Murata MAGICSTRAP LXMS Series Application Manual page 7

Reference Antenna Design and Performance
Type 2
Actual Read Range
PCB Size
L x W
20 x 6cm
14 x 4cm
10 x 4cm
6 x 4cm
30dBm, 6dB1 (4W EIRP) w/circularly polarized
wave
*Reader/Writer: CSL-461
** 2mm read range is available with loop antenna
Read Range (m) by Freq (MHz)
Simulation according to min. operating power
Application Guide
USA Japan
(m) (m)
1.4 1.1
2.5 2.0
1.6 1.6
0.6 0.5
PCB Size USA
L x W (cm)
20 x 6cm
14 x 4cm
10 x 4cm
6 x 4cm
10dBm, 6dB1 (40mW EIRP)
w/linearly polarized wave
6
Directivity
Japan
(cm)
5 3
20 10
5 10
** **
