KUHN GMD44 Operator's Manual

KUHN GMD44 Operator's Manual

Hide thumbs Also See for GMD44:

Advertisement

Table of Contents

GMD44 _760001 _xxxxxx
Last update
Release date: 17-01-2014 (17:20:45)
Revision index:
Printing date : 06-02-2014
GMD44_760001_xxxxxx
Page 1/95

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GMD44 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for KUHN GMD44

Summary of Contents for KUHN GMD44

  • Page 1 GMD44 _760001 _xxxxxx Last update Release date: 17-01-2014 (17:20:45) Revision index: Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 1/95...
  • Page 2 GMD44 _760001 _xxxxxx Machine view and glossary (Cutterbar) Mark Description Disk Disk with cone Knives Disk housing Swath shield holder Upper gear case Set of gearwheels Lower gear case Guard angle bracket Disk skid Wear skids Reinforcements Angles Printing date : 06-02-2014...
  • Page 3 Copyright 2012 KUHN S.A. Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 3/95...

  • Page 4: Safety Instructions

    GMD44 _760001 _xxxxxx Safety instructions Introduction The machine must only be operated, maintained and repaired by qualified persons who are familiar with the machines' operation and understand safety regulations and procedures for preventing accidents. The operator must follow the safety instructions in this manual and in the warnings posted on the machine.
  • Page 5 Before starting work, the operator must be familiar with all machine controls, handling devices and their functions. It is too late to learn once work has been started! Never let anyone operate the machine who is not trained to do so. Precautions to be taken before carrying out any operations on the machine ../../Illustrations/59900400-34.eps.png Before leaving the tractor or before adjusting,...
  • Page 6 Tractor handling, stability, performance and braking efficiency are all affected by weight distribution, trailed or mounted implements, additional ballast and driving conditions. It is therefore of great importance that the operator exercises caution in every given situation. Drive speed must be adapted to ground conditions as well as to roads and paths.
  • Page 7 Gross weight and weight per axle Check that the tractor's authorized gross weight as well as its lift capacity and maximum weight per axle are not exceeded. The front axle load (1) must never, under any circumstances, be less than 20% of the tractor's unladen weight.
  • Page 8 Always keep to the legal speed limit for driving a tractor-machine assembly on public roads. Precautions when coupling Before attaching the machine, make sure that it cannot accidentally start moving (chock the wheels) and that the parking stand is in the right position.
  • Page 9 accidents. Regularly check the hydraulic hoses. In case of normal wear, replace the hydraulic hoses every 5 years. Damaged or worn hoses must immediately be replaced. When replacing the hydraulic hoses, only use hoses with the specification recommended by the manufacturer of the machine. To locate a leak, use appropriate means.
  • Page 10 If the primary PTO shaft is equipped with a torque limiter or a free wheel, these must be fitted on the machine side. Ensure that the PTO shaft is always correctly fitted and locked into place. Before connecting the PTO shaft, ensure that the PTO speed (rotational frequency) and direction of rotation are in line with the machine manufacturer's recommendations.
  • Page 11 A hydro-pneumatic accumulator contains nitrogen under pressure (risk of suffocation in closed rooms). Repairs, maintenance or commissioning may only be carried out by competent persons. Wait for the accumulator to cool down before handling it. Only use nitrogen to precharge it. Depressurize the gas and fluid sides of the hydraulic accumulator before opening it.
  • Page 12 Do not solder, weld or use a blow torch near fluids under pressure or flammable components. For your own safety and for correct machine operation, only use original manufacturer parts. It is strongly recommended to have your machine checked by your Kuhn dealer after each season, especially tools and their attaching hardware.
  • Page 13 Immediately replace any worn, damaged or missing cutting tool or element. To do this, use the tool outfit supplied with the machine. For your safety, only use genuine KUHN parts ! Regularly check the condition of the protection covers. Immediatly replace any worn, damaged or missing cover.
  • Page 14 place. Keep all persons and animals away from the danger zone. Stay a safe distance from the Gyrorake when rotors are moving. Never work in reverse. After disengaging the PTO drive, cuttings tools can continue rotating for some time. Stay away from the machine until all moving parts have come to a complete standstill.
  • Page 15 Before engaging the pto drive, lower the shredder onto the ground. For your safety, only use genuine KUHN parts ! Regularly check the condition of the guard plates/covers. Make sure all the guards are in place. Keep all persons and animals away from the danger zone.
  • Page 16 GMD44 _760001 _xxxxxx Stability of the tractor-spreader unit (Appendix A EN 14017) Introduction The example refers to a solid fertilizer spreader mounted on a tractor. Due to the machine's mass and products contained in the hopper, the tractor-spreader unit can become unstable. In order to check the...
  • Page 17 [m] Distance between the center of the lower links and the center of gravity of the rear mounted equipment/rear ballasting combination See tractor operator's manual See price and/or equipment operator's manual To measure Copyright 2012 KUHN S.A. Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 17/95...

  • Page 18: Maintenance Plan

    GMD44 _760001 _xxxxxx Maintenance plan Cutterbar draining and refilling Lateral gearbox draining Copyright 2012 KUHN S.A. Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 18/95...

  • Page 19: Cutterbar Draining And Refilling

    GMD44 _760001 _xxxxxx Cutterbar draining and refilling 30 min Required equipment Preliminary operations Never use an oil of viscosity SAE90 in the cutterbar. Before draining oil, operate the machine for a few minutes so that the oil warms up. Operating procedure Main operations Step 1.
  • Page 20 Pour the correct oil quantity and quality through the opening of the filler plug. The oil must reach the lower edge of the filling hole. Clean and reinstall filler plug (1) and its washer. Replace if necessary. Copyright 2012 KUHN S.A. Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 20/95...

  • Page 21: Lateral Gearbox Draining

    GMD44 _760001 _xxxxxx Lateral gearbox draining 30 min Required equipment Preliminary operations Before draining oil, operate the machine for a few minutes so that the oil warms up. Operating procedure Main operations Step 1. The lateral gearbox is lubricated with 0.250.06 of SHELL SPIRAX extreme-pressure oil for mechanical transmissions with viscosity grade SAE 80W90 and API grade GL5.
  • Page 22 From the transport position: Lock and secure machine in this position. Place a container of sufficient capacity under drain plug. Remove filler plug (1) and its washer. Remove drain plug (2) and its washer. Allow oil to drain completely. Wait for dripping to stop. Place the machine in working position.
  • Page 23 From the working position: Remove breather plug (1). Clean and check breather plug for good functioning. Reinstall breather plug (1). Copyright 2012 KUHN S.A. Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 23/95...

  • Page 24: Parts Replacement

    GMD44 _760001 _xxxxxx Parts replacement Cutterbar Gearbox Copyright 2012 KUHN S.A. Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 24/95...
  • Page 25 GMD44 _760001 _xxxxxx Cutterbar Required equipment Specific tools Part no. 83450009 Bearing extractor. Bronze rod. Preliminary operations Cutterbar draining and refilling. Operating procedure Upstream operations Step 1. Remove disks Place a wooden wedge between two disks to stop them from rotating.
  • Page 26 Clean the nut case. Note the direction of the spring washer. Remove nut (1). Remove spring washer (2). On cone disks: Reinstall plug (1). Note the direction of the spring washer. Remove nut (2). Remove spring washer (3). Step 2. Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 26/95...
  • Page 27 Note direction of fender washer. Remove disk (1). Remove fender washer (2). For easier removal, use levers on either sides of the disk. Main operations Step 1. Parking Remove cutterbar from the chassis. Remove 4 bolts (1). Remove brackets (2). Remove side skids (3).
  • Page 28 Remove the 8 bolts (1) and nuts (2). Remove the gearbox (3). Remove the chock (4). Remove O-ring (5). Remove compensation volume (6). Remove wavy washer (7). Step 2. Remove disk guards Remove 2 bolts (1). Remove bolt (2) and nut (3). Note the number and position of the spacers.
  • Page 29 Step 3. Remove guard angle bracket Remove bolt (1) and nut (2). Remove 3 bolts (3). Remove guard angle bracket (4). Remove swath board holder (5). Step 4. Note position of mounting bolts, disk skids and reinforcements. sheet. Remove bolts and nuts . Remove the reinforcement brackets .
  • Page 30 To prevent damaging the threads and jamming the nylon bush on the bolt: Loosen mounting bolts (1) of a few turns, going from the cutter bar oustide towards the center. Remove the mounting bolts (1). Separate the half gearcases. Recover spacers (1). Remove lower gearcase o-ring (2).
  • Page 31 Note position of helical pinions. Drive helical pinions (1) out. Remove disk bearing housings. Remove 4 bolts (1). Removing disk housing (2). Remove o-rings (3) and (4). Step 7. Remove bearings (1) and (2) with a bearing extractor. Specific tools Part no. 83450009. Remove o-ring (3).
  • Page 32 Step 8. Remove intermediate gearwheels Note the position of the intermediate gearwheels. Remove intermediate gearwheel (1) using 2 crowbars or levers. Remove nylon bushes (1). Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 32/95...
  • Page 33 From 760001 to 786383. Remove shim ring (1). Remove bearing (2). Remove bearing (3). Remove spacer (4). Remove circlip (5). From 786384 to ..Remove snap rings (1) and (2). Remove bearing (3). sheet. Step 9. Remove drive shaft Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 33/95...
  • Page 34 Remove circlip (1). Remove drive pinion (2). Remove circlip (1). Remove bearing (2). Step 10. Replace all parts that are worn or damaged with KUHN original parts. Main operations Step 1. Fitting Clean components before reinstalling them. Printing date : 06-02-2014...
  • Page 35 Use appropriate tools to fit the bearings. Insert bearing (2) fully. Reinstall retaining ring (1). How to fit a retaining ring. Reinstall drive shaft (2). Reinstall retaining ring (1). Step 2. Reinstall disk bearing housings Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 35/95...
  • Page 36 Reinstall bearings with the protected part towards the outside of the disk housing. Insert lower bearing (1) until it bottoms. Replace o-rings (3) and (4). Reinstall disk housing (2). Reinstall the 4 bolts (1). Torque: 752. Step 3. Reinstall helical pinions (1). Respect left and right helical pinion fitting position according to the type of machine.
  • Page 37 Step 4. Reinstall disk housing upper bearings Reinstall O-ring (1). Reinstall spacers with the bevelled part downwards. Reinstall spacer (2). Reinstall oil seal (3). Insert bearing (4) fully. Step 5. Reinstall intermediate gearwheels From 760001 to 786383. Reinstall retaining ring (5). Reinstall spacer (4).
  • Page 38 From 786384 to ..Reinstall ball bearing (3). Reinstall snap rings (1) and (2). sheet. Before reinstalling the intermediate pinions, position helical pinions making sure to respect the disk synchronization. sheet. Position intermediate gearwheel flat part towards the half casing. Insert intermediate gearwheel using a hollow tube of diameter smaller than the inner bearing cage.
  • Page 39 Replace all nylon bushes (1). sheet. Step 6. Reinstall the half gearcases Reinstall spacers (1). Position o-ring (2) on lower half gearcase . Glue the 4 o-ring ends with quick setting glue. Position upper half casing over lower half casing. Reinstall 2 bolts on the ends to maintain half casings in position.
  • Page 40 Reinstall bolts (1). Give screws 2 or 3 preload turns by hand. Before tightening the bolts, reinstall temporarily several disks, rotate them by hand and check disk synchronization. Tighten screws (1) from the center outwards. Torque: 38280. Step 7. Guard angle bracket Reinstall swath board holder (5).
  • Page 41 Note position of mounting bolts, disk skids and reinforcements. sheet. Reinstall wear plates. Reinstall the reinforcement brackets . Reinstall bolts and nuts . Torque: 8.564. Step 9. Reinstall disk guards. Note the number and position of the spacers. sheet. Reinstall disk skid (4) and spacer (5). Reinstall bolt (2) and nut (3).
  • Page 42 Reinstall O-ring (5). Fit spacer (4). Reinstall wavy washer (7). Reinstall compensation volume (6). Reinstall angle gearbox (3). Reinstall the 8 bolts (1) and nuts (2). Torque: 1289. Reinstall side skid (3). Reinstall the 2 brackets (2). Reinstall the 4 bolts (1). Reinstall cutterbar on the chassis.
  • Page 43 Respect disk direction of rotation according to fitting of knives. On each knife, an arrow indicates the disk's direction of rotation. Make sure that the securing nut and bolt are in good condition and if necessary, replace them. Torque: 7.555. Position conical center of dust seal (1) at the bottom.
  • Page 44 Place a wooden wedge between two disks to stop them from rotating. Position conical center of spring washers at the top. Reinstall spring washer (2). Reinstall nut (1). Torque: 18133. Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 44/95...
  • Page 45 On cone disks: Reinstall spring washer (3). Reinstall nut (2). Torque: 18133. Reinstall plug (1). Reinstalling operations Step 1. Pour required oil quantity in the cutter bar Copyright 2012 KUHN S.A. Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 45/95...
  • Page 46 GMD44 _760001 _xxxxxx Cutterbar bearing Preliminary operations Bearings are precisely matched, do not invert inner races. Operating procedure Upstream operations Step 1. Remove gearwheel of intermediate wheel Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 46/95...
  • Page 47 Make a notch on the snap ring angle, close to its opening with a chisel. Step 2. Place intermediate gearwheel in a vise. Stop the snap ring from rotating by using locking pliers. Step 3. Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 47/95...
  • Page 48 Press on notch using a screwdriver to close the snap ring. Position a small screwdriver behind the snap ring to stop it from taking up its initial position. Position small screwdriver at 90 degrees with regardsto the first screwdriver. Step 4. Remove larger screwdriver.
  • Page 49 Lay pinion on its flat side. Remove bearing cage using a tube. Clean intermediate gearwheel. Step 2. Reinstall new bearing Insert bearing in its housing : Use an old bearing cage or an adequate bush Insert and tighten the unit in a vise or a press. Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 49/95...
  • Page 50 Position snap ring in intermediate gearwheel groove . Check that the snap ring functions properly by rotating it using a screwdriver. Copyright 2012 KUHN S.A. Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 50/95...
  • Page 51 GMD44 _760001 _xxxxxx How to fit a retaining ring Operating procedure Main operations Step 1. When fitting a retaining ring, position the small lug diameter on the plier side. Copyright 2012 KUHN S.A. Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 51/95...
  • Page 52 GMD44 _760001 _xxxxxx Assembly positioning of the helical pinions Mark Function Right helical drive pinion Left helical pinion Right helical pinion Copyright 2012 KUHN S.A. Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 52/95...
  • Page 53 GMD44 _760001 _xxxxxx Disk synchronization Before reinstalling the intermediate pinions, position helical pinions making sure to respect the disk synchronization. Position first helical pinion mark on (A-A) axis and the second helical pinion mark at 90 degrees with regards to (A-A) axis.
  • Page 54 GMD44 _760001 _xxxxxx Replacement of the Nylon bushes Inser nylon bush (1) manually. Use screw (1) and hammer (2) to fully insert nylon bush (3) delicately. Copyright 2012 KUHN S.A. Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 54/95...
  • Page 55 GMD44 _760001 _xxxxxx Gearbox Required equipment Preliminary operations Changing angle gearbox oil. Operating procedure Upstream operations Step 1. Remove the gearbox Remove cutterbar from the chassis. Remove 4 bolts (1). Remove brackets (2). Remove side skids (3). Printing date : 06-02-2014...
  • Page 56 Remove the 8 bolts (1) and nuts (2). Remove the gearbox (3). Remove the chock (4). Remove O-ring (5). Remove compensation volume (6). Remove wavy washer (7). Main operations Step 1. Parking Remove key (1). Remove 6 bolts (2). Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 56/95...
  • Page 57 Remove cover (1). Remove seal (2). Note number and position of shim rings. Remove spacer (1). Remove o-ring (2). Remove shim rings (3). Step 2. Remove 6 bolts (1). Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 57/95...
  • Page 58 Remove unit (1). Remove seal (2). Step 3. Note number and position of shim rings. Remove cover (1). Remove shim rings (2). Remove O-ring (3). Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 58/95...
  • Page 59 Remove bearings (1). Remove gearwheel (2) from shaft. Remove key (3). Step 4. Remove circlip (1). Remove o-ring (2). Remove circlip (3). Remove unit (4). Remove bearing (1). Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 59/95...
  • Page 60 Step 5. Check and clean breather plug (1). Step 6. Replace all parts that are worn or damaged with KUHN original parts. Main operations Step 1. Fitting Reinstall seal (1). Reinstall cover (2). Reinstall the 6 bolts (3). Torque: 644.
  • Page 61 Step 2. Reinstall ball bearing (1). Reinstall unit (4). Reinstall retaining ring (3). Reinstall oil seal (2). Reinstall retaining ring (1). How to fit a retaining ring. Step 3. Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 61/95...
  • Page 62 Knife not parallel to anvil. Reinstall gearwheel (2) on shaft. Reinstall bearings (3). Reinstall shim rings (4). Spacing principle. Reinstall unit (1). Reinstall shim rings (1). Spacing principle. Reinstall seal (2). Reinstall cover (3). Reinstall the 6 bolts (4). Torque: 644. Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 62/95...
  • Page 63 Step 4. Check that there is no longitudinal play on the shaft. Check that the shaft can be rotated by hand. If the shaft does not rotate, remove shim ring and repeat check. If the longitudinal play remains, add a shim ring and repeat check. Step 5.
  • Page 64 Step 6. Reinstall O-ring (5). Fit spacer (4). Reinstall wavy washer (7). Reinstall compensation volume (6). Reinstall angle gearbox (3). Reinstall the 8 bolts (1) and nuts (2). Torque: 1289. Reinstall side skid (3). Reinstall the 2 brackets (2). Reinstall the 4 bolts (1). Reinstall cutterbar on the chassis.
  • Page 65 Copyright 2012 KUHN S.A. Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 65/95...
  • Page 66 GMD44 _760001 _xxxxxx Spacers Operating procedure Main operations Step 1. Spacing principle Fit thickest spacer against smallest contact area. Fit the second thickest spacer against the largest contact area or the retaining ring. Position spacers betwen the two others. Copyright 2012 KUHN S.A.

  • Page 67: Hydraulic Diagrams

    GMD44 _760001 _xxxxxx Hydraulic diagrams Schematic diagram Copyright 2012 KUHN S.A. Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 67/95...
  • Page 68 GMD44 _760001 _xxxxxx Adjustment Assembly positioning of the helical pinions Replacement of the Nylon bushes Copyright 2012 KUHN S.A. Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 68/95...

  • Page 69: Component Test

    GMD44 _760001 _xxxxxx Component test Bolt and nut torque chart Spacers How to fit a retaining ring Fixing elements Copyright 2012 KUHN S.A. Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 69/95...
  • Page 70 GMD44 _760001 _xxxxxx Bolt and nut torque chart Tightening torque and assembly preload for metric-pitch standard or precision screws Tightening torque and assembly preload with v= 0,9 for metric-pitch standard or prevision screws ISO262 and ISO965-2. The values indicated correspond to standard steel nuts and bolts (ISO 898-1).
  • Page 71 ../../Illustrations/k0015496.jpg.jpg Copyright 2012 KUHN S.A. Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 71/95...

  • Page 72: Fixing Elements

    GMD44 _760001 _xxxxxx Fixing elements Operating procedure Main operations Step 1. Fixing elements Check the fixing elements: After hitting an obstacle. When replacing knives. At the beginning of each season. The fixing bolts should be changed in the following cases: When there is visible distortion.
  • Page 73 After having been removed 5 times. Check the condition of the fixing elements regularly and also the torque of the knife-fixing bolt. Torque nut to: 1289 Copyright 2012 KUHN S.A. Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 73/95...

  • Page 74: Technical Documentation

    GMD44 _760001 _xxxxxx Technical documentation Spare parts catalogue (9014168.18) Operator's manual (95011AUS) Copyright 2012 KUHN S.A. Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 74/95...
  • Page 75 GMD44 _760001 _xxxxxx Documentation charter Description of menus Description of safety decals Animation user guide SVG format illustration user guide Video user guide Browsing principle for trouble shooting sheets Copyright 2012 KUHN S.A. Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 75/95...

  • Page 76: Description Of Menus

    GMD44 _760001 _xxxxxx Description of menus Menus level 1 Menus level 2 Description Symbol Presentation Machine name Machine name meaning. Machine and Location and description of the identification plate equipment identification and equipment linked to the machine. Machine views and...
  • Page 77 Operating principle Operating procedures Machine use. Description of control elements Machine functions Description and functioning of the machine electric and hydraulic components; hydraulic circuits, electric... Additional information Torque chart Wiring harness diagram... Adjustments and Adjustments Operating procedures for the various machine checking adjustments.
  • Page 78 Safety instructions Kuhnitech operating Documentation charter. procedures Technical questions Information request or comment form on the technical content of the site. Copyright 2012 KUHN S.A. Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 78/95...
  • Page 79 GMD44 _760001 _xxxxxx Icons Sheet title Icons Description Standard sheet Standard Standard sheet Pre-delivery instructions Standard sheet Installing options Standard sheet Adjustment Standard sheet Control Standard sheet Maintenance Standard sheet Replacement Estimated number of persons and time Icons Risks Printing date : 06-02-2014...
  • Page 80 Time Persons Required equipment Icons Description Paint Specific tools Cleaning tools Clamping tools Electric measuring tools Measuring tools Electric repair tools Hammer Greasing tools Lifting gear Wrenches Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 80/95...
  • Page 81 Keys Torque wrench Cloth Screwdriver Safety Icons Description Hazardous gases Cutting of fingers Toxic substances Pollution Fire Explosion High pressure fluid - injection into body Entanglement - tedder rake Finger entanglement Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 81/95...
  • Page 82 Hand and arm entanglement - belt drive Projections Crushing of toes or foot - force applied from above Crushing of fingers or hands - force applied from side Crushing of hand Crushing of torso - Force applied from side Crushing of hand - force applied from above Crushing of whole body - Force applied from above Cutting of foot Cutting of fingers or hand...
  • Page 83 Drive Video SVG format illustration Link: Transfer to new sheet Download a PDF Download an executable New sheet Sheet update Copyright 2012 KUHN S.A. Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 83/95...
  • Page 84 GMD44 _760001 _xxxxxx Animation user guide To start the animation Click on Animation icon. Browsing Two browsing systems are used Buttons. Links. Buttons Button Example: Play button Description The buttons are composed of a yellow background and a central purple icon.
  • Page 85 Click on the Forward button to go to the next stage of the animation. Click on Return button to go to the previous stage of the animation. Click on PTO button to launch an action. Links Link Example: Mass symbol Description Links are always displayed in purple color.
  • Page 86 Example: Select button (1): The blue color indicates the current button position. The purple links are clickable (2): The purple links are clickable. (3): The grey link is inactive and non clickable. Example: Control box area selector (1): The color blue indicates the current position of the control box area selector.
  • Page 87 The wiring diagram animation is split in several stages. Each stage corresponds to a function (Masses also form a stage) . Operating principle: Description of electric wire connection: Zoom on the connector terminal of the machine wiring harness and the on the wire color (a). Description of the wire connection at splicing level.
  • Page 88 Corresponding solenoid valve highlighted on hydraulic valve bank (d). Information on the hydraulic part The hydraulic diagram animation is split in stages. Each stage corresponds to a function. Operating principle: Corresponding solenoid valve highlighted on hydraulic valve bank (d). Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 88/95...
  • Page 89 Display of the selected function hydraulic hoses. The hydraulic components operated by the function appear in color (a). Color arrows indicate the direction in which the oil flows in the hydraulic circuit. Zoom on the connection of hydraulic hoses (b). Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 89/95...
  • Page 90 Zoom on the hydraulic valve bank oil supply (c). (P): Hydraulic valve bank supply pressure. (T): Return to tank pressure. Zoom on the animation of the machine movement with regards to the function selected (e). Copyright 2012 KUHN S.A. Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 90/95...
  • Page 91 GMD44 _760001 _xxxxxx Video user guide To start the video Click on the video icon. The video player is always composed of: 1 navigation bar that enables interaction with the video. 1 scroll bar that enables to view your position with regards to the length of the video.
  • Page 92 GMD44 _760001 _xxxxxx SVG format illustration user guide The SVG format illustrations are represented by pictorials: A browsing system reminder is available by browsing on the SVG pictorial. Browsing in the picture To zoom in: Press key Ctrl and click on picture to increase the zoom percentage.
  • Page 93 GMD44 _760001 _xxxxxx Browsing principle for trouble shooting sheets Possible problems 2 ways to access to trouble shooting are available Possible problems. Search by keywords: Enter character string to search in field (1). The breakdowns containing the entered character string (2), is displayed.
  • Page 94 Other links rerouting the user to other sheets already listed on the site (2). After having fulfilled the stage operations Click on icon Yes to go to the next stage. Click on icon No when described operations have been respected but do not solve the breakdown: Either the stage provided the solution for the breakdown and closes the procedure.
  • Page 95 Copyright 2012 KUHN S.A. Printing date : 06-02-2014 GMD44_760001_xxxxxx Page 95/95...
