Inductive sensor
NI50U-CK40-VP4X2-H1141/3GD
Type designation
Ident no.
Rated switching distance Sn
Mounting conditions
Secured operating distance
Repeat accuracy
Temperature drift
Hysteresis
Ambient temperature
Operating voltage
Residual ripple
DC rated operational current
No-load current I
0
Residual current
Isolation test voltage
Short-circuit protection
Voltage drop at I
e
Wire breakage/Reverse polarity protection
Output function
Protection class
Switching frequency
Approval acc. to
Design
Dimensions
Housing material
Active area material
Electrical connection
Vibration resistance
Shock resistance
Protection class
MTTF
Packaging unit
Power-on indication
Switching state
Included in delivery
1 / 4 Hans Turck GmbH & Co.KG ñ D-45472 Mülheim an der Ruhr ñ Witzlebenstraße 7 ñ Tel. 0208 4952-0 ñ Fax 0208 4952-264 ñ more@turck.com ñ www.turck.com
NI50U-CK40-VP4X2-H1141/3GD
1514120
50 mm
Non-flush, flush
ð (0,81 x Sn) mm
ð 2 % of full scale
ð ± 10 %
ð ± 20 %, ð -25 °C v ï +70 °C
3...15 %
-30...+85 °C
For explosion hazardous areas see instruction
leaflet
10...65 VDC
ð 10 % U
ss
ð 200 mA
ð 15 mA
ð 0.1 mA
ð 0.5 kV
yes
ð 1.8 V
yes/ Complete
4-wire, Complementary contact, PNP
÷
0.25 kHz
ATEX test certificate TURCK Ex-10002M X
Rectangular,CK40
65 x 40 x 40 mm
variable orientation of active face in 5 directions
Plastic, PBT-GF20-V0, Black
Plastic, PA12-GF30, yellow
Connectors, M12 × 1
55 Hz (1 mm)
30 g (11 ms)
IP68
874 years acc. to SN 29500 (Ed. 99) 40 °C
1
2 × LEDs,Green
2 × LEDs, Yellow
Fixing clamp BS4-CK40, SC-M12/3GD
■ ATEX category II 3 G, Ex zone 2
■ ATEX category II 3 D, Ex zone 22
■ Rectangular, height 40 mm
■ Variable orientation of active face in 5
directions
■ Plastic, PBT-GF30-V0
■ High luminance corner LEDs
■ Optimum view on supply voltage and
switching state from any position
■ Factor 1 for all metals
■ Increased switching distance
■ Protection class IP68
■ Resistant to magnetic fields
■ Auto-compensation protects against
pre-attenuation
■ Partially embeddable
■ DC 4-wire, 10...65 VDC
■ Changeover contact, PNP output
■ M12 x 1 male connector
Wiring Diagram
Functional principle
Inductive sensors detect metal objects con-
tactless and wear-free. Due to the patented
multi-coil system, uprox®+ sensors have dis-
tinct advantages over conventional sensors.
They excel in largest switching distances,
maximum flexibility and operational reliability
as well as efficient standardization.
