be connected to an exterior vent. The vent has an inner flap with two snaps. This flap can be snapped shut when the vehicle is in motion, or during storage to keep insects, debris, snow, rain, etc.
  • Page 173 Section 10: Appliances The ice maker (if so equipped) should be turned off and the ice tray emptied when power to your recreation vehicle has been shut off. With no power, the ice will melt and water may “pool” in the refrigerator door. When power is restored, the vibration may cause this water to run out of the door and on to the vehicle floor.

  • Page 174: Washer/Dryer Prep (If So Equipped)

    Section 10: Appliances If you need to clean the condenser: Remove the base grille. Use a vacuum cleaner with a soft brush to clean the grille, the open areas behind the grille and the front surface area of the condenser. Replace the base grille when finished.

  • Page 175: Water Heater - See Plumbing Section

    Section 10: Appliances Central Vacuum System The following is an overview of the central vacuum system operation. For detailed operat- ing and safety instructions, refer to the manufacturer’s user guide. The central vacuum system installed cleans virtually any surface with no electric cords and has a variety of attachments for many cleaning needs.

  • Page 176: Quick Coupler Connection

    Section 10: Appliances Attaching the “quick coupler” connection The “quick coupler” is directly connected to the RV propane system. The “quick-coupler” connection has a positive shut-off valve as required by code and standards. Place the “quick coupler handle in the OFF position and push back the sleeve.
  • Page 177 Section 10: Appliances The grill requires proper ventilation. It is designed for RV outdoor use only. NEVER put lava rocks or charcoal or anything else on or under the grate. Grill is designed so it does not require those items. Serious injury or property damage can occur by placing foreign objects on the grate.
  • Page 178 Section 10: Appliances Notes:...

  • Page 179: Section 11: Electronics

    Section 11: Electronics Winegard Air 360 Plus System (If So Equipped) The Winegard Air 360 Plus system is a fixed omnidi- rectional TV/FM antenna, plus Wi-Fi, and 4G extender. The antenna enclosure is 8 inches high and 17 inches in diameter.

  • Page 180: Opening The Router Box

    Section 11: Electronics This router box, can receive a cellular data connection (through the use of a SIM card sup- plied by your cellular provider or through Winegard). The Winegard SIM card comes pre- installed in the ceiling router box. A second antenna in the rooftop enclosure will also pick up any wireless Wi-Fi signals in the immediate area and distribute those signals through the ceiling mounted Winegard Gateway router box.
  • Page 181 Section 11: Electronics Replace the box back in the ceiling mounting plate and slide it towards the plastic lever and it should lock in place without pressing the tab. Bluetooth control: NOTE: You MUST turn the power switch (Fig 3) ON or there will be no cellular or Wi-Fi signals from the 4GLTE/Wi-Fi router box.
  • Page 182 Section 11: Electronics Winegard has two free apps that can be downloaded for Android or IPhone to help locate TV and Satellite signals: TV Signal Finder and HD Tower Finder. These apps will help you determine HDTV tower lo- cations and satellite dish pointing coordinates. It uses the device camera to help set the angle on your satel- lite dish or show you a graphic representation of the TV towers located in your area.

  • Page 183: Exterior Sliding / Pivoting Tv

    Section 11: Electronics Exterior Sliding / Pivoting TV Your recreation vehicle may be equipped with a TV located in an exterior compartment that allows you to slide it in and out of the compartment, along with the ability to pivot and reposi- tion for viewing.
  • Page 184 Section 11: Electronics Notes:...

  • Page 185: Section 12: Interior

    Section 12: Interior Cleaning The Interior To keep the value of your recreation vehicle, perform regular maintenance using the proper materials and procedures. Using the wrong cleaner may result in damage to the surfaces in your vehicle. Check with the manufacturer’s information for the recommended cleaning agent.
  • Page 186 Section 12: Interior Fill a spray bottle with water and a tiny amount of soap. Then spray a lint-free towel with the mixture and use the towel to wipe down each slat. While cleaning, try not to bend the slats. They can also be soaked in a bathtub to loosen up any debris so the slats can be wiped down easily.

  • Page 187: Sofa And Dinette

    Section 12: Interior NOTE: Oil based soaps and cleaners are not recommended. No abrasive cleaners or alcohol cleansers should be used. If other cleaner solutions are used, first try on a spot in an inconspicuous area. Sofa and Dinette Your recreation vehicle may be equipped with one of the following sofa styles. Hide-A-Bed Sofa or Sofa Sleeper The hide-a-bed sofa functions much the same as a regular residential hide-a-bed sofa.

  • Page 188: Cube Sofa

    Section 12: Interior Cube Sofa The Cube Sofa functions similar to a residential futon. The slanted back pillows offer nu- merous options as a sofa, along with the ability to extend the cushions for additional sleeping space. Booth Dinette (if so equipped) The dinette is designed to seat up to four adults.

  • Page 189: Pantry Or Hutch (If So Equipped)

    Section 12: Interior Pantry or Hutch (if so equipped) Your recreation vehicle may have a pantry or hutch that you can use for storage. Make sure all items stored in the pantry or hutch are secured to prevent shifting during travel. This cabinetry has been designed to accommodate the normal camping items which may be bulky but not necessarily heavy.

  • Page 190: Flooring

    Section 12: Interior Solid surface sink maintenance Occasionally, clean the solid surface sink by filling one-quarter full with a 50/50 water/ bleach solution. Let soak for 15 minutes, and then wash sides and bottom of sink as solu- tion drains. Flooring Always test a cleaning agent in an inconspicuous area for colorfastness.

  • Page 191: Gas Struts (If So Equipped)

    Section 12: Interior Before lifting, be sure there is nothing on the bed that will restrict its movement or add extra weight. Use caution when opening or closing the bed to keep hands and fin- gers at the end ledge provided (not on the side or farther back than necessary).
  • Page 192 Section 12: Interior NOTE: Loft area appearance and design may differ by model. Exercise extreme care when climbing up or down the ladder (either steel or wood) used for entering or exiting the loft bed. Closet door MUST be securely closed and latched before using the lad- der.

  • Page 193: Bunk Beds (If So Equipped)

    Section 12: Interior Bunk Beds (if so equipped) Your recreational vehicle may be equipped with bunk style beds. Bunk bed weight ratings will vary depending on the style of bunk bed. Refer to the warnings for bunk beds below. Bunk Bed Ladder (if so equipped) Your recreational vehicle may be equipped with a ladder to access the upper bunk.

  • Page 194: Safe (If So Equipped)

    Section 12: Interior Exercise extreme care when entering or exiting the bunk beds and using the ladder (if so equipped). Do not allow more than one person on the top bunk. Do not allow children under 6 years of age to use the upper bunk. Do not allow horseplay on or under the bed and prohibit jumping on the bed.

  • Page 195: Section 13: Exterior

    Section 13: Exterior Cleaning The Exterior To protect your recreation vehicle’s exterior finish, wash it often and thoroughly. For recreation vehicles with painted exterior graphics, if desired you may wash and wax your vehicle 60 days after purchase. The exterior paint needs time to cure before any wax is applied to the exterior surface.
  • Page 196 Pour warm water on the gasket to melt the ice. Wipe off the water thor- oughly after opening the slideout or door. To prevent the weather stripping from freezing, treat it with a silicone spray.

  • Page 197: Frame

    Section 13: Exterior Damaged paint To prevent corrosion, touch up small cracks and scratches in the paint coat as soon as pos- sible with touch-up film or paint. Carefully check the body areas facing the road and the tires for damage to the paint coat caused by flying stones, etc. Use the closest automotive paint (available locally) match possible when touch-up paint is needed.

  • Page 198: Windows

    Section 13: Exterior Windows Any ventilating window may permit water inside, especially during heavy rainstorms. Con- densation will also cause water to accumulate on windows and in the tracks. The window “glass” can normally be cleaned with a sponge and water. Use glass cleaner to remove wax, oil, grease, dead insects, etc.

  • Page 199: Sealants

    Section 13: Exterior LADDER CAPACITY MAXIMUM 300 lbs. (136 kg) DO NOT exceed the ladder maximum weight rating. The maximum rating includes the person's weight PLUS weight of items carried. When climbing: • Always face the ladder. • Climb slowly with weight centered between side rails. •...

  • Page 200: Fifth Wheels - Sealant Diagram

    Section 13: Exterior If you notice water inside the recreation vehicle, immediately have the dealer check for the source of the leak. Failure to correct the leak may result in serious damage to your recreation vehicle, and this damage may not be warrantable. If you have questions and/or need assistance with sealing your recreation vehicle, consult with your recreation vehicle dealer.

  • Page 201: Section 14: Travel/Camping/Storage Checklists

    Section 14: Travel/Camping/Storage Checklists Travel Checklist Following is a preliminary list of items that need to be checked before leaving your home or campsite. This is a general list, which you may want to customize as you determine your own needs. Safety Make sure you follow all safety precautions noted in this owner’s manual and in any manufacturer’s operators manual when preparing to travel.

  • Page 202: Rv Storage

    Section 14: Travel/Camping/Storage Checklists Before leaving the campsite Check the area under the RV after overnight parking and look for water or other fluid leaks. If leaks are detected, find the cause and correct it immediately. Turn off propane tanks. Empty black and gray holding tanks, rinse as needed (if so equipped).
  • Page 203 Section 14: Travel/Camping/Storage Checklists Close the propane cylinder valve(s). We recommend using a propane cylinder cover, and to make sure the propane regulator is covered. If is equipped with a gas/ electric DSI range, light a range gas burner to consume any gas remaining in the lines.
  • Page 204 Section 14: Travel/Camping/Storage Checklists Notes:...

  • Page 205: Section 15: Additional Information

    Section 15: Additional Information Featured Components Quick Reference Chart Your recreation vehicle may be equipped with some of the items listed below. This is a partial listing and it is not intended to cover all components. All information is the latest available at the time of publication.
  • Page 206 Section 15: Additional Information Winegard Company www.winegard.com TV Antenna King Jack www.kingconnect.com Water Heater, Tank DSI Atwood Greenbrier www.atwoodmobile.com Girard Systems www.greenrvproducts.com Water Heater, Tankless Truma AquaGo www.truma.com Water Pump, 12V Shurflo East www.shurflo.com...

  • Page 207: Vehicle Maintenance Record

    Section 15: Additional Information Vehicle Maintenance Record Make: Model: Model Year: Vehicle Serial#: Service Performed Mileage Work Performed Notes Date...

  • Page 208: Ownership Notification

    Section 15: Additional Information Jayco Ownership Notification Fax Form To: (800) 825-7876 ATTENTION! Federal record keeping laws require that we maintain a file of owners of our product. Your cooperation in filling out this from will be appreciated. □ □ Change of Owner Transfer of Limited Warranty (If Applicable - see limited...
  • Page 209 Section 15: Additional Information Notes:...

Table of Contents

Save PDF
