Addi-Data APCI-3010 Technical Description page 65

APCI-3xxx (standard)
Functionality
Sample00
Counter
Sample01
Sample02
Sample03
Sample04
Sample00
Watchdog
Sample01
Sample02
Sample03
Sample
number
Shows all counter information
Initialisation of 1 counter without interrupt.
The user can trigger the counter by key press.
The user selects the counter he wants to test.
The user defines if the HW gate, the HW trigger and the HW
output are used.
Initialisation of 1 counter with interrupt.
The user can trigger the counter by key press.
The user selects the counter he wants to test.
The user defines if the HW gate, the HW trigger and the HW
output are used.
The user defines the interrupt mode
(asynchronous/synchronous)
Initialisation of all counters without interrupt.
The user can trigger the counter by key press.
The user selects the counter he wants to test.
The user defines if the HW gate, the HW trigger and the HW
output are used.
Initialisation of all counters with interrupt.
The user can trigger the counter by key press.
The user selects the counter he wants to test.
The user defines if the HW gate, the HW trigger and the HW
output are used.
The user defines the interrupt mode (asynchrone / synchrone).
Shows all watchdog information
Initialisation of 1 watchdog without interrupt.
The user can trigger the watchdog by key press.
The user selects the watchdog he wants to use.
The user defines if the HW gate, the HW trigger and the HW
output are used.
Initialisation of 1 watchdog with interrupt.
The user can trigger the watchdog by key press.
The user selects the watchdog he wants to use.
The user defines if the HW gate, the HW trigger and the HW
output are used.
The user defines the interrupt mode (asynchrone/synchrone).
Initialisation of all watchdogs without interrupt.
The user can trigger the watchdog by key press.
Standardsoftware
Description
65
