- Page 1 Leica M205 A, M205 C M165 C & M125 Stereomicroscopes Technical Information Living up to Life...
- Page 2 Technical Data Performance Characteristics Leica M125 Leica M165 C Leica M205 C / M205 A 12.5 : 1 manual 16.5 : 1 manual 20.5 : 1 manual/motorized with Optical data FusionOptics ™ Zoom Data with standard optics (1× objective/10× eyepieces) – Zoom range 8×–100×...
- Page 3 Rottermann contrast and CCIC Incident-light stand Large incident-light base with black-and-white stage insert and Antishock feet ™ Stages Gliding stage, MATS heating stage, cup stage, rotating polarization stage, Leica IsoPro mechanical ™ stage (manual and motorized) Illuminators LED5000 MCI...
- Page 4 Leica M125 Optical Data Objectives Plan 0.5× Planapo 0.63× Plan 0.8× Plan 1× Planapo 1× Planapo 1.6× Planapo 2× Working distances 135mm 97mm 67mm 112mm 59mm 61.5mm 30.5mm 20.1mm Zoom Total Object Total Object Total Object Total Object Total Object...
- Page 5 Leica M165 C Optical Data Objectives Plan 0.5× Planapo 0.63× Plan 0.8× Plan 1× Planapo 1× Planapo 1.6× Planapo 2× 135mm 97mm 67mm 112mm 59mm 61.5mm 30.5mm 20.1mm Working distances Zoom Total Object Total Object Total Object Total Object Total...
- Page 6 Optical data for Leica M205 A / M205 C Objektive Plan 0.5× Planapo 0.63× Plan 0.8× Plan 1× Planapo 1× Planapo 1.6× Planapo 2× Working distances 135 mm 97 mm 67 mm 112 mm 59 mm 61.5 mm 30.5 mm 20.1 mm...
- Page 11 LED5000 MCI LED5000 RL Dimensions in mm ø70 275.3...
- Page 12 Leica M165 C / M125 Leica M165 C / M125 with incident-light base and new focusing column with tL RC transmitted-light stand, Leica isoPro manual mechanical stage and manual focusing drive Dimensions in mm max. 370 X = +-75 mm...
- Page 13 Leica M165 C / M125 Leica M165 C / M125 with tL St transmitted-light base and manual focus with tL RC transmitted-light stand and manual focus Dimensions in mm...
- Page 14 Leica M205 C Leica M205 C with incident-light stand and manual focusing drive with tL BFDF transmitted-light stand and manual focusing drive Dimensions in mm...
- Page 15 Leica M205 A Leica M205 A with tL RCi transmitted-light stand and motor focus with tL RCi transm. light stand, Leica isoPro motorized mechanical stage and Dimensions in mm motor focus max. 410 max. 410 max. 410...
- Page 16 Criminology General criminological Crime labs, research and law enforcement examinations, evidence and clues In addition, the high-performance Leica M125, M165 C, M205 C and M205 A stereomicroscopes are capable of meeting the most stringent requirements in many other applications. www.leica-microsystems.com...
