insys icom 336 LL Manual page 59

INSYS 19" 336 LL
Command
AT*U<n>
ATV<n>
AT\V<n>
Description
Select the data format at the serial interface
The data format can be preselected with this command. This will, however, not
switch off the automatic detection. As soon as an AT is recognized, the serial in-
terface will set itself to the recognized speed and protocol.
If no AT is sent, the selected protocol is maintained until a hardware reset is per-
formed. If the selected protocol should be maintained longer, it must be stored
with AT&W.
This command will not change the register S23! It only changes if
the automatic speed and protocol detection is used.
8 data bits,
AT*U0
7 data bits,
AT*U1
7 data bits,
AT*U2
7 data bits,
AT*U3
7 data bits,
AT*U6
8 data bits,
AT*U7
8 data bits,
AT*U8
8 data bits,
AT*U9
Format of modem messages
This command determines if the INSYS 19" 336 LL Modem transmits messages
to the application in short or long format.
Messages in short format, i.e. only the error number
ATV0
Messages in long format, i.e. the error text (default)
ATV1
Format of connect rate messages
This command enables the display of the connect message in
AT\V0
three lines.
This command enables the display of the connect message in
AT\V1
one line. (default)
no parity, 1 stop bit
odd parity, 1 stop bit
even parity, 1 stop bit
no parity, 1 stop bit
no parity, 2 stop bits
odd parity, 1 stop bit
even parity, 1 stop bit
no parity, 2 stop bits
AT Command Reference
59
