Friedrich VERT-I-PAK Series Engineer's Manual
Single package vertical heat pumps
Hide thumbs
Also See for VERT-I-PAK Series:
- Product profile (12 pages) ,
- Installation instructions (5 pages)
Advertisement
Quick Links
PRODUCT PROFILE
Single Package Vertical Heat Pumps
Features
• Up to 10.4 EER
• Completely self-
contained; no outside
condensing unit
• Can be installed from any
interior side (front, right
or left)
• Patented telescoping
plenum (accessory)
easily adapts to more
installations
• Unique free-floating
chassis and fully insulated
cabinets for improved
sound characteristics and
unit performance
• Condensate removal
system uses slinger ring
technology to cool the coil
and increase efficiency
PRPRF_VPAK_2018
VERT-I-PAK
• Primary condensate
removal system provided
thru 3/4" pipe fittings for
more placement options
• Secondary overflow from
primary drain*
• Pre wired, charged and
piped
• Two-speed fan control
from wireless or wired
wall thermostat
• Safety power disconnect
• 5 YR. limited warranty-
includes labor
TH E EX P ER T S IN RO O M A I R C ON DI TI ON I N G
PRODUCT PROFILE
®
*24000 Btu models (VHA24K & VHA24R) and 18000 BTU
model (VHA18K & VHA18R) use secondary gravity-fed
drain (VPDP1).
9521 4200_01
Advertisement
Related Manuals for Friedrich VERT-I-PAK Series
Summary of Contents for Friedrich VERT-I-PAK Series
- Page 1 PRODUCT PROFILE PRODUCT PROFILE VERT-I-PAK ® Single Package Vertical Heat Pumps Features • Up to 10.4 EER • Primary condensate removal system provided • Completely self- thru 3/4" pipe fittings for contained; no outside more placement options condensing unit • Secondary overflow from •...
-
Page 2: Chassis Specifications
CHASSIS SPECIFICATIONS K-Series models 230/208V, R-Series models 265V MODEL VHA09K VHA09R VHA12K VHA12R VHA18K VHA18R VHA24K VHA24R COOLING DATA COOLING BTU 9400/9400 9400 12200/12000 12400 18200/18000 18000 23000/22800 22500 POWER (W) 905/905 1220/1200 1240 1825/1800 1815 2527/2505... - Page 3 UNIT CHASSIS DIMENSIONS Applicable Models Applicable Models VHA09K VHA18K VHA09R VHA18R VHA12K VHA24K VHA12R VHA24R UNIT TOP VIEW DIMENSIONS " control box electrical " entrance " Outside Wall " " "...
-
Page 4: Installation Overview
INSTALLATION OVERVIEW Small chassis Applicable Models VHA09K VHA09R VHA12K VHA12R Louver VPAL2/VPSC2 (Sold separately) Part A Outside Wall Plenum Exterior/ Outside Wall Filter (14” x 20”) Part B Inside Wall Plenum Unit VPAWP1-8 = 5 1/2" - 8" D x 24 1/8" W x 30 3/8" H VPAWP1-14 = 8"... - Page 5 TYPICAL UTILITY CLOSET Chassis shown in closet on optional platform 25" x 20" Filter (Field Supplied) Rigid Ductwork Electrical Connection Exterior Wall Flexible Ductwork VPAWP1-8/1-14 Wall Plenum Plenum Divider Thermostat Wiring VPRG4/VPRG4R Access Panel and Return Air Filter Grille Power Disconnect 3/4"...
- Page 6 ACCESSORIES DIMENSIONS VPAL2 / VPSC2 Louver Architectural Louver ” VPAL2/VPSC2 ” VPAWP1-8 Wall Plenum Cutout Dimensions: " W x 30- ⁄ ”H " " Wall Plenum VPAWP1-8 - telescopes from 5- ” to 8” VPAWP1-14 - telescopes from 8” to 14”...
- Page 7 ACCESSORIES DIMENSIONS 30” Cutout Dimensions: 28”W x 48”H Access Panel with Return Air Grille 50” VPRG4/VPRG4R Filter Size: 20” x 20” Field Supplied...
- Page 8 EXTENDED COOLING PERFORMANCE OUTDOOR DRY BULB TEMP. (DEGREES F AT 40% R.H.) INDOOR WET BULB TEMP. (DEGREES F AT 80 F D.B.) BTUH 11054 10631 9842 10528 9926 9156 10114 9400 8319 9475 8413 7417 8954 7835 6914 WATTS 1023 1022 1026 VHA09K...
- Page 9 SMALL CHASSIS ELECTRICAL DATA ELECTRICAL DATA VHA09K VHA12K HEATER WATTS 2500/2050 3400/2780 5000/4090 2500/2050 3400/2780 5000/4090 VOLTAGE 230/208 ELECTRIC HEATING BTU 8500/7000 11600/9500 17000/13900 8500/7000 11600/9500 17000/13900 HEAT CURRENT (AMPS) 10.9/9.9 14.8/13.4 21.7/19.7 10.9/9.9 14.8/13.4 21.7/19.7 HEATING AMPS HP 4.0/4.0 4.0/4.0 4.0/4.0 5.7/5.9...
- Page 10 LARGE CHASSIS ELECTRICAL DATA ELECTRICAL DATA VHA18K VHA24K HEATER WATTS 2500/2050 3400/2780 5000/4090 2500/2050 3400/2780 5000/4090 7500/6135 10000/8180 VOLTAGE 230/208 ELECTRIC HEATING BTU 8500/7000 11600/9500 17000/13900 8500/7000 11600/9500 17000/13900 25600/20900 34100/27900 HEAT CURRENT (AMPS) 10.9/9.9 14.8/13.4 21.7/19.7 10.9/9.9 14.8/13.4 21.7/19.7 32.6/29.5 43.5/39.3 HEATING AMPS HP...
-
Page 11: Application And Installation
• Quick connect drain coupling ships standard to make installation and removal easier. Application and Accessories (All models) • The use of a Friedrich wall plenum is required for instal- lation. Plenum opening is " above the floor for 9,000 &... - Page 12 Wired, single stage, wall-mounted digital thermostat with two fan speeds and backlight for control of Friedrich VERT-I-PAK. WRT1 Wireless, single stage, wall-mounted digital thermostat with two fan speeds and backlight for control of Friedrich VERT-I-PAK. ENERGY MANAGEMENT THERMOSTATS RT6, RT6P WRT1 EMRT1 Wired thermostat with occupancy sensor.
- Page 13 HVAC Engineering Specifications A-Series Vertical Packaged Heat Pumps Cooling: 9400 – 23000 Btu Friedrich Models: VHA – Heat Pump with electric heat Heating: 8400 – 20000 Btu (Heat Pump) All units shall be factory assembled, piped, wired and fully An emergency heat override switch must be available to allow charged with R-410A.
- Page 14 ITEM PLAN DESIGNATION QUANTITY COOLING Btu VOLTAGE FRIEDRICH MODEL A-SERIES ACCESSORIES (Wall Plenum and Outdoor Louver are required) VPAWP1-8 Adjustable Wall Plenum (5 ½"- 8") RT6 Wired Digital Wall Thermostat VPAWP1-14 Adjustable Wall Plenum (8"-14") RT6P Wired Programmable Wall Thermostat...
- Page 15 Friedrich Air Conditioning Company - International Division. Any defective part to be replaced must be made available to FRIEDRICH in exchange for the replacement part. Reasonable proof must be presented to establish the date of install, otherwise the beginning date of this certificate will be considered to be our shipment date plus sixty days. Replacement parts can be new or re-manufactured.
- Page 16 Friedrich Air Conditioning Co. l 10001 Reunion Place, Suite 500 l San Antonio, TX 78216 l 877.599.5665 l www.friedrich.com PRPRF_VPAK_2018 9521 4200_01...
