EQUIPMENT SELECTION PROCEDURE
Table 319: Rated Outdoor Unit Capacity.
Rated Capacity (Btu/h)
Minimum No. of Connectable Indoor Units
Connectable Indoor
Maximum No. of Connectable Indoor Units
Units
Determine the Corrected Capacity
The corrected cooling / heating capacity is different from the rated cooling / heating capacity. The corrected capacity includes changes in
unit performance after considering design temperatures, available capacity that can be allocated from the outdoor unit, pressure drop due
to refrigerant line length, defrost operation in heating mode, and (if applicable) altitude. Depending on the location of the building, additional
capacity correction factors may need to be applied.
Using the Outdoor Unit Cooling and Heating Capacity Tables
Rated cooling capacity ratings are obtained with air entering the indoor unit at 80ºF dry bulb (DB) and 67ºF wet bulb (WB), and outdoor ambi-
ent conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB). Rated heating capacity ratings are obtained with air entering the indoor unit at
70ºF dry bulb (DB) and 60ºF wet bulb (WB) and outdoor ambient conditions of 47ºF dry bulb (DB) and 43ºF wet bulb (WB).
To evaluate the total outdoor unit capacity at design conditions, using LATS Multi F software (preferred method) or reference the Perfor-
mance Data Capacity Tables found in the Multi F outdoor unit section in this manual. All design temperatures are not explicitly shown in the
charts, therefore, interpolation may be necessary to calculate the capacity for specific design conditions. Based on the premise that capacity
follows a linear curve, the following formula can be applied:
(y - y1) / (y2 - y1) = (x - x1) / (x2 - x1)
Where
y = Missing Capacity (Capacity at the Design Temperature).
y1 = Capacity at Lower Temperature (Smaller value of the two nearest published TC datapoints).
y2 = Capacity at Higher Temperature (Higher value of the two nearest published TC datapoints).
x = Design Temperature (Temperature not shown in published capacity tables).
x1 = (Smaller value of the two nearest published temperature datapoints).
x2 = (Larger value of the two nearest published temperature datapoints).
Median between two published Total Capacity [TC] Btu/h datapoints in the capacity table.
1
Median between two nearest published temperature datapoints.
2
Using the Indoor Unit Cooling and Heating Capacity Tables
The datapoints shown in the indoor unit cooling and heating capacity charts are based on (and convey) an indoor unit operating with maxi-
mum possible refrigerant flow from the outdoor unit and before any derates are applied. In other words, the capacities displayed reflect what
the indoor unit would produce if it was the only indoor unit that required capacity, and the outdoor unit did not have to allocate any capacity to
another indoor unit.
System operation with a combination of indoor units is not conveyed in these charts, however, the information can be used to calculate
indoor unit allocated capacity (without using the system combination tables). Simply calculate by using the formula:
Qidu(combi) = Qodu(rated) x Qidu(rated)
ΣQidu(rated)
Where
Qidu(combi) = Individual Indoor Unit Combination Capacity.
Qodu(rated) = Outdoor Unit Rated Capacity.
• The formula can be used to find individual indoor unit capacity for Multi F MAX systems.
• A more accurate method to determine expected capacity would be to apply the outdoor unit's corrected capacity instead of rated
capacity.
344 | APPLICATION GUIDELINES
Cooling
Heating
Maximum Capacity Index
1
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. "LG" is a registered trademark of LG Corp.
Outdoor Units
LMU18CHV LMU24CHV
17,000 20,000
22,000 24,000
2 2
2 3
24,000 33,000
2
Qidu(rated) = Individual Indoor Unit Rated Capacity.
ΣQidu(rated) = Total Connected Indoor Unit Rated Capacity.
F
MULTI
F
MULTI MAX
LMU36CHV LMU540HV
32,000 52,500
36,000 58,000
2 2
4 8
48,000 73,000
