Contemporary Controls BAST-221C User Manual page 44

Control Type
BACnet Object Table - BW2 Wi-Fi Model (BACnet/IP)
Object name
BACnet Thermostat
Object name
Current
Temperature
Temp SP Status
Built-in
Temperature
Sensor
Remote
Temperature
Sensor
Current Humidity
UM-15090000-AA4
MSV 8 R/W
Type & Instance
Device 100001
Type & Readable/
Instance Writable
AI 0 R
AI 1 R
AI 2 R
AI 3 R
AI 4 R
Control Type Selection
Object Property
(Readable/Writable)
Model Name (R)
Application Software Version (R)
Object Identifier (R)
Object Name (R/W)
Description
Current Temperature
Active Temperature Set-
Point
Built-in Temperature
Sensor Reading
Remote Temperature
Sensor Reading
Current Humidity
3: CO2 & Time 4: SP & CO2
5: T & RH
6: T & Valve
1: Cool Only
2: 4-Pipe Cooling or Heating
Manual Changeover
3: 4-Pipe Cooling and
Heating Auto Changeover
4: Heating Only
NOTE: Cool only and Heat
only types disabled
Range
32 characters (max.)
Range and Definition
-999~9999: -99.9～999.9
℃/°F
°C :0~500 (0.0～50.0℃)
°F : 320~1220
(32.0~122.0°F)
-999~9999:-99.9～999.9
℃/°F
-999~9999:-99.9～999.9
℃/°F
0~1000: 0.0～100.0%RH
Page 44
