Standardsoftware
Functionality
Analog
56
- Scan mode:
- Delay mode: Not used/Mode1/Mode2
- Delay timing:
b_ADDIDATA_StartAnalogInputSequenceAcquisition
b_ADDIDATA_ConvertDigitalToRealAnalogValueSequenceAcq
uisition
b_ADDIDATA_GetSequenceAcquisitionCounter
b_ADDIDATA_StopAnalogInputSequenceAcquisition
b_ADDIDATA_ReleaseAnalogInputSequenceAcquisition
b_ADDIDATA_GetAnalogInputHardwareTriggerInformation
Return:
- High-/Low level selectable
- Can be used for auto refresh, SCAN and sequence
- Max. trigger counter is 65535 (16-bit)
- One shot trigger mode available
- Single cycle trigger mode available
- X-Zcycle trigger mode available.
b_ADDIDATA_EnableDisableAnalogInputHardwareTrigger
Available parameters:
- Level: High/Low
- Action: Auto refresh/SCAN/sequence
One shot
Single cycle
x cycles
b_ADDIDATA_GetAnalogInputHardwareTriggerStatus
b_ADDIDATA_GetAnalogInputSoftwareTriggerInformation
Return:
- Can be used for auto refresh, SCAN, sequence
- One shot trigger mode available
- Single cycle trigger mode available
- X cycles trigger mode available
Available parameters:
- Action: Auto refresh/SCAN/sequence
One shot
Single cycle
x-cycles
b_ADDIDATA_GetAnalogInputSoftwareTriggerStatus
b_ADDIDATA_GetNumberOfAnalogOutputs
APCI-3xxx (standard)
Function name
1 to 65535 for ms
X cycle/ continuous
µs/ms
