Page 1 MULTI MULTI HEAT PUMP SYSTEM ENGINEERING MANUAL Multi-Zone Heat Pump Systems 1.5 to 4.5 Tons Dual and Tri-Zone Quad-Zone Eight-Zone Multi F Multi F Multi F MAX...
Page 2 This document is for design purposes only. EM-MultiFODU-01-15 For continual product development, LG reserves the right to change specifications without notice. ©LG Electronics Inc. This document, as well as all reports, illustrations, data, information, and other materials are the property of LG Electronics U.S.A., Inc.
Page 3: Table Of Contents
Creating a Balanced / Quality Piping System ........362 Cooling Capacity Tables ............. 39-182 Manual Layout Procedure ............... 362 Heating Capacity Tables ............183-278 LG Engineered Multi F MAX Y-Branch Kits ........363 Electrical Data ................. 279 Refrigerant Charge ..............364-365 Acoustic Data .................. 279 Selecting Field-Supplied Copper Tubing ........
Page 4: About Lg Electronics, Inc
Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. 4 | INTRODUCTION...
Page 5 PRODUCT INTRODUCTION “Unit Nomenclature” on page 6 “Outdoor Unit Overview” on page 7 “Indoor Unit Overview” on page 8 “Controls and Options Overview” on page 9...
Page 6: Unit Nomenclature
• Compatible single zone IDU nomenclature is listed in the Single Zone Wall-Mounted IDU Engineering Manual. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. 6 | INTRODUCTION...
Page 7: Outdoor Unit Overview
Minimum number of connectable indoor units is two (2). Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. INTRODUCTION | 7...
Page 8: Indoor Unit Overview
Nominal capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and 67ºF wet bulb (WB) and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB). H/M/L = High/Medium/Low. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. 8 | INTRODUCTION...
Page 9: Controls And Options Overview
PRARS0 units. 2.7°F above setpoint. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. INTRODUCTION | 9...
Page 10 For information on controller capabilities, refer to the Controls and Options Table on page 12. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. 10 | INTRODUCTION...
Page 11 For information on controller capabilities, refer to the Controls and Options Table on page 12. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. INTRODUCTION | 11...
Page 12 Branch location and static pressure requirements. Requires PTPKQ0 Plasma kit. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. 12 | INTRODUCTION...
Page 13: Controls And Options Overview
Dynamic V8 Air Cleaner Egg Crate Return Air Grille (one per plenum) Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. INTRODUCTION | 13...
Page 14 MULTI MULTI Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. 14 | INTRODUCTION...
Page 15: Product Features And Benefits
MULTI F OUTDOOR UNIT DATA “Product Features and Benefits” on page 16 “Mechanical Specifications” on page 17 “General Data” on page 18 “Dimensions” on page 20 “Rated Cooling Combination Tables” on page 23 “Rated Heating Combination Tables” on page 31 “Cooling Capacity Tables”...
Page 16 18,000-48,000 Btu/h. 16 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 17 MULTI F OUTDOOR UNIT | 17 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 18 23 to 38. 18 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 19 Rated capacity is certified under AHRI Standard 210 / 240. EER, IEER, COP, and HSPF are subject to change. See www.ahrinet.org for the latest values. MULTI F OUTDOOR UNIT | 19 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 20 20 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 21 MULTI F OUTDOOR UNIT | 21 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 22 22 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 23 (WB), and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB). MULTI F OUTDOOR UNIT | 23 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 24 (WB), and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB). 24 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 25 *The indoor unit must be non-ducted type. MULTI F OUTDOOR UNIT | 25 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 26 (WB), and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB). 26 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 27 (WB), and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB). MULTI F OUTDOOR UNIT | 27 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 28 The specification may be subject to change without prior notice for purpose of improvement. 28 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 29 *The indoor unit must be non-ducted type. MULTI F OUTDOOR UNIT | 29 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 30 Wiring cable size must comply with the applicable local and national codes. 30 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 31 Wiring cable size must comply with the applicable local and national codes. MULTI F OUTDOOR UNIT | 31 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 32 (WB), and outdoor ambient conditions of 47ºF dry bulb (DB) and 43ºF wet bulb (WB). 32 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 33 Wiring cable size must comply with the applicable local and national codes. MULTI F OUTDOOR UNIT | 33 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 34 (WB), and outdoor ambient conditions of 47ºF dry bulb (DB) and 43ºF wet bulb (WB). 34 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 35 (WB), and outdoor ambient conditions of 47ºF dry bulb (DB) and 43ºF wet bulb (WB). MULTI F OUTDOOR UNIT | 35 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 36 Wiring cable size must comply with the applicable local and national codes. 36 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 37 Wiring cable size must comply with the applicable local and national codes. MULTI F OUTDOOR UNIT | 37 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 38 Wiring cable size must comply with the applicable local and national codes. 38 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 39 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 39 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 40 0 ft. level difference between outdoor and indoor units. 40 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 41 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 41 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 42 0 ft. level difference between outdoor and indoor units. 42 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 43 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 43 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 44 0 ft. level difference between outdoor and indoor units. 44 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 45 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 45 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 46 0 ft. level difference between outdoor and indoor units. 46 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 47 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 47 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 48 0 ft. level difference between outdoor and indoor units. 48 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 49 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 49 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 50 0 ft. level difference between outdoor and indoor units. 50 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 51 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 51 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 52 0 ft. level difference between outdoor and indoor units. 52 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 53 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 53 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 54 0 ft. level difference between outdoor and indoor units. 54 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 55 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 55 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 56 0 ft. level difference between outdoor and indoor units. 56 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 57 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 57 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 58 0 ft. level difference between outdoor and indoor units. 58 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 59 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 59 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 60 0 ft. level difference between outdoor and indoor units. 60 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 61 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 61 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 62 0 ft. level difference between outdoor and indoor units. 62 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 63 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 63 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 64 0 ft. level difference between outdoor and indoor units. 64 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 65 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 65 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 66 0 ft. level difference between outdoor and indoor units. 66 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 67 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 67 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 68 0 ft. level difference between outdoor and indoor units. 68 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 69 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 69 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 70 0 ft. level difference between outdoor and indoor units. 70 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 71 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 71 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 72 *The indoor unit must be non-ducted type. 72 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 73 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 73 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 74 0 ft. level difference between outdoor and indoor units. 74 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 75 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 75 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 76 0 ft. level difference between outdoor and indoor units. 76 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 77 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 77 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 78 0 ft. level difference between outdoor and indoor units. 78 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 79 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 79 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 80 0 ft. level difference between outdoor and indoor units. 80 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 81 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 81 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 82 0 ft. level difference between outdoor and indoor units. 82 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 83 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 83 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 84 0 ft. level difference between outdoor and indoor units. 84 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 85 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 85 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 86 0 ft. level difference between outdoor and indoor units. 86 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 87 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 87 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 88 0 ft. level difference between outdoor and indoor units. 88 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 89 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 89 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 90 0 ft. level difference between outdoor and indoor units. 90 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 91 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 91 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 92 0 ft. level difference between outdoor and indoor units. 92 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 93 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 93 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 94 0 ft. level difference between outdoor and indoor units. 94 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 95 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 95 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 96 0 ft. level difference between outdoor and indoor units. 96 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 97 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 97 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 98 0 ft. level difference between outdoor and indoor units. 98 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 99 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 99 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 100 0 ft. level difference between outdoor and indoor units. 100 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 101 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 101 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 102 0 ft. level difference between outdoor and indoor units. 102 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 103 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 103 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 104 0 ft. level difference between outdoor and indoor units. 104 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 105 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 105 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 106 0 ft. level difference between outdoor and indoor units. 106 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 107 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 107 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 108 0 ft. level difference between outdoor and indoor units. 108 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 109 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 109 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 110 0 ft. level difference between outdoor and indoor units. 110 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 111 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 111 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 112 0 ft. level difference between outdoor and indoor units. 112 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 113 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 113 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 114 0 ft. level difference between outdoor and indoor units. 114 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 115 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 115 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 116 0 ft. level difference between outdoor and indoor units. 116 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 117 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 117 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 118 0 ft. level difference between outdoor and indoor units. 118 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 119 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 119 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 120 0 ft. level difference between outdoor and indoor units. 120 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 121 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 121 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 122 0 ft. level difference between outdoor and indoor units. 122 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 123 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 123 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 124 0 ft. level difference between outdoor and indoor units. 124 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 125 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 125 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 126 0 ft. level difference between outdoor and indoor units. 126 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 127 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 127 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 128 0 ft. level difference between outdoor and indoor units. 128 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 129 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 129 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 130 0 ft. level difference between outdoor and indoor units. 130 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 131 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 131 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 132 0 ft. level difference between outdoor and indoor units. 132 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 133 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 133 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 134 0 ft. level difference between outdoor and indoor units. 134 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 135 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 135 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 136 0 ft. level difference between outdoor and indoor units. 136 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 137 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 137 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 138 0 ft. level difference between outdoor and indoor units. 138 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 139 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 139 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 140 0 ft. level difference between outdoor and indoor units. 140 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 141 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 141 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 142 0 ft. level difference between outdoor and indoor units. 142 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 143 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 143 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 144 0 ft. level difference between outdoor and indoor units. 144 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 145 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 145 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 146 0 ft. level difference between outdoor and indoor units. 146 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 147 *The indoor unit must be non-ducted type. MULTI F OUTDOOR UNIT | 147 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 148 0 ft. level difference between outdoor and indoor units. 148 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 149 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 149 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 150 0 ft. level difference between outdoor and indoor units. 150 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 151 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 151 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 152 0 ft. level difference between outdoor and indoor units. 152 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 153 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 153 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 154 0 ft. level difference between outdoor and indoor units. 154 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 155 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 155 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 156 0 ft. level difference between outdoor and indoor units. 156 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 157 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 157 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 158 0 ft. level difference between outdoor and indoor units. 158 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 159 *The indoor unit must be non-ducted type. MULTI F OUTDOOR UNIT | 159 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 160 0 ft. level difference between outdoor and indoor units. 160 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 161 *The indoor unit must be non-ducted type. MULTI F OUTDOOR UNIT | 161 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 162 *The indoor unit must be non-ducted type. 162 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 163 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 163 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 164 *The indoor unit must be non-ducted type. 164 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 165 *The indoor unit must be non-ducted type. MULTI F OUTDOOR UNIT | 165 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 166 0 ft. level difference between outdoor and indoor units. 166 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 167 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 167 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 168 0 ft. level difference between outdoor and indoor units. 168 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 169 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 169 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 170 0 ft. level difference between outdoor and indoor units. 170 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 171 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 171 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 172 0 ft. level difference between outdoor and indoor units. 172 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 173 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 173 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 174 0 ft. level difference between outdoor and indoor units. 174 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 175 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 175 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 176 0 ft. level difference between outdoor and indoor units. 176 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 177 Nominal cooling capacity rating obtained with air entering the indoor unit at 80ºF dry MULTI F OUTDOOR UNIT | 177 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 178 0 ft. level difference between outdoor and indoor units. 178 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 179 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 179 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 180 *The indoor unit must be non-ducted type. 180 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 181 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 181 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 182 0 ft. level difference between outdoor and indoor units. 182 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 183 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 183 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 184 0 ft. level difference between outdoor and indoor units. 184 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 185 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 185 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 186 0 ft. level difference between outdoor and indoor units. 186 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 187 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 187 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 188 0 ft. level difference between outdoor and indoor units. 188 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 189 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 189 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 190 0 ft. level difference between outdoor and indoor units. 190 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 191 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 191 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 192 0 ft. level difference between outdoor and indoor units. 192 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 193 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 193 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 194 0 ft. level difference between outdoor and indoor units. 194 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 195 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 195 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 196 0 ft. level difference between outdoor and indoor units. 196 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 197 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 197 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 198 0 ft. level difference between outdoor and indoor units. 198 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 199 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 199 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 200 0 ft. level difference between outdoor and indoor units. 200 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 201 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 201 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 202 0 ft. level difference between outdoor and indoor units. 202 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 203 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 203 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 204 0 ft. level difference between outdoor and indoor units. 204 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 205 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 205 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 206 0 ft. level difference between outdoor and indoor units. 206 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 207 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 207 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 208 0 ft. level difference between outdoor and indoor units. 208 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 209 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 209 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 210 0 ft. level difference between outdoor and indoor units. 210 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 211 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 211 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 212 0 ft. level difference between outdoor and indoor units. 212 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 213 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 213 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 214 0 ft. level difference between outdoor and indoor units. 214 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 215 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 215 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 216 0 ft. level difference between outdoor and indoor units. 216 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 217 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 217 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 218 0 ft. level difference between outdoor and indoor units. 218 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 219 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 219 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 220 0 ft. level difference between outdoor and indoor units. 220 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 221 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 221 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 222 0 ft. level difference between outdoor and indoor units. 222 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 223 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 223 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 224 0 ft. level difference between outdoor and indoor units. 224 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 225 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 225 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 226 0 ft. level difference between outdoor and indoor units. 226 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 227 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 227 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 228 0 ft. level difference between outdoor and indoor units. 228 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 229 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 229 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 230 0 ft. level difference between outdoor and indoor units. 230 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 231 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 231 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 232 0 ft. level difference between outdoor and indoor units. 232 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 233 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 233 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 234 0 ft. level difference between outdoor and indoor units. 234 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 235 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 235 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 236 0 ft. level difference between outdoor and indoor units. 236 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 237 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 237 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 238 0 ft. level difference between outdoor and indoor units. 238 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 239 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 239 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 240 0 ft. level difference between outdoor and indoor units. 240 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 241 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 241 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 242 0 ft. level difference between outdoor and indoor units. 242 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 243 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 243 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 244 0 ft. level difference between outdoor and indoor units. 244 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 245 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 245 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 246 0 ft. level difference between outdoor and indoor units. 246 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 247 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 247 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 248 0 ft. level difference between outdoor and indoor units. 248 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 249 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 249 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 250 0 ft. level difference between outdoor and indoor units. 250 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 251 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 251 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 252 0 ft. level difference between outdoor and indoor units. 252 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 253 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 253 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 254 0 ft. level difference between outdoor and indoor units. 254 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 255 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 255 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 256 0 ft. level difference between outdoor and indoor units. 256 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 257 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 257 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 258 0 ft. level difference between outdoor and indoor units. 258 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 259 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 259 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 260 0 ft. level difference between outdoor and indoor units. 260 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 261 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 261 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 262 0 ft. level difference between outdoor and indoor units. 262 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 263 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 263 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 264 0 ft. level difference between outdoor and indoor units. 264 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 265 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 265 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 266 0 ft. level difference between outdoor and indoor units. 266 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 267 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 267 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 268 0 ft. level difference between outdoor and indoor units. 268 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 269 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 269 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 270 0 ft. level difference between outdoor and indoor units. 270 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 271 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 271 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 272 0 ft. level difference between outdoor and indoor units. 272 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 273 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 273 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 274 0 ft. level difference between outdoor and indoor units. 274 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 275 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 275 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 276 0 ft. level difference between outdoor and indoor units. 276 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 277 0 ft. level difference between outdoor and indoor units. MULTI F OUTDOOR UNIT | 277 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 278 0 ft. level difference between outdoor and indoor units. 278 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 279: Electrical Data
Octave Band Center Frequency (Hz) MULTI F OUTDOOR UNIT | 279 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 280: Refrigerant Flow Diagrams
Pressure Sensor CN_H/PRESS 280 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 281 Pressure Sensor CN_H/PRESS MULTI F OUTDOOR UNIT | 281 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 282: Refrigerant Flow Diagrams
Pressure Sensor CN_TH1 282 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 283: Wiring Diagrams
Figure 14: LMU18CHV Wiring Diagram. MULTI F OUTDOOR UNIT | 283 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 284 Figure 15: LMU24CHV Wiring Diagram. 284 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 285: Wiring Diagrams
Figure 16: LMU36CHV Wiring Diagram. MULTI F OUTDOOR UNIT | 285 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 286: Operation Range
Cooling operation range can extend down to -4 °F outdoor temperature if Low Ambient Kit is installed (sold separately). 286 | MULTI F OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 287: Product Features And Benefits
MULTI F MAX OUTDOOR UNIT DATA “Product Features and Benefits” on page 288 “Mechanical Specifications” on page 289 “General Data” on page 290 “Dimensions” on page 292 “Rated Cooling Combination Tables” on page 293 “Rated Heating Combination Tables” on page 296 “Cooling Capacity Tables ”...
Page 288 Figure 18: Multi F MAX Heat Pump Inverter System — Mix and match for 24,000-73,000 Btu/h. 288 | MULTI F MAX OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 289 MULTI F MAX OUTDOOR UNIT | 289 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 290 For allocated capacity information, see the combination tables on pages 131 to 136. 290 | MULTI F MAX OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 291 MULTI F MAX OUTDOOR UNIT | 291 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 292 Center of Gravity 292 | MULTI F MAX OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 293 (WB), and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB). MULTI F MAX OUTDOOR UNIT | 293 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 294 (WB), and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB). 294 | MULTI F MAX OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 295 (WB), and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB). MULTI F MAX OUTDOOR UNIT | 295 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 296 (WB), and outdoor ambient conditions of 47ºF dry bulb (DB) and 43ºF wet bulb (WB). 296 | MULTI F MAX OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 297 (WB), and outdoor ambient conditions of 47ºF dry bulb (DB) and 43ºF wet bulb (WB). MULTI F MAX OUTDOOR UNIT | 297 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 298 (WB), and outdoor ambient conditions of 47ºF dry bulb (DB) and 43ºF wet bulb (WB). 298 | MULTI F MAX OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 299 0 ft. level difference between outdoor and indoor units. MULTI F MAX OUTDOOR UNIT | 299 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 300 0 ft. level difference between outdoor and indoor units. 300 | MULTI F MAX OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 301 0 ft. level difference between outdoor and indoor units. MULTI F MAX OUTDOOR UNIT | 301 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 302 0 ft. level difference between outdoor and indoor units. 302 | MULTI F MAX OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 303 0 ft. level difference between outdoor and indoor units. MULTI F MAX OUTDOOR UNIT | 303 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 304 0 ft. level difference between outdoor and indoor units. 304 | MULTI F MAX OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 305 0 ft. level difference between outdoor and indoor units. MULTI F MAX OUTDOOR UNIT | 305 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 306 0 ft. level difference between outdoor and indoor units. 306 | MULTI F MAX OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 307 0 ft. level difference between outdoor and indoor units. MULTI F MAX OUTDOOR UNIT | 307 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 308 0 ft. level difference between outdoor and indoor units. 308 | MULTI F MAX OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 309 0 ft. level difference between outdoor and indoor units. MULTI F MAX OUTDOOR UNIT | 309 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 310 0 ft. level difference between outdoor and indoor units. 310 | MULTI F MAX OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 311 0 ft. level difference between outdoor and indoor units. MULTI F MAX OUTDOOR UNIT | 311 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 312 0 ft. level difference between outdoor and indoor units. 312 | MULTI F MAX OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 313 0 ft. level difference between outdoor and indoor units. MULTI F MAX OUTDOOR UNIT | 313 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 314 0 ft. level difference between outdoor and indoor units. 314 | MULTI F MAX OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 315 0 ft. level difference between outdoor and indoor units. MULTI F MAX OUTDOOR UNIT | 315 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 316 0 ft. level difference between outdoor and indoor units. 316 | MULTI F MAX OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 317 0 ft. level difference between outdoor and indoor units. MULTI F MAX OUTDOOR UNIT | 317 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 318 0 ft. level difference between outdoor and indoor units. 318 | MULTI F MAX OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 319 0 ft. level difference between outdoor and indoor units. MULTI F MAX OUTDOOR UNIT | 319 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 320 0 ft. level difference between outdoor and indoor units. 320 | MULTI F MAX OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 321: Heating Capacity Tables
0 ft. level difference between outdoor and indoor units. MULTI F MAX OUTDOOR UNIT | 321 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 322 0 ft. level difference between outdoor and indoor units. 322 | MULTI F MAX OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 323 0 ft. level difference between outdoor and indoor units. MULTI F MAX OUTDOOR UNIT | 323 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 324 0 ft. level difference between outdoor and indoor units. 324 | MULTI F MAX OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 325 0 ft. level difference between outdoor and indoor units. MULTI F MAX OUTDOOR UNIT | 325 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 326 0 ft. level difference between outdoor and indoor units. 326 | MULTI F MAX OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 327: Electrical Data
Octave Band Center Frequency (Hz) MULTI F MAX OUTDOOR UNIT | 327 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 328: Refrigerant Flow Diagrams
CN-P/SENSOR(H) 328 | MULTI F MAX OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 329: Wiring Diagrams
Figure 24: LMU540HV Wiring Diagram. MULTI F MAX OUTDOOR UNIT | 329 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 330: Operation Range
Cooling operation range can extend down to -4 °F outdoor temperature if Low Ambient Kit is installed (sold separately). 330 | MULTI F MAX OUTDOOR UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 331: Mechanical Specifications
MULTI F MAX BD UNIT DATA “Features and Benefits” on page 332 “Mechanical Specifications” on page 333 “General Data” on page 334 “Dimensions” on page 335 “Refrigerant Flow Diagram” on page 336 “Wiring Diagram” on page 337 “Y-Branch Accessory” on page 338 “Branch Distribution Unit Orientation”...
Page 332 Figure 26:Example of Multi F MAX Heat Pump Inverter System with two BD Units 332 | BD UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 333 / communication cable. BD UNIT | 333 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 334: General Data
Piping lengths are equivalent. 334 | BD UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 335: Dimensions
4. * Thickness of insulation BD UNIT | 335 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 336: Refrigerant Flow Diagram
PMBD3640 and PMBD3641 BD Units supplied with "A, B, C, D". 336 | BD UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 337: Wiring Diagram
PMBD3640 and PMBD3641 BD Units supplied with "A, B, C, D". BD UNIT | 337 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 338: Y-Branch Accessory
B = To Branch Distribution Unit 338 | BD UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 339: Branch Distribution Unit Orientation
Bottom View, Port End Facing Up BD UNIT | 339 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 340 MULTI MULTI 340 | BD UNIT Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Page 341: Application Guidelines
APPLICATION GUIDELINES “Equipment Selection Procedure” on page 342 “Building Ventilation Design Guide” on page 348 “Placement Considerations” on page 353...
Page 342: Equipment Selection Procedure
1.2. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. 342 | APPLICATION GUIDELINES...
Page 343 In some designs, oversized indoor units may be unavoidable in the case where the smallest size indoor unit available from LG is larger than what is necessary to satisfy the zone load. This scenario may also occur when an indoor unit selection one size down from the selected unit is slightly short of fulfilling the design load requirements, and the designer must choose the next largest size unit.
Page 344 • A more accurate method to determine expected capacity would be to apply the outdoor unit’s corrected capacity instead of rated capacity. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. 344 | APPLICATION GUIDELINES...
Page 345 96.6 82.0 89.6 95.4 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. APPLICATION GUIDELINES | 345...
Page 346 98.8 49.2 95.7 97.6 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. 346 | APPLICATION GUIDELINES...
Page 347 • Verify that the sensible load of the zone is satisfied. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. APPLICATION GUIDELINES | 347...
Page 348: Building Ventilation Design Guide
LG Electronics, U.S.A., Inc., In all cases, the designer, installer, and contractor should understand if the suggested method is used, it is used at their own risk. LG Electronics U.S.A., Inc., takes no responsibility and offers no warranty, expressed or implied, of merchantability or fitness of purpose if this method fails to perform as stated or intended.
Page 349 OA Wall Louver Damper Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. APPLICATION GUIDELINES | 349...
Page 350 Filter OA Wall Cap Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. 350 | APPLICATION GUIDELINES...
Page 351 Figure 42: Coupled Dedicated Outdoor Air (CDOA). Outdoor Air Unit Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. APPLICATION GUIDELINES | 351...
Page 352 Ceiling Diffuser Air Unit Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. 352 | APPLICATION GUIDELINES...
Page 353: Placement Considerations
• Don’t install the unit in a location where oil, acidic solutions, sprays, or dust (sulfur, carbon, other corrosive materials) are present / often used. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. APPLICATION GUIDELINES | 353...
Page 354 Consider tie-down requirements in case of high winds or where required by local codes. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. 354 | APPLICATION GUIDELINES...
Page 355 13/16 Unit: Inch Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. APPLICATION GUIDELINES | 355...
Page 356 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. 356 | APPLICATION GUIDELINES...
Page 357 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. APPLICATION GUIDELINES | 357...
Page 358: Application Guidelines
Minimum 23-19/32" Minimum 39-3/8" Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. 358 | APPLICATION GUIDELINES...
Page 359: Refrigerant Piping Design & Layout Best Practices
“Design Guideline Summary” on page 360 “Creating a Balanced / Quality Piping System” on page 362 “Manual Layout Procedure” on page 362 “LG Engineered Multi F MAX Y-Branch Kits” on page 363 “Refrigerant Charge” on page 364 “Selecting Field-Supplied Copper Tubing” on page 366 “Refrigerant Piping System Layout”...
Page 360 246.1 LMU36CHV 246.1 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. 360 | DESIGN & PRACTICES...
Page 361 Between branch distribution units (h4) ≤42.9 feet Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. DESIGN & PRACTICES | 361...
Page 362 Multi F order. Following the installation, if any changes or variations to the design were necessary, an “as-built” LATS piping design software report must be provided to LG prior to system commissioning. User should always check the LATS report actual pipe layout versus pipe limits.
Page 363 Field-Installed Piping Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. DESIGN & PRACTICES | 363...
Page 364: Refrigerant Charge
= 10.82 oz. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. 364 | DESIGN & PRACTICES...
Page 365: Refrigerant Charge
= 20.43 oz. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. DESIGN & PRACTICES | 365...
Page 366: Selecting Field-Supplied Copper Tubing
Inches to feet conversion (12 in./ft.) Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. 366 | DESIGN & PRACTICES...
Page 367 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. DESIGN & PRACTICES | 367...
Page 368: Refrigerant Piping System Layout
Field-Provided Isolation Ball Valves LG recommends installing field-supplied ball valves with Schrader ports at each indoor unit. Full-port isolation ball valves with Schrader ports (positioned between valve and indoor unit) rated for use with R410A refrigerant should be used on both the liquid and vapor lines.
Page 369 A + B ~ 12" – 19" Max. 12" Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. DESIGN & PRACTICES | 369...
Page 370 Hexagonal Nut Refrigerant Pipe Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. 370 | DESIGN & PRACTICES...
Page 371 Insulation thickness (value in parenthesis) = 3/4 inch. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. DESIGN & PRACTICES | 371...
Page 372 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. 372 | DESIGN & PRACTICES...
Page 373 Ø1/4 → Ø3/8 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. DESIGN & PRACTICES | 373...
Page 374 Field Piping Torque wrench Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. 374 | DESIGN & PRACTICES...
Page 375 Indoor Unit Piping 71.6-87.5 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. DESIGN & PRACTICES | 375...
Page 376: Piping Insulation
Check the fit of the insulation jacket after the header fitting and all run-out pipes are installed. Mark all pipes at the point where the insulation jacket ends. Remove the jacket. Install field provided insulation on the run-out and main trunk pipes first. Install the LG-pro- vided insulation plugs on the ends of all unused header ports.
Page 377: Condensate Drain Piping
Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. DESIGN & PRACTICES | 377...
Page 378 Not Required Requir ed Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. 378 | DESIGN & PRACTICES...
Page 379: Cut Sheet
Pipe Joints Field-Installed Piping Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. DESIGN & PRACTICES | 379...
Page 380 MULTI MULTI Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. 380 | DESIGN & PRACTICES...
Page 381: Wiring Connections
WIRING CONNECTIONS “General Information” on page 382 “Power Wiring (208-230V) and Communications Cable Details” on page 365 “Indoor Unit Group Control” on page 390...
Page 382 • Indoor Unit(s) to Wired Controller: Three-core cable Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. 382 | WIRING CONNECTIONS...
Page 383 Always include some allowance in the wiring length when terminating. Provide some slack to facilitate removing the electrical panels while servicing. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. WIRING CONNECTIONS | 383...
Page 384 Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. 384 | WIRING CONNECTIONS...
Page 385 Indoor unit D Conduit (field supply) Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. WIRING CONNECTIONS | 385...
Page 386 • Wiring cable size must comply with applicable national, state, and local codes. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. 386 | WIRING CONNECTIONS...
Page 387 • Wiring cable size must comply with applicable national, state, and local codes. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. WIRING CONNECTIONS | 387...
Page 388 • Wiring cable size must comply with applicable national, state, and local codes. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. 388 | WIRING CONNECTIONS...
Page 389 • Wiring cable size must comply with applicable national, state, and local codes. Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. WIRING CONNECTIONS | 389...
Page 390: Wiring Connections
• Control of air flow rate (High/Medium/Low) Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. 390 | WIRING CONNECTIONS...
Page 391: Acronyms
High / Medium / Low Ventilation Rate Procedure Due to our policy of continuous product innovation, some specifications may change without notification. ©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp. WIRING CONNECTIONS | 391...
Page 392 20001747 ISO 9001: 2008 LG ELECTRONICS INC. LG Electronics Products Support EM-MultiFODU-01-15 1-888-865-3026 USA LG Electronics, U.S.A., Inc. Supersedes EM-MultiFODU-06-14 Follow the prompts for HVAC products. Commercial Air Conditioning Division Supersedes DFS-EM-AJ-001-US 014C25 11405 Old Roswell Road Supersedes DFS-EM-AJ-001-US 014A03...

This manual is also suitable for:

Multi f max eight-zone lmu540hv Multi f quad-zone lmu36chv Multi f tri-zone lmu24chv Multi f dual-zone lmu18chv

LG MULTI F Series Engineering Manual

About LG Electronics, Inc

Multi-Zone Systems

Unit Nomenclature

Outdoor Unit Overview

Indoor Unit Overview

Controls and Options Overview

Multi F Outdoor Unit Product Data

Multi F MAX Outdoor Unit Product Data

Multi F MAX Branch Distribution Unit Product Data

Application Guidelines

Refrigerant Piping Design & Layout Best Practices

Wiring Connections

Acronyms

Quick Links

Related Manuals for LG MULTI F Series

Summary of Contents for LG MULTI F Series

This manual is also suitable for:

Table of Contents
