INDOOR UNIT OVERVIEW

Table 2: Summary Data—Multi F Indoor Units.
Indoor Unit Type
Art Cool Mirror Wall-Mounted
TM
Art Cool Gallery Wall-Mounted
TM
Standard Wall-Mounted
Ceiling-Concealed Duct
(Low Static)
Ceiling-Concealed Duct
(High Static)
Four-Way Ceiling-Cassette
Vertical-
Horizontal
Air Handling
Model number shows nominal capacity and frame size designator.
1
Nominal capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and 67ºF wet bulb (WB) and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
2
H/M/L = High/Medium/Low.
3
8 | INTRODUCTION
Dimensions
Model
(W x H x D)
Number
1
(inches)
LMAN097HVT
35-1/4 × 11-3/8 × 8-1/16
LMAN127HVT
LMAN187HVT 40-9/16 x 12-25/32 x 9-21/32
LMAN097HVP
23-5/8 x 23-5/8 x 5-25/32
LMAN127HVP
LMN077HVT 35-1/4 x 11-3/8 x 8-9/32
LSN090HSV4 34-7/8 x 11-1/4 x 8-1/4
LSN120HSV4 34-7/8 x 11-1/4 x 8-1/4
LMN157HVT 35-1/4 x 11-3/8 x 8-9/32
LSN180HSV4 40-9/16 x 12-13/16 x 9-13/16
LMN247HVT 40-9/16 x 12-25/32 x 9-27/32
LMDN096HV 27-9/16 x 7-15/32 x 27-9/16
LMDN126HV
35-7/16 x 7-15/32 x 27-9/16
LMDN186HV
LMHN240HV
46-17/32 x 11-23/32 x 17-23/32
LMHN360HV
LMCN077HV
Body: 22-7/16 x 8-7/16 x 22-7/16
LMCN097HV
Panel: 27-9/16 x 7/8 x 27-9/16
LMCN125HV
Body: 22-7/16 x 10-3/32 x 22-7/16
LMCN185HV
Panel: 27-9/16 x 7/8 x 27-9/16
LMVN240HV
18 x 48-21/32 x 21-1/4
LMVN360HV
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. "LG" is a registered trademark of LG Corp.
Nominal Air Flow Rate
Cooling (CFM)
Capacity Btu/h (H/M/L )
2 3
9,000 247 / 230 / 212
12,000 335 / 318 / 300
18,000 572 / 501 / 434
9,000 272 / 208 / 155
11,200 314 / 258 / 198
7,000 198 / 177 / 162
9,000 247 / 230 / 212
12,000 335 / 318 / 300
14,300 371 / 318 / 247
18,000 572 / 501 / 434
24,000 720 / 600 / 466
9,000 318 / 247 / 194
12,000 353 / 300 / 247
18,000 530 / 441 / 353
24,000 688 / 618 / 530
36,000 1,130 / 953 / 706
7,000 265 / 212 / 177
9,000 300 / 265 / 230
12,000 335 / 283 / 247
18,000 459 / 424 / 388
24,000 710 / 640 / 480
36,000 990 / 880 / 800
F
MULTI
F
MULTI MAX
Pipe
Net
Connections
Weight
(inches, O.D.)
(lbs.)
(Liquid, Vapor)
25 1/4, 3/8
35 1/4, 1/2
32 1/4, 3/8
23 1/4, 3/8
20 1/4, 3/8
20 1/4, 3/8
23 1/4, 3/8
31 3/8, 5/8
32 1/4, 1/2
39
1/4, 3/8
51
1/4, 1/2
80 1/4, 1/2
91 3/8, 5/8
31 (Body),
1/4, 3/8
7 (Panel)
34 (Body),
1/4, 1/2
7 (Panel)
117 1/4, 1/2
121 3/8, 5/8
