Specifications

Video processing
Preset signal
See page 23 (GB).
Sampling rate
13.5 MHz to 140 MHz
Panel system
a-Si TFT Active Matrix LCD
Panel
Display resolution 1366 dots (horizontal) × 768 lines
(vertical)
FWD-42LX1/42LX1E:
0.681 (horizontal) × 0.681
Pixel pitch
(vertical) mm (
930 (horizontal) × 523 (vertical)
Picture size
mm (36
Panel size
42-inch (diagonal 1068 mm)
FWD-32LX1/32LX1E:
0.510 (horizontal) × 0.510
Pixel pitch
(vertical) mm (
698 (horizontal) × 392 (vertical)
Picture size
mm (27
Panel size
32-inch (diagonal 801 mm)
Inputs and Outputs
INPUT1
DVI
DVI (DVI Specification Rev. 1.0
compliant)
AUDIO
Stereo minijack (×1)
500 mVrms, high impedance
INPUT2
RGB/COMPONENT
D-sub 15-pin (female) (×1) (See
"Pin assignment" on page 42
(GB).)
AUDIO
Stereo minijack (×1)
500 mVrms, high impedance
CONTROL S IN/OUT Minijack (×2)
AUDIO OUT
Pinjack (×2)
500 mVrms, high impedance
REMOTE (RS-232C)
D-sub 9-pin (×1)
×
1
1
inches)
32
32
× 20
5
5
inches)
8
8
×
1
1
inches)
32
32
× 15
1
1
inches)
2
2
VIDEO/S VIDEO input/output adaptor
BKM-FW10 (only for the FWD-42LX1/
32LX1)
VIDEO (NTSC, PAL, SECAM, NTSC4.43,
PAL60, PAL-M, PAL-N)
VIDEO IN
BNC (×1)
Composite video, 1 Vp-p ±2 dB
sync negative, 75 ohms
(automatic termination)
VIDEO OUT
BNC (×1) Loop-through
S VIDEO IN
Mini DIN 4-pin (×1)
Y (luminance): 1 Vp-p ±2 dB sync
negative, 75 ohms terminated
C (chrominance): Burst
0.286 Vp-p ±2 dB (NTSC),
75 ohms terminated
Burst 0.3 Vp-p ±2 dB (PAL),
75 ohms terminated
S VIDEO OUT Mini DIN 4-pin (x1) Loop-through
AUDIO IN
Pinjack (×2)
500 mVrms, high impedance
SPEAKER
7 W + 7 W (6 ohms), direct
unbalanced impedance:
6-16 ohms
Component/RGB Input Adaptor BKM-
FW11 (For the FWD-42LX1 only)
COMPONENT/RGB IN
COMPONENT/RGB BNC (×3)
HD/VD
BNC (×2)
AUDIO
Stereo minijack (×1)
500 mVrms, high
impedance
General
Power requirements
100 V to 240 V AC, 50/60 Hz,
FWD-42LX1/42LX1E:
2.8 A to 1.1 A
FWD-32LX1/32LX1E:
1.7 A to 0.8 A
Power consumption
FWD-42LX1/42LX1E: 240 W
FWD-32LX1/32LX1E: 170 W
Operating conditions
Temperature: 0 °C to +35 °C
(32 °F to 95 °F)
Humidity: 20% to 90%
(no condensation)
Specifications
1)
41
(GB)
