CKD WKF2 Series Manual page 2

DIVERSIFIED
Diversified
Compatible with flow rates of 0.4 to 250 L/min
Compatible with a wide range of flow rates.
Easy flow rate adjustment
Can be adjusted with a
manual valve.
Various output functions available
Analog output
Instantaneous flow rate
U
Temperature
U
Pulse output
Integrating flow
U
IO-Link model released
IO-Link is a digital communication standard for factory sensors and actuators. (IEC61131-9)
Parameters and event data that could not be transmitted by analog communication can now be transmitted.
Cloud
Plant
PLC
Case identification
Parameter change
I/O
(option)
OUT1
Switch output
NPN/PNP switchable
Instantaneous flow rate 1, 2
U
Temperature 1, 2
U
Integrating flow
U
External input
Integrating flow reset
U
Peak hold reset
U
Permanent monitoring
Alarm notification
Water temperature measuring feature
is standard for all models
There is no need to for an external water temperature
sensor, reducing space and wiring work.
Handles water up to 95 °C
Molding machine cooling
Analog output
Instantaneous flow rate
U
Temperature
U
Pulse output
Integrating flow
U
Features of IO-Link
Digital signal
Permanent monitoring made possible by
digital data.
Parameter remote Parameters can be set and changed from
operation
the network, so the system can be operated
remotely.
Ethernet
Case identification
Model No. and serial No. can be checked via
the network.
Settings can be copied from the master,
Plug & Play
making cumbersome resetting of parameters
during maintenance unnecessary.
Malfunction
notification
Malfunctions and disconnections of the device
can be checked.
Connection to fieldbus
Connection to an Ethernet network is possible,
enabling the creation of an IoT system.
Heated water for mold Laser oscillator cooling
temperature controlling
OUT2
Switch output
NPN/PNP switchable
Instantaneous flow rate 1, 2
U
Temperature 1, 2
U
Integrating flow
U
IO-Link
