INSYS 19" 336 LL
S24 Time period until switching into sleep mode
The time after which the modem switches to energy saving mode (sleep)
during inactivity is determined (in seconds) in S24. The energy saving mode
will be quit as soon as characters are sent to the modem, or when a call
comes in.
Note:
S25 Time period for DTR signal
Time period, in which a modem waits without a DTR signal before it hangs up
(1/100 seconds).
S26 Time period between RTS/CTS
Time period between RTS and CTS activation in 1/100 seconds.
S27* General settings
Bit
Bit 0-3
Bit 4.5
Bit 6
Bit 7
S29 Time period for modifier "Flash"
Sets the time period in tenths of seconds, after which the modem hangs up due to
a flash in the dialing string.
S30 Time period until hang up due to silence
Time period, in which the modem waits without activity before hanging up. Units
in seconds (only for FAX Class 1).
When the modem is in sleep mode, it is necessary to send an
"AT" command before sending other commands. This first "AT"
command may not be answered with "OK". Further AT com-
mands may be entered immediately.
Meaning
RS232-Mode
Reserved
CCITT or Bell
Modulation
Remote Control Status
Asynchronous Mode Selection:
0: see AT&M0 or AT&Q0
9: see AT&Q5
10: see AT&Q6
CCITT/Bell Select
0: CCITT Modulation
1: Bell Modulation
Remote control
0: Switches the remote control OFF.
1: Remote control ON
S Registers
