Operating Modes

The IOCB1616 has the following modes that are set from the Client software.
Mode
01 – Delayed Output
02-Timed Output
03-Pulsed Output
04-Input\RTE Mode
05-Delayed Input &
Delayed Output
06-Delayed Input &
Timed Output
07- Delayed Input &
Pulsed Output
11 – Manual Pulse
Control
Keyscan Inc. A Member of the Kaba Group
Output
If the input remains in alarm past
the specified output time, the
output is triggered. The output
remains triggered until the input is
secured or closed.
If the input goes into alarm, the
output is triggered. The output
remains on for the duration of the
specified output time.
If the input goes into alarm, the
output is triggered. The output
pulses off and on for the specified
output time. The output remains
triggered until the input is secured
or closed.
When an RTE device triggers, the
associated input is shunted. The
shunt time is the associated input
time. The assigned output is
triggered for the duration of the
specified output time. When the
associated input is closed or
secured, all timers are reset.
If the input is triggered, the alarm
is delayed. The input is delayed by
the specified input time. The output
is triggered at the end of the
cumulative input and output times.
The output remains triggered until
the input is secured or closed.
If the input is triggered, the alarm
is delayed. The input is delayed by
the specified input time. The output
remains on for the duration of the
specified output time. The output
remains triggered until the input is
secured or closed.
If the input is triggered, the alarm
is delayed. The input is delayed by
the specified input time. The output
pulses off and on for the specified
output time. The output remains
triggered until the input is secured
or closed.
Client enabled pulse option for an
output. (Primarily for use with the
active mapping module)
Input
Alarm immediately
Alarm immediately
Alarm immediately
Alarm immediately sent
if the RTE input is not
used as a shunt for the
associated input. Alarm if
input for the door contact
is left open after the
associated input time has
expired.
The input's alarm is
delayed until the input
timer expires. Then it is
sent to software.
The input's alarm is
delayed until the input
timer expires. Then it is
sent to software.
The input's alarm is
delayed until the input
timer expires. Then it is
sent to software.
The output is pulsed for
the specified output time.
