Summary of Contents for Leica M320

  • Page 1 Leica M320 User Manual 10 718 878 - version 01...
  • Page 2 Thank you for deciding in favor of a leica surgical microscope system. For valuable information about leica Microsystems products and services and the address of your nearest leica representative, please visit our website: www.leica-microsystems.com leica Microsystems (schweiz) aG Medical division...

  • Page 3: Table Of Contents

    M320 / Ref. 10 718 878 / version 01 inTRoducTion ..............1 Basics .

  • Page 5: Introduction

    The leica surgical microscope may be used only in closed rooms and must be placed on a nOTE solid floor or attached to a strong wall or ceiling.

  • Page 6: Instructions

    Microsystems (schweiz) aG. - The influence on other devices by the leica M320 surgical microscope has been tested in accordance with en 60601-1-2. The system passed the emissions and immunity test. The standard preventive measures and safety regulations pertaining to electromagnetic and other radiation have to be observed.

  • Page 7: Directions For The Operator Of The Instrument

    M320 / Ref. 10 718 878 / version 01 diRecTions FoR THe oPeRaToR oF THe insTRuMenT - Follow the user Manual. - Follow the instructions given by your employer regarding the organization of work and safety at work.

  • Page 8: Controls

    conTRols sTands nOTE To assemble the stand, note the installation instructions provided. Rolling floor stand (F12), Rolling floor stand, short Wall stand (W12) ceiling mount (c12) long swing arm swing arm standard for operating manual Floor stand/baseplate (FP12) Table stand with terminal Wall stand (lW12) Table stand with plate (TP12) (Tc12)

  • Page 9: Swing Arm And Horizontal Arm

    M320 / Ref. 10 718 878 / version 01 sWinG aRM and HoRizonTal aRM integrated tilt switch inFO The integrated tilt switch is not available for models Tc12, TP12 and lW12. swing arm and horizontal arm Move the swing arm upwards.

  • Page 10: Optics Carrier

    conTRols oPTics caRRieR inFO caps for magnification changer are steam- or gas-sterilizable. Magnification changer, illumination control for Filter and diaphragm controls Types of counterweight for both sides, increments: illumination intensity. for white light, orange filter balancing when many 6.4, 10, 16, 25, 40× and spot illumination.
  • Page 11 M320 / Ref. 10 718 878 / version 01 BRake knoBs/aRTiculaTion BRakes articulation brake lever for locking the vertical Joint for balancing articulation brake articulation brake position articulation brake (lW12, TP12, Tc12) Tilt brake Rotary brake (inclined version)
  • Page 12 conTRols connecTions Brake knob for setting the Main switch Power socket Port for HdMi/usB cable articulation brakes...
  • Page 13 M320 / Ref. 10 718 878 / version 01 insTallinG THe accessoRies CaUTiOn inFO installing the accessories, for Risk of injury from downward example, ergonoptic dent. movement of the swing arm! install any other accessories Before installing accessories, in a similar manner.
  • Page 14 accessoRies Handles 4.3.1 InstallIng and remOvIng the frOnt handle nOTE inFO Gray handle sleeves are installing the front handle steam- or gas-sterilizable. before the rest of the White handle sleeves can be accessories. disinfected. screw on the handle sleeve insert until the handle sleeve Push the knob and release holder.
  • Page 15 M320 / Ref. 10 718 878 / version 01 eRGonoPTic denT inFO improves ergonomics at certain working positions: Turning range 45° with 180° binocular tube. ergonoptic dent: optical For installation, see "4.1 extension for more installing the accessories".
  • Page 16 accessoRies oBJecTives inFO Fixed and fine objectives available in various focal lengths. Remove the cover from the screw in the objective. Turn the fine focusing optics carrier. objective for fine focus. PRoTecTive Glass inFO The protective glass is used to protect the objective.
  • Page 17 M320 / Ref. 10 718 878 / version 01 BinoculaR TuBes Binocular tube 5° - 25° inclined binocular tube Binocular tube, 180° variable straight binocular tube Binocular tube, variable 30° - 150° eyePieces inFO Possible eyepieces: - 10× eyepiece, standard (aside from with straight tube 12.5×)
  • Page 18 accessoRies 4.10 adaPTeR nOTE The microscope is not balanced. To prevent it from tipping over, tighten the articulation brakes. install the stereo adapter. Fit the beam splitter. install the stereo attachment Fit the binocular tubes. For 50/50 % or for second observer on the 70/30 % observation.

  • Page 19: 4.12 Installing The Drape

    M320 / Ref. 10 718 878 / version 01 4.11 MounTinG sTeRile coMPonenTs CaUTiOn inFO do not install the sterile danger of infection! components until shortly avoid touching the sterile before the operation. components. allow sufficient free space.

  • Page 20: 4.13 External Orange Filter

    accessoRies 4.13 exTeRnal oRanGe FilTeR inFO nOTE Filters out the parts of the light For installation, refer to the spectrum that cause rapid separate assembly curing of dental composite. instructions provided. external orange filter: additional accessory for dentistry.

  • Page 21: Settings

    M320 / Ref. 10 718 878 / version 01 BalancinG THe sWinG aRM Remove the screw. Remove the side cover. Remove the screws. set the desired position. Fasten the screws. Four different positions can be set. Refit the side cover.

  • Page 22: Transporting The Microscope

    seTTinGs TRansPoRTinG THe MicRoscoPe CaUTiOn Risk of injury from outward movement of swinging arm! Transport the microscope in transport position. Place swing arm in a horizontal Turn the lever for locking the Turn the optics/microscope Tighten the articulation position. vertical position. carrier towards the outside.
  • Page 23 M320 / Ref. 10 718 878 / version 01 nOTE CaUTiOn Possible damage of the cable! Risk of injury to feet! always pull the plug, never always push the instrument the cable. to move it; never pull it.

  • Page 24: Starting Up

    Hd transformers are available HdMi cables are available standard. from leica. from leica. Remove cover of the Plug the power cable into the Plug the HdMi cable and usB screw in the cover of the connect the HdMi cable to a horizontal arm.
  • Page 25 M320 / Ref. 10 718 878 / version 01 connect the usB cable to the connect the power cable. switch on the main switch. White led illumination on the computer. Main switch lights up in green. optics carrier lights up.

  • Page 26: Additional Settings

    seTTinGs addiTional seTTinGs 5.4.1 adJustIng the desIgn led IllumInatOr inFO There are five different dimming levels. switch on the main switch. Remove cover of the using a ball-point pen or screw in the cover of the Main switch lights up in green. horizontal arm.

  • Page 27: Adjusting The Illumination

    M320 / Ref. 10 718 878 / version 01 5.4.3 adJustIng the IllumInatIOn Warning danger of retinal damage! do not shine lights in anyone's eyes. set the desired illuminance. select the desired filter or diaphragm function: White light...
  • Page 28 seTTinGs 5.4.5 adJustIng the parfOcalIty wIth camera and mOnItOr inFO Parfocal means that the sharpness remains constant over the entire magnification range. adjust the diopter settings for both eyes separately and Place a piece of paper with Maximum magnification Bring the writing on the sheet accurately.
  • Page 29 M320 / Ref. 10 718 878 / version 01 inFO The writing should now remain sharp when you change the magnification. if it does not, repeat the procedure. Bring the writing on the sheet Turn out the eyecups to the into focus.
  • Page 30 seTTinGs 5.4.6 adJustIng the parfOcalIty wIthOut camera and mOnItOr Personal diopter setting known: inFO Parfocal means that the sharpness remains constant over the entire magnification range. adjust the diopter settings for both eyes separately and set dioptric correction on accurately. eyepieces.
  • Page 31 M320 / Ref. 10 718 878 / version 01 Without looking into the Turn the dioptric correction set maximum magnification Turn out the eyecups to the look into the eyepieces. eyepieces, set the minimum on the eyepieces to "+5".

  • Page 32: Information

    video caMeRa inFoRMaTion 6.1.1 standard delIvery - Remote control - sd card (8 GB or similar) optional accessories: - usB (a-B) cable, 1.8 m - usB with Repeater cable, 10 m 6.1.2 requIrements - HdMi port: HdMi-capable screen or television set to the Hd ready (720 p) or Full-Hd (1080 p) standard.

  • Page 33: Sd Memory Card

    M320 / Ref. 10 718 878 / version 01 sd MeMoRy caRd inFO an sd memory card cannot be formatted in the video camera. Format it at a computer or external digital camera. The video camera is designed for sd memory cards up to 32 GB.

  • Page 34: Graphical User Interface

    video caMeRa 6.3.2 OvervIew Perform white balance adjustment save still image to sd card Thumbnail mode / live view mode Perform remote control pairing arrow keys for navigation enter / exit camera Menu start / stop video recording Freeze live view / pause video show / hide information menu 10 arrow keys for navigation 11 ok / confirm...
  • Page 35 M320 / Ref. 10 718 878 / version 01 6.4.2 cOlOr (whIte balance) inFO Manual White Balance (recommended) use neutral white or gray color chart for manual white balance adjustment. Manual white balance can be set by: 1.
  • Page 36 video caMeRa 6.4.3 eXpOsure Manual exposure coloR exP Mode Manual select "Manual" for manual exposure. correct the values for "exPosuRe", "Gain", and "GaMMa". exPosuRe exPosuRe ResoluTion Gain seTuP caMeRa BRiGHTness seTuP useR GaMMa 0.40 seT FilenaMe no Mask automatic exposure (Recommended) coloR exP Mode auTo...
  • Page 37 M320 / Ref. 10 718 878 / version 01 inFO no Mask The exposure is automatically adjusted based on the entire image seen on the screen. Grid The exposure is automatically adjusted based on the grid(s) selected.
  • Page 38 video caMeRa 6.4.4 resOlutIOn live select the resolution for live view: coloR live Hd 1080-25 (16×9 mode) exPosuRe caPTuRed 10.0MP-JPG Hd720p50, Hd720p60, Hd1080p25, Hd1080p30, Hd1080i50, Hd1080i60. ResoluTion Movie Hd 1080-MP4 seTuP caMeRa (4×3 mode) 720p50-4×3,720p60-4×3,1080i50-4×3,1080i60-4×3. seTuP useR seT FilenaMe caPTuRed coloR live Hd 1080-25...
  • Page 39 M320 / Ref. 10 718 878 / version 01 use the tip of a ball-point pen (or a bent paperclip) to press the hidden button: inFO Pressing the button for the first time displays the current live image resolution on the Hd monitor.
  • Page 40 3 images will be captured consecutively seTuP caMeRa sHoW FilenaMe none seTuP useR FliP iMaGe 0° seT FilenaMe audio/BeeP leica loGo none ReseT caM PRess ok seT daTe/TiMe coloR caPTuRe Mode noRMal set the date/time and select the format: exPosuRe...
  • Page 41 M320 / Ref. 10 718 878 / version 01 sHoW daTe/TiMe coloR caPTuRe Mode noRMal exPosuRe seT daTe/TiMe PRess ok select the option for show date/Time: ResoluTion sHoW daTe/TiMe none live only: date/Time in live view only...
  • Page 42 FliP iMaGe 0° 0° original orientation seT FilenaMe audio/BeeP image is mirrored horizontally leica loGo none ReseT caM PRess ok image is mirrored vertically 180° image is rotated 180° audio/BeeP coloR...
  • Page 43 M320 / Ref. 10 718 878 / version 01 leica loGo coloR caPTuRe Mode noRMal exPosuRe seT daTe/TiMe PRess ok ResoluTion sHoW daTe/TiMe none seTuP caMeRa sHoW FilenaMe none seTuP useR FliP iMaGe 0° seT FilenaMe audio/BeeP...
  • Page 44 6.4.6 setup user (user-defIned settIngs) Menue coloR select color scheme for menu: coloR Menu coloR deFaulT “leica/las “ : red exPosuRe sHoW caPTuRe “deFaulT” : blue sHoW Menu 05 sec ResoluTion seTuP caMeRa lanGuaGe enGlisH seTuP useR seT FilenaMe...
  • Page 45 M320 / Ref. 10 718 878 / version 01 lanGuaGe coloR Menu coloR deFaulT exPosuRe sHoW caPTuRe ResoluTion sHoW Menu 05 sec seTuP caMeRa lanGuaGe enGlisH select the language. seTuP useR seT FilenaMe 6.4.7 set fIlename set the first 4 characters of the filenames for still captures and the video...
  • Page 46 video caMeRa 6.4.8 quIck menu File TRansFeR Mode Press to call up the “quick Menu”. quick Menu File TRansFeR select “File TRansFeR Mode”, and press inFO in “File TRansFeR Mode”, the sd card will appear as ‘Removable disk’ on the Pc, and files can be copied from the sd card and pasted to the local Pc.
  • Page 47 M320 / Ref. 10 718 878 / version 01 6.4.9 autOmatIc lIght cOntrOl (alc) Press to select the alc mode: no Mask “no Mask”, “GRid”, “s ciRcle”, “M ciRcle”, oR “l ciRcle” 6.4.10 capture mOde Press to select the capture mode:...

  • Page 48: Acquisition

    video caMeRa acquisiTion 6.5.1 Images 2. entering “File TRansFeR Press on the remote Files can be transferred to Pc Mode” and the sd card will control or on the video appear as “Removable disk” camera still images. 1. Removing the sd card from on the computer.
  • Page 49 M320 / Ref. 10 718 878 / version 01 inFO you can show and hide the timer using the key. 2. entering “File TRansFeR Mode” and the sd card will appear as “Removable disk” on the computer.
  • Page 50 video caMeRa RoTaTinG iMaGe Press to return to live Press to rotate the image To rotate the image, press view. counter clockwise. to enter the rotation menu. Press to rotate the image clockwise. zooMinG iMaGe Press to enlarge the still image.
  • Page 51 M320 / Ref. 10 718 878 / version 01 6.5.4 vIewIng vIdeOs navigate by using the arrow Press to forward the video. Press to return to live view. Press to enter thumbnail keys. Press to rewind the video.
  • Page 52 video caMeRa 6.5.6 paIrIng remOte cOntrOl inFO inFO Remote control pairing allows in order to achieve successful the camera to only responds pairing and avoid pairing by to the one specific remote mistake, the second step control, which had been must be performed within paired to the camera 4 seconds.

  • Page 53: Taking The Surgical Microscope Out Of Operation

    TakinG THe suRGical MicRoscoPe ouT oF oPeRaTion leica M320 / Ref. 10 718 878 / version 01 nOTE Possible loss of data! Before decommissioning the surgical microscope, end the video recording procedure. Bring the surgical microscope switch off the surgical...

  • Page 54: Care And Maintenance

    (package of 10) 10448280 Protective objective glass, leica M720, Tropical environment/fungus complete, sterilizable leica Microsystems employs certain safety precautions in its manufacturing techniques and 10446469 Protective objective glass, materials. other preventive measures include: leica M680/Fl400 - keep optical parts clean.

  • Page 55: Changing Fuses

    Cleaning needed: water, detergent, spirits, microfiber cloth The leica M320 surgical microscope is maintenance-free. To ensure operational safety 1. Flush the surface with running water (<40 °c), using a little detergent if necessary. and reliability, leica Microsystems (schweiz) aG recommends taking the precaution of 2.

  • Page 56: Brake Knobs/Articulation Brakes

    - Balance system/swing arm. see "5.1 malfunction that is not Balancing the described here, contact swing arm" your leica representative. interference from light Turn the protective glass, must be at an reflections. oblique angle relative to the work surface. streaks in the image.
  • Page 57 M320 / Ref. 10 718 878 / version 01 electrical data optical data objective f = 250 mm Power socket eyepiece Total magnification (mm) Field of view Ø (mm) stand F12, W12, c12, FP12, centrally located on the control unit Tc12, TP12, lW12 100-240 v ac (±10 %), 50/60 Hz...

  • Page 58: Handles

    601.1-M90. video accessories - electromagnetic compatibility iec/60601-1-2; en/60601-1-2. - according to sqs certificate, leica Microsystems (schweiz) aG, Leica M320 FULL HD Video & Photo Camera Medical division has a management system which corresponds to the...
  • Page 59 Manual). not intended for ophthalmology. The leica F12 stand is not intended to be moved down steps of more than 20 mm in height. To move the surgical microscope over thresholds of 20 mm, the wedge (arrow) included in the packaging can be used.
  • Page 60 Working range Leica M320 F12 long swing arm Leica M320 short swing arm Leica M320 W12 Leica M320 C12 (standard) Max. extension range 1775 mm 1455 mm 1775 mm 1775 mm 800 mm 300 mm 800 mm 800 mm Travel range (up/down) 608×608 mm...
  • Page 61 M320 / Ref. 10 718 878 / version 01 Leica M320 FP12 Leica M320 TC12 Leica M320 TP12 Leica M320 LW12 Comment 1775 mm 1455 mm 1455 mm 1455 mm Fully stretched for the inclined version 800 mm...
  • Page 62 sPeciFicaTions dimensions (in mm)
  • Page 63 The leica M320 surgical microscope is intended for use in the electromagnetic environment specified below. The customer or the user of the leica M320 surgical microscope should assure that it is used in This "Guidance and manufacturer's declaration" document is based on en 60601-1-2: 2007.
  • Page 64 RF transmitters, an electromagnetic site survey should be considered. if the measured below. The customer or the user of the leica M320 surgical microscope should assure that it is used in field strength in the location in which the leica M320 surgical microscope is used exceeds the such an environment.
  • Page 65 M320 surgical microscope can lead to elevated electromagnetic emissions or reduced interference resistance. The leica M320 surgical microscope may not be used in direct proximity of other devices. if it is necessary to operate it in the vicinity of other instruments, the instrument should be monitored to ensure that it functions properly in this arrangement.
  • Page 66 +65 6773 0628 10 718 878en/01 • Copyright © by Leica Microsystems (Schweiz) AG, Medical Division, CH-9435 Heerbrugg, 2013 • Printed – X.2013 – Data preparation by galledia • Subject to change. LEICA and the Leica Logo are registered trademarks of Leica Microsystems IR GmbH.
