S Registers
S17* Initial character for remote configuration
In S17, the ASCII code of a character which is used to start the remote con-
figuration is defined. Values >127 switch the remote configuration off com-
pletely. The default setting in S17 is "42", which equals the ASCII character
"*". This means that the remote configuration is started with the Escape
character sequence
<Pause> **** <Pause>.
Note: The number of characters in the Escape sequence is fixed to "4" char-
acters).
S21* Settings for V.24
Bit
Bit 0.1
Bit 2
Bit 3-4
Bit 5
Bit 6
Bit 7
S22* Speaker system settings
Bit
Bit 0.1
Bit 2-3
Bit 4-6
Bit 7
70
Meaning
Reserved
CTS behavior
DTR behavior
DCD behavior
DSR behavior
Reserved
Meaning
Speaker volume
Speaker control
Error message group
Stores the setting of
AT*L
CT106 (CTS) behavior:
CT108 (DTR) behavior:
CT109 (DCD) behavior
CT107 (DSR) behavior
Reserved
Speaker volume:
0: Off
1: Silent
2: Medium
3: Loud
Speaker control:
0: Off
1: On until carrier (ATM1)
2: Always on
3: On at establishing
Limit result codes:
0: see ATX0
4: see ATX1
5: see ATX2
6: see ATX3
7: see ATX4
INSYS 19" 336 LL
0: see AT&R0
1: see AT&R1
0: see AT&D0
1: see AT&D1
2: see AT&D2
3: see AT&D3
0: see AT&C0
1: see AT&C1
0: see AT&S0
1: see AT&S1
(ATL0)
(ATL1)
(ATL2)
(ATL3)
(ATM0)
(ATM2)
