Related Manuals for Gefen GTB-HD4K2K-444-BLK
Summary of Contents for Gefen GTB-HD4K2K-444-BLK
- Page 1 Application Guides 4K Ultra HD HDMI Extenders, Splitters & Matrixes • KVM Over IP • Wireless Extenders for HDMI...
- Page 2 Eight in. Route Eight 4K Ultra HD...
- Page 3 Eight Out. Sources to Eight Displays Features: • Compact, wall-mountable solution • Intuitive, easy-to-use web server • Simplified IP configuration through Gefen Syner-G™ software • Part of the complete line of Gefen 4K Ultra HD products...
-
Page 4: Table Of Contents
Contents Extenders ..................... 5 Application 1 - 4K Ultra HD Extender for HDMI with POL, 2-Way IR, .......... 5 Application 2 - 4K Ultra HD ELR Extender for HDMI with 2-Way IR, RS-232, ....... 6 Application 3 - 4K Ultra HD ELR-POL Extender for HDMI with 2-Way IR, RS-232, Ethernet ..7 Application 4 - Using Splitters &... -
Page 5: Extenders
The illustration shows a typical application for a Gefen 4K Ultra HD Extender. This application features the Gefen GTB-HDBT-POL-BLK 4K Ultra HD Extender. The 4K Ultra HD source is connected to the Sender via HDMI Cable. 4K Ultra/4K Cinema HD video, LPCM 7.1 channel audio, Dolby ® TrueHD, Dolby Digital ®... -
Page 6: Application 2 - 4K Ultra Hd Elr Extender For Hdmi With 2-Way Ir, Rs-232
Gefen 4K Ultra HD Extenders Application 2 - 4K Ultra HD ELR Extender for HDMI with 2-Way IR, RS-232, 4K up to 330' (100m), 1080p Full HD up to 495' (150m) 4K ULTRA HD SOURCE 4K ULTRA HD DISPLAY ULTRA HD SOURCE... -
Page 7: Application 3 - 4K Ultra Hd Elr-Pol Extender For Hdmi With 2-Way Ir, Rs-232, Ethernet
Gefen 4K Ultra HD Extenders Application 3 - 4K Ultra HD ELR-POL Extender for HDMI with Ethernet, 2-Way IR, RS-232, 4K up to 330' (100m), 1080p Full HD up to 495' (150m) 4K ULTRA HD SOURCE 4K ULTRA HD DISPLAY... -
Page 8: Application 4 - Using Splitters & Extenders For Remote Display Clusters With Ip Control
HDMI Cable 4K UHD SOURCE This application shows how to incorporate Gefen splitters and extenders to create a 4K Ultra HD distribution system with remote 4K Ultra HD display clusters and IP (and/or RS-232/2-way IR) control for Smart TVs or other IP, RS-232 and IR controlled devices. -
Page 9: Settings
Gefen 4K Ultra HD Extenders Settings GTB-HDBT-POL-BLK The GTB-HDBT-POL-BLK is designed for fast, clean installation and stable, reliable performance. Just hook it up and it's ready to go! GTB-UHD2IRS-ELRPOL-BLK Long Reach Mode - In the ON position, resolutions up to 1080p Full HD can be extended to a maximum distance of 495 feet (150m). -
Page 10: Connections
Technology the viewing area via IR Remote and IR control from an automation system or base • Gefen POL (Power Over Line) sends power station to control the display or other devices from the Sender to the Receiver over the... - Page 11 Technology • No loss of video signal quality or multi- channel audio content over extended run • Gefen POL (Power Over Line) sends power from Sender to Receiver over same CAT5e/6 • Bi-directional IR allows source control from cable as HDMI signal...
- Page 12 Gefen 4K Ultra HD Extenders Connections EXT-UHD-CAT5-ELRPOL S EXT-UHD-CAT5-ELRPOL R Power/Status Locking Power/Status Locking Power HDMI In RS-232t Power Power HDMI Out RS-232t Power Power 24V DC Link HDMI In 24V DC Link HDMI Out RS-232 RS-232 EXT-UHD-CAT5-ELRPOLS EXT-UHD-CAT5-ELRPOLR Link...
-
Page 13: Splitters
4K UHD SOURCE 4K Ultra HD SOURCE The illustration shows the most basic application for a Gefen 4K Ultra HD Splitter. This application features a Gefen GTB-HD4K2K-142C-BLK two-way splitter distributing a single 4K Ultra HD source to two 4K Ultra HD displays. -
Page 14: Application 2 - Two-Way Splitters Daisy-Chained (10 Displays)
Each 'split' in a daisy-chain or cascade system (page 4) is called a 'layer'. The maximum number of layers for Gefen GTB 4K UHD Series Splitters is ten. The maximum number of displays for this application is ten. For more displays, daisy-chain four-way or eight-way splitters, (next page) or use just about any combination of two, four and eight-way splitters to accommodate the number of displays needed to show a single source. -
Page 15: Application 3 - Four-Way Splitters Daisy-Chained (31 Displays)
This application is also easy to design and install, and the four-way splitters will allow connection of up to 31 displays. If more displays are required, Gefen GTB-HD4K2K-148C-BLK eight-way splitters can be configured in a similar configuration with each splitter feeding up to seven displays, with the last splitter being able to feed up to eight displays, for a total of up to 71 displays. -
Page 16: Application 4 - Four-Way Splitters Cascaded (124 Displays)
The enlarged detail shows how each of the 'sub' splitters would then feed up to four displays. In the same configuration, Gefen GTB-HD4K2K-148C-BLK eight-way splitters, would net a total of 224 displays. But what do we do when the displays are needed in locations farther than the typical, even daisy-chained runs... -
Page 17: Application 5 - Using Splitters & Extenders For Remote Display Clusters With Ip Control
4K Ultra HD display clusters and IP control for Smart TVs or other IP controlled devices. Inserting a Gefen EXT-UHD-CAT5-ELRPOL Extender between the Head-end Splitter and Remote Splitter can extend HDMI, Ethernet, two-way IR, RS-232 and Receiver Power up to 330' (100m) for 4K Ultra/4K Cinema (8-bit) or 1080p Full HD (12-bit Deep Color). -
Page 18: Settings
Gefen 4K Ultra HD Splitters Settings Gefen GTB-HD4K2K-142/4/8C-BLK Splitters feature three settings that help improve performance and stability in HDMI distribution systems. Out 3 Out 7 FST - Fast Switching Technology (FST) Fast Mode improves performance when Out 4 Out 8 connecting/disconnecting HD sources, and powering HD displays ON/OFF. -
Page 19: Connections & Controls
Gefen 4K Ultra HD Splitters Connections & Controls GTB-HD4K2K-142C-BLK GTB-HD4K2K-144C-BLK Mounting Holes Mounting Holes Locking HDMI Out Locking HDMI Out Out 1 Out 2 FST Mode Fast Slow Audio Mode 4K Ultra HD 1:2 Splitter Multi-ch for HDMI Audio EDID Mode... - Page 20 Gefen 4K Ultra HD Splitters GTB-HD4K2K-148C-BLK Mounting Holes Out 1 Out 5 Locking HDMI Out Out 2 Out 6 Out 3 Out 7 Out 4 Out 8 FST Mode Audio Mode Fast Slow 4K Ultra HD EDID Mode 1:8 Splitter...
-
Page 21: Matrixes
LEDs. All ToolBox Matrixes have a built-in IR Sensor on the front panel and also provide an IR EXT jack for connecting a Gefen IR Receiver (part no. EXT-IRN-EXTIRN, option, available separately) allowing IR control when the matrix is installed in a cabinet, equipment rack or closet. -
Page 22: Application 2 - 4X4 4K Ultra Hd Matrix For Hdmi
IP From Controller to LAN This application features the GTB-HD4K2K-444-BLK 4X4 4K Ultra HD Matrix. This model includes all of the same features as the 442 4x2 matrix with two additional outputs. Two additional rows of Output Status LEDs indicate current routing of available sources to connected displays. -
Page 23: Application 3 - 6X2 4K Ultra Hd Matrix With 2 Optical Audio Outs
IP From Controller to LAN This application features the Gefen GTB-HD4K2K-642-BLK. The 642 is a 6x2 4K Ultra HD matrix with all of the same features as the 442 an 444 with one great addition...two Optical Audio Outputs. These outputs provide 'zone' specific audio outs that can be used to add audio in residential or commercial applications. -
Page 24: Application 4 - 8X8 4K Ultra Hd Matrix For Hdmi
Gefen 4K Ultra HD Matrixes Application 4 - 8x8 4K Ultra HD Matrix for HDMI CAT-5e (or better) Cable 4K ULTRA HD DISPLAYS Source HDMI Outs Matrix HDMI Outs HDMI Cable to Matrix HDMI Ins to Display HDMI Ins RS-232 Cable... -
Page 25: Settings - Gtb-Hd4K2K-442/444/642-Blk
The LED indicators illuminate to show which input is routed to each output. Settings - GTB-HD4K2K-848-BLK The Gefen GTB-HD4K2K-848-BLK Matrix features a front panel LCD with push-button menu controls that route HDMI signals Power and select settings that help improve performance and ... -
Page 26: Web Interface
Web Interface All Gefen 4K Ultra HD Matrixes have a Web Server Interface that can be used for device setup and control. The Web Server Interface is divided into four main pages: Main, I/O Setup, Manage EDID and Configuration and include the following status windows, settings and controls: Main Page: Routing, Lock, I/O Status, Input Device Info and Display Info. -
Page 27: Connections & Controls
Gefen 4K Ultra HD Matrixes Connections & Controls GTB-HD4K2K-442-BLK GTB-HD4K2K-444-BLK Locking Audio EDID Locking Audio EDID Locking Locking HDMI In Mode Mode Mode HDMI Out Mode Mode Mode HDMI In HDMI Out In 1 In 3 Fast Slow In 1... - Page 28 Gefen 4K Ultra HD Matrixes GTB-HD4K2K-642-BLK GTB-HD4K2K-848-BLK Locking Audio EDID Locking Locking Main Lock Power Locking HDMI In Display Sensor HDMI Out HDMI In Mode Mode Mode HDMI Out (Side) (Side) Power Lock Out 1 Out 2...
-
Page 29: Kvm Over Ip
Audio Cable Mic Cable The illustration shows the typical connections on a Gefen KVM Sender and Receiver. This application has the Sender and Receiver setup in a standalone, direct connect configuration for KVM extension. This application does not require a network switch. KVM Senders and Receivers can also be configured for extension, switching, distribution and matrix over IP. -
Page 30: Application 2 - Kvm & Video Extension - Extended Range
Gefen KVM over IP Application 2 - KVM & Video Extension - Extended Range SENDER RECEIVER Example Total Distance: HD KVM over IP S HD KVM over IP R 990’ (300m) Additional Switches or SFP Modules Power Link Mode Reset... -
Page 31: Application 4 - Video Distribution - Daisy Chain
Gefen KVM over IP Application 4 - Video Distribution - Daisy Chain CAT-5e (or better) Cable HD SOURCE HDMI Cable IR Control Path HD SOURCE HDMI Source Control SOURCE UNIT’S IR REMOTE From Source From IR Remote Remote Control To Sender... -
Page 32: Application 5 - Kvm & Video Matrix Over Ip (Combined Mode)
CAT-5e (or better) Cable HDMI Cable The illustration shows the KVM Senders and Receivers configured in a simple matrix. The example shows Gefen KVM Senders and Receivers for HDMI 1080p Full HD, VGA, DVI and the HDMI/IR/RS-232 model. All Senders and Receivers are connected to a gigabit switch with 8K jumbo frame and multicast capabilities. -
Page 33: Application 6 - Kvm & Video Matrix Over Ip (Separate Mode)
Although the LANs can be completely separate, the EXT-CU-LAN will allow control of Gefen KVM and Video over IP devices from computers or third-party controllers on the ‘Control Network’ and computers or third-party controllers on the Video Network. -
Page 34: Ext-Cu-Lan
IP system control • Extend and matrix HDMI 1080p Full HD, DVI, VGA, USB 2.0, 2-way analog audio, RS-232 and IR over • Gefen KVM over IP products are ideal for controlling gigabit network multiple computers remotely, such as in edit bays, server rooms or classrooms •... -
Page 35: Connections & Controls
Gefen KVM over IP Connections & Controls EXT-CU-LAN Controller Matrix Control & Menu Navigation Buttons LCM Display IR Sensor Power LED Preset Preset ® Menu Lock Quick Mask Status Mask Presets Power Clear Clear Back Lock Menu Matrix Controller Menu Navigation Soft Buttons... - Page 36 Gefen KVM over IP Connections & Controls EXT-DVIKVM-LAN-L Power Link Mode Power Link Channel - Channel + Line Button Reset Reset Display Ch Select USB DVI KVM over IP S DVI KVM over IP R ® Switch Power Link Mode...
-
Page 37: Wireless Extenders For Hdmi
Wireless Extenders for HDMI EXT-WHD-1080P-SR Gefen’s 5 GHz short range Wireless HDMI In conference rooms, everyone gets a seat Extender transmits HDMI content up to 1080p at the table. For home theater, sharing Full HD from computers, game consoles and... -
Page 38: Features & Benefits
For longer range extension use the Gefen EXT-WHD-1080P-LR. The EXT-WHD-1080P-LR 5 GHz Extender provides wireless extension of HDMI up to 100 feet (30m). -
Page 39: Connections & Controls
Gefen Wireless Extenders for HDMI Connections & Controls RECEIVER TRANSMITTER HDMI Connector Mini-B Power/ USB Port Gefen Syner-G HDMI Out IR In Indicator (side) Not Used Tripod Connector Pairing/Info Power ® Button Button Power Indicator Info Button IR REMOTE Link... - Page 40 1800 S McDowell Blvd • Petaluma, CA 94954 • 800.472.5555 • Fax 707.283.5901 • gefen.com ©2016 Core Brands, LLC. All rights reserved. Gefen® is a registered trademark of Core Brands, LLC, a Nortek company. 042016...
