Product Specifications

Environmental

Testing Criteria

Transit Mixer Controller (TMC)
General PLUS+1 Module Ratings
Description
Operating temperature
Storage temperature
Allowable module supply voltage
Module sensor supply voltage
Analog input voltage levels
Allowable output load current
(per pin)
TMC allowable total output current A
IP rating
(with mating connector attached)
CE rating
* PLUS+1 module IP 67 rating is only valid when the module mating connector is in place and unused connector pin positions
have sealing plugs installed.
Testing Criteria
Climate Environment
Description
Storage temperature
Operating temperature
Thermal cycle
Humidity
Degree of protection
Chemical Environment
Description
Salt mist
Chemical resistance
Mechanical Environment
Description
Vibration
Bump
Shock
Free fall
11061324 • Rev CA • Sep 2013
Units Minimum Maximum Comment
˚C [˚F] -40 [-40] 70 [158]
˚C [˚F] -40 [-40] 85 [185]
Vdc 9 36
Vdc 4.88 5.12
Vdc 36
A 8
11.5
Applicable standard Comment
IEC 60068-2-1, test Ab, IEC
60068-2-2 test Bb
IEC 60068-2-1, test Ab, IEC
60068-2-2 test Bd
IEC 60068-2-2, test Na, IEC
60068-2-38 (partial)
IEC 60068-2-78, IEC Damp heat steady state and cyclic.
60068-2-30 test Db
IEC 60529
Applicable standard Comment
IEC 60068-2-58 test Kb
ISO 16750-5
Applicable standard Comment
IEC 60068-2-6 test Fc,
IEC6008-2-64 test Fh
IEC 60068-2-29 test Eb
IEC 60068-2-27 test Ea
IEC 60068-2-32 test Ed
All current returns must be directly wired
to the machine ground to reduce any
voltage losses to the sensor power line.
Failure to comply may result in a sensor
power voltage lower than the specified
minimum.
IP 69K (front)
IP 67* (rear)
CE compliant
9
