LG MULTI F Series Engineering Manual page 292

MULTI F MAX OUTDOOR UNIT
Dimensions
Figure 20: LMU540HV External Dimensions.
6-1/2
292 | MULTI F MAX OUTDOOR UNIT
24-13/32 6-1/2
14-1/20
37-13/32
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. "LG" is a registered trademark of LG Corp.
4-holes for anchor bolts
No.
Liquid pipe connection
1
2 Gas pipe connection
3 Air discharge grille
4 Power & transmission connection
4
Supporter
F
MULTI
F
MULTI MAX
Part Name
Unit: inch
Center of Gravity
