Elko RFTC-50/G Manual

Programmable temperature controller
Hide thumbs Also See for RFTC-50/G:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction Manual
Programmable temperature
controller
E
E
N
N
°C
RFTC-50/G

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RFTC-50/G and is the answer not in the manual?

Questions and answers

Related Manuals for Elko RFTC-50/G

Summary of Contents for Elko RFTC-50/G

  • Page 1 Programmable temperature controller °C RFTC-50/G...

  • Page 2: Table Of Contents

    Battery replacement ..................Description of device ..................Description of display .................. Description of control................... Selecting the heating mode................. Setting the temperature for manual mode ..........Entering the programming menu..............Entering the settings menu................Example of programming the RFTC-50/G ........... - 2 -...

  • Page 3: Warning

    Warning Instruction manual is designated for mounting and also Control is designated only for mounting in interiors. for user of the device. It is always a part of its packing. Devices are not designated for installation into exteriors Installation and connection can be carried out only by and humid spaces.

  • Page 4: Characteristics

    Characteristics - the temperature controller RFTC-50/G is used as a simple solution for controlling temperature in a room or the home - The RFTC-50/G is a programmable temperature controller with the option of setting a weekly program, which offers two...

  • Page 5: Technical Parameters

    Technical parameters Supply voltage: 2 x 1.5V bat. AAA Battery life: up to 1 year (depending on number of controlled actuators) Temperature offset: 2 buttons Temperature offset range: ± 5 °C Display: LCD, characters Backlight: Yes, active - blue Transmission/function indicator: symbols Temperature measurement input: 1x internal sensor...

  • Page 6: Battery Replacement

    Battery replacement Prior to first assembly, remove the moldings in the frame (see image) and peel off the protective film from the display. After inserting the °C batteries, all features for controlling the display function illuminate for 2 seconds, then the FW version is dis- played in the upper row.

  • Page 7: Description Of Device

    Description of device Day of the week Current time Circuit status Heating mode °C Current temperature Control button ^ Control button Hidden button - 7 -...

  • Page 8: Description Of Display

    Description of display Display of the day of the week Current time in selected format 12/24 Automatic mode Prog Auto - output switched on when selecting heating - Setting the time function - locking the menu item or program °C - output switched on when selecting cooling - manual mode °F...

  • Page 9: Description Of Control

    Description of control Button functions for controlling: - short press of buttons (< 2 s) - switching menu items, changing value °C long button press (> 2 s) - unlocking the menu item or time program for changing - confirmation of changed value after setting and locking of the menu item or program long button press (>...

  • Page 10: Selecting The Heating Mode

    Selecting the heating mode Auto °C - Auto - automatic mode, - „OFF“ - thermostat swit- - symbol - manual mode, - symbol - vacation the thermostat regulates to ched off, when selecting the the thermostat regulates to mode, the thermostat a temperature based on the function „heating “...

  • Page 11: Setting The Temperature For Manual Mode

    Setting the temperature for manual mode °C At the default display, briefly press the button . In the upper row, the indication „t °C“ is displayed and in the lower row the current selected temperature flashes. By short presses of the buttons , you will change the value by an increment of 0.5 °C.

  • Page 12: Entering The Programming Menu

    Entering the programming menu °C °C - „StA“ - time of start of - „ECO“ - setting the the program step, range reduced temperature, regu- 12:00 a.m. - 11:50 p.m., lation to this temperature increment 10 minutes is performed in the „Auto“ mode, outside the set time segments - „DAYS“...
  • Page 13 - only possible from the default display by pressing and holding the middle button - the display indicates „ProG“ - by short presses of the buttons , you can toggle between display „ProG“ and „SEt“ °C - by pressing and holding the button you select entry into the setting of time programs („ProG“) or into the menu („SEt“) - „End“...

  • Page 14: Entering The Settings Menu

    Entering the settings menu °C °C - „rF-A“ - the number - 1,2,3,4 - according to - „OFS“ - offset of the of controlled actuators the number of controlled temperature sensor, of the type RFSA-6x or actuators there are available range -5.0 to +5.0 °C, RFSTI-11B - range 1 - 4 1 - 4 of the following items,...
  • Page 15 °C - „bLt“ - intensity of - „HYS“ - setting the display back lighting hysteresis of heating/ „OFF, 1 - 10“ cooling, range 0.2 to 5.0 °C, step 0.2 °C - „FCE“ - selection of function heating/ cooling („HEAt “ / „CooL“ - „For“...
  • Page 16 °C °C - „OFF“ - setting the - „1.1.12“ - setting data. First the - setting the time - first - „St“ - Transition of summer - Setting the tempe- non-freezing temperatu- year is set (range 12 - 99, meaning hours are set followed by winter time (daylight rature and time for...
  • Page 17 °C °C - „FL-H“ - setting the - „FL-L“ - setting the mini- - „Corr“ - correction of time max. temperature for mum floor temperature**** deviation, sets the number underfloor heating *** of seconds for 10 days, range ± 99 *** - OFF - floor temperature function is switched off, the actuator(s) of the type RFSA-6x is(are) controlled - range 20 - 35 °C, floor temperature function is switched on, the actuator(s) of the type RFSTI-11B is(are) controlled (with date of manufacture from 03/2013)

  • Page 18: Example Of Programming The Rftc-50/G

    Example of programming the RFTC-50/G Example of settings for actuator RFSA-6x, RFSC-61 and RFSTI-11B °C °C °C - 18 -...
  • Page 19 Example for 1 actuator type RFSTI-11B with RF address 001234 with hysteresis of 0.6°C, heating function, time format 24 hr., daylight savings time switched off, non-freezing temperature set to 7 °C, maximum floor temperature 28 °C, °C minimum floor temperature 21°C, time correction 0. °C °C °C...
  • Page 20 ELKO EP, s.r.o. Palackého 493 | 769 01 Holešov | Všetuly,CZ, tel.: +420 573 514 211 | fax: +420 573 514 227 elko@elkoep.com | www.elkoep.com 4475-02VJ-007 Rev.: 1...
