Minimum Fan
Output
Maximum Fan
Output
Low Fan Speed
Setting
Med. Fan Speed
Setting
Hi Fan Speed
Setting
Minimum Off
Time
Minimum On Time
Stroke Time
Set Point for
Humidity
Dew Point Set
Point
Occupancy Status
Window-Door Status
Cooling-heating
Status
Relay 1 Status
Relay 2 Status
Relay 3 Status
Relay 4 Status
Relay 5 Status
Relay 6 Status
Relay 7 Status
Dl 1 Status
Dl 2 Status
Dl 3 Status
UM-15090000-AA4
AV 41 R/W
AV 42 R/W
AV 43 R/W
AV 44 R/W
AV 45 R/W
AV 46 R/W
AV 47 R/W
AV 48 R/W
AV 49 R/W
AV 50 R/W
BI 0 R
BI 1 R
BI 2 R
BI 3 R
BI 4 R
BI 5 R
BI 6 R
BI 7 R
BI 8 R
BI 9 R
BI10 R
BI11 R
BI12 R
Minimum Fan Output at Auto
Fan Mode (for Modulating
Fan Application)
Maximum Fan Output at
Auto Fan Mode (for
Modulating Fan Application)
Low Fan Speed Setting (for
Modulating Fan Application)
Med. Fan Speed Setting (for
Modulating Fan
Application)
Hi Fan Speed Setting(For
Modulating Fan Application)
Minimum Off Time
Minimum On Time
Stroke time
Set Point for Humidity
Control
Dew Point Temperature
Set Point
Status of Occupancy
Window/ Door Status
Status of Cooling/Heating
Control
Output
Status of Relay 1
(Cooling Stage 1)
Status of Relay 2
(Cooling Stage 2)
Status of Relay 3
(Heating Stage 1)
Status of Relay 4
(Heating Stage 2)
Status of Relay 5
Status of Relay 6
Status of Relay 7
Fan
Status of Digital Input 1
Status of Digital Input 2
Status of Digital Input 3
0%~Reg 51
Reg 50~100%
0%~Reg 53
Reg 52~Reg54
Reg 53~100%
0~180 seconds
0~180 seconds
10~1600 sec.
0~1000 (0.0～100.0
%RH)
℃/°F
-999~9999: -99.9～999.9
0: Room Occupied
1: Room Unoccupied
0: Door/Window Closed
1: Door/Window Open
0: Close & Off 1: Open & On
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
0: Off, 1: On
