Technical Information
Product Ratings

Environmental Testing Criteria

PLUS+1® Controller Family

General Product Ratings

Description
Operating temperature
Storage temperature
Allowable module supply voltage
Module sensor supply voltage
Analog input voltage levels
Allowable output load current (per
pin)
Module allowable total output
current
All modules Ingress Protection (IP)
rating**
All modules CE rating

PLUS+1 Module Environmental Testing Criteria

Climate Environment
Description
Storage temperature
Operating temperature
Thermal cycle
Humidity
Degree of protection
520L0719 • Rev PB • Feb 2014
Units Minimum Maximum
˚C [˚F] -40 [-40] 70 [158]
˚C [˚F] -40 [-40] 85 [185]
Vdc 9 36*
Vdc 4.8 5.2
Vdc 36*
A
A
Applicable standard Comment
IEC 60068-2-1, test Ab, IEC
60068-2-2 test Bb
IEC 60068-2-1, test Ab, IEC
60068-2-2 test Bd
IEC 60068-2-2, test Na, IEC
60068-2-38 (partial)
IEC 60068-2-78, IEC Damp heat steady state and cyclic.
60068-2-30 test Db
IEC 60529
Comment
Maximum operating temperature for
MC012-026/029 modules is 105° C (221°
F).
Maximum storage temperature for
MC012-026/029 modules is 105° C (221°
F).
Minimum allowable supply voltage for
the MC038-010 module CPU power pin
is 6 Vdc.
* MC050-055/05B input voltage
maximum is limited to 16 Vdc.
Sensor voltage drops below the
minimum value if module supply
voltage < 9 Vdc. Exception for
MC050-055/05B and MC024-01A, see
Sensor Power Supply Ratings, page 23.
* MC050-055/05B input voltage
maximum is limited to 16 Vdc.
See individual module date sheets.
See individual module data sheets.
IP 67
** The PLUS+1 modules IP 67 rating is
only valid when the module mating
connector is in place and unused
connector pin positions have sealing
plugs installed.
CE compliant.
25
