- Page 1 SmartSensor Climate Wireless Device User Guide Commissioning instructions for the ELKO Smart system, devices and app. 02/2023 www.elko.no...
- Page 2 Legal Information The ELKO brand and any trademarks of ELKO AS and its subsidiaries referred to in this guide are the property of ELKO AS or its subsidiaries. All other brands may be trademarks of their respective owners. This guide and its content are protected under applicable copyright laws and furnished for informational use only.
-
Page 3: Table Of Contents
Table of Contents Safety information ..................4 SmartSensor Climate Wireless ..............5 For your safety ...................5 About the device..................5 Installing the device ..................6 Pairing the device ..................6 Pairing device manually.................6 Pairing device with auto scan..............9 Configuring the device ................10 Changing the device icon ..............10 Renaming the device ................ -
Page 4: Safety Information
Safety information Safety information Important information Read these instructions carefully and look at the equipment to become familiar with the device before trying to install, operate, service, or maintain it. The following special messages may appear throughout this manual or on the equipment to warn of potential hazards or to call attention to information that clarifies or simplifies a procedure. -
Page 5: Smartsensor Climate Wireless
ELKO SmartHUB, it reports the temperature and humidity data to the ELKO SmartHUB. The sensor triggers other ELKO devices (such as turning on an air conditioner if the temperature is high or turning on an exhaust fan if the humidity is high) through automation. -
Page 6: Installing The Device
SmartSensor Climate Wireless. Pairing the device Using the ELKO Smart app, pair your device with the ELKO SmartHUB to access and control the device. You can either add the device manually or do an auto-scan to pair it. Pairing device manually To pair the device manually: 1. - Page 7 SmartSensor Climate Wireless 4. To pair the device with an install code, tap Add Device with Install Code to display the slide-up menu. Select any one of the options (B): – Scan Install Code - you can scan the device for the install code.
- Page 8 SmartSensor Climate Wireless 7. In the app, select Confirm LED is flashing orange and tap Start configuration (C). Cancel How to pair device Short-press function key 3 times. The app displays the progress of connecting the device. 8. After a few seconds, a solid green LED indicates that the sensor is successfully paired.
-
Page 9: Pairing Device With Auto Scan
NOTE: If you have multiple hubs, do Step 4 or proceed to Step 5. 4. Tap Select hub and select the ELKO SmartHUB from the slide-up menu. 5. Short press the setup/reset button 3 times (< 0,5 s) and wait for a few seconds until the device search is complete. -
Page 10: Configuring The Device
Configuring the device Changing the device icon You can change the device icon using the ELKO Smart app. 1. On the Home page, select the device for which you wish to change the icon. 2. At the top-right corner of the screen, tap 3. -
Page 11: Renaming The Device
Name Save Changing the device location You can change the device location using the ELKO Smart app. 1. On the Home page, select the device for which you wish to change the location. 2. At the top-right corner of the screen, tap 3. -
Page 12: Removing The Device
SmartSensor Climate Wireless Removing the device You can remove a device from the device list using the ELKO Smart app, To remove the device: 1. On the Home page, tap All devices > Temperature Humidity Sensor. 2. Tap to display more details. -
Page 13: Resetting The Device
SmartSensor Climate Wireless Resetting the device You can reset the sensor to factory default manually. To reset the sensor: 1. Remove the sensor from the base plate by sliding it upwards. 2. Short-press the function key 3 times (<0.5 s) and then long-press the function key once (>10 s), the LED blinks red after 10 s, and then release the function... -
Page 14: Using The Device
History Checking the device history You can monitor the temperature and humidity changes by accessing the device history in the ELKO Smart app. To see the device history: 1. On the Home page, tap All devices > Temperature Humidity Sensor. -
Page 15: Creating An Automation
Creating an automation An automation allows you to group multiple actions that are usually done together, triggered automatically or at scheduled times. By using the ELKO Smart app, you can create automations based on your needs. 1. On the Home page, tap the 2. - Page 16 SmartSensor Climate Wireless 6. In the Add Condition menu, you can do either or all of the following options (C): – When weather changes- Select the various weather settings. – Schedule- Set the time and day. – When device status changes - Select the device and it’s function.
- Page 17 SmartSensor Climate Wireless 9. In the Add task menu, you can do either or all of the following options (H): – Run the device - Select the devices that you want to trigger. – Moment or Automation - Select the moment which you want to trigger or select the automation that you want to enable or disable.
- Page 18 SmartSensor Climate Wireless 3. Tap Add Condition > When device status changes > Temperature Humidity Sensor. 4. Tap Current temperature, set the temperature and condition and tap Next. TIP: You can set the temperature as 27 °C and the condition as > (greater than).
-
Page 19: Replacing The Batteries
SmartSensor Climate Wireless Editing an automation To edit an automation: 1. On the Automation tab, locate the automation you want to edit and tap 2. On the Edit page, you can tap each item (such as dimmer, shutter, delay, temperature, etc.) to change the settings. -
Page 20: Led Indications
SmartSensor Climate Wireless LED indications Pairing User Action LED Indication Status Press the function key 3 times LED blinks orangeamber, once per second. Pairing mode is active for 30 seconds. When pairing is completed, LED glows green for some time before turning Off. -
Page 21: Technical Data
SmartSensor Climate Wireless Technical Data Battery 3 VDC, CR2450 Battery life Up to 5 years (may vary based on the usage, frequency of firmware update and environment) Nominal power ≤90 mW IP rating IP20 Operating frequency 2405 – 2480 MHz Max. - Page 22 Trademarks This guide makes reference to system and brand names that are trademarks of their relevant owners. • Zigbee ® is a registered trademark of the Connectivity Standards Alliance. • Apple ® and App Store ® are brand names or registered trademarks of Apple Inc. •...
- Page 24 ELKO AS Sandstuveien 68, 0680 OsloPb 6598 Etterstad, 0607 Oslo Norway +47 67 79 39 00 support@elko.no www.elko.no As standards, specifications, and design change from time to time, please ask for confirmation of the information given in this publication. © 2023 – 2023 ELKO AS.
