Contemporary Controls BAST-221C User Manual page 43

Relay 2 Control
Relay 3 Control
Relay 4 Control
Relay 5 Control
Relay 6 Control
Relay 7 Control
Occupancy
Command
Fan Output for
Heating
Sensor type
Fan Mode
System Mode
Sleep
Temperature Source
Lowest Fan
Speed
Fan Speed Status
Baud Rate
Display Options
UM-15090000-AA4
BV8 R/W
BV9 R/W
BV10 R/W
BV11 R/W
BV12 R/W
BV13 R/W
BV 14 R/W
BV15 R/W
BV16 R/W
R/W
MSV 0
MSV 1
R/W
MSV 2 R/W
MSV3 R/W
MSV 4 R/W
MSV 5 R
MSV 6 R/W
MSV 7 R/W
On/Off Control of Relay 2
(Cooling Stage 2)
On/Off Control of Relay 3
(Heating Stage 1)
On/Off Control of Relay 4
(Heating Stage 2)
On/Off Control of Relay 5
On/Off Control of Relay 6
On/Off Control of Relay 7
Fan
Room Occupancy Setting
Disable/ Enable Fan
Output for Heating
Select Sensor type
Fan Mode
Working Mode: Heat, Cool or
Ventilation
Sleep (Only for Models with
Sleep Function Available).
Current Temperature Source
Lowest Fan speed in
Auto Fan mode
Fan Speed Status
Baud rate
(BACnet MS/TP)
LCD Display Options
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
0: Occupied,
1: Unoccupied
0: Disable
1: Enable
0: CO2
1: RH
0: Auto 1: Low 2: Med.
3: Hi
0: Cool Mode
1: Heat Mode
2: Ventilation @ Cool Mode
3: Ventilation @ Heat
Mode
0: Disable,
1: 0 Hr. Sleep
2: 0.5 Hr. Sleep
3: 1 Hr. Sleep
4: 1.5 Hrs. Sleep,
5: 2 Hrs. Sleep
0: Built-In Temp. Sensor 1:
Remote Temp. Sensor 2:
Assigned through
Modbus
0: Stop 1: Low 2: Med. 3: Hi.
0: Stop 1: Low 2: Med 3: Hi
0: 9600 bps
1: 19200 bps
2: 38400 bps
3: 57600 bps
4: 76800 bps
0: T & Time (if available) 1:
SP & Time(if available) 2: T
& CO2
