Contemporary Controls BAST-221C User Manual page 47

Control Out
Percentage
Device Instance
UDP Port No
Humidity Offset
Cooling Short Cycle
Cooling Maximum
Cycles
per Hour
Heating Short Cycle
Heating
Maximum Cycles
per Hour
Minimum Output for
AO2
Span Offset for
AO2
CO2 Input Low
Value
CO2 Input High
Value
CO2 Control Output
Proportional Band
CO2 Setpoint
CO2 Control
Minimum Output
After Hour Extension
Time
Input Low Value of
Valve Feedback
Input High Value of
Valve Feedback
Analog Input Low
Value
UM-15090000-AA4
AV 19 R/W
AV 20 R/W
AV 21 R/W
AV 22 R/W
AV 23 R/W
AV 24 R/W
AV 25 R/W
AV 26 R/W
AV 27 R/W
AV 28 R/W
AV 29 R/W
AV 30 R/W
AV 31 R/W
AV 32 R/W
AV 33 R/W
AV 34 R/W
AV 35 R/W
AV 36 R/W
AV 37 R/W
Percentage of Modulating/
Floating Control Output
Device Instance
UDP Port Number
Humidity Offset Value
Cooling Short Cycle Delay
Cooling Maximum Cycles
per Hour
Heating Short Cycle Delay
Heating Maximum Cycles
per Hour
Minimum Output Voltage in
Digital Value When Reach
Low Limit for AO2
Span Offset for AO2
CO2 Input Low Value
CO2 Input High Value
CO2 Control Output
Proportional Band
CO2 Setpoint
CO2 Control Minimum
Output Percentage
After Hour Extension Run
Time
Input Low Value of Control
Valve Feedback
Input High Value of Control
Valve Feedback
Analog Input Low Value
0～100 (0%～100%)
0~4194302
(Note: Changing this value
needs to unlock modification
for communication
parameters in advance.
i.e. AV17=0~255 or
512~768. Please refer to
LOCK(AV17) for details)
0~65535
-300~300 (-30.0～30.0
%RH)
1~3 Minutes
2~6 Cycles
0~3 Minutes
2~8 Cycles
0~125 (LSB)
-55~0 (LSB)
0~1000 ppm
1000~3000 ppm
100~2000 ppm
600~1000 ppm
0~20%
5~20(0.5~2.0) Hour
0~1000 (0.0～100.0 %)
0~1000 (0.0～100.0 %)
0~1000 (0.0～100.0 %)
Page 47
